Pillar Drilling Machine Dealers in Gadhechi Vadala, Bhavnagar

• Brand Name: JaY

We are offering rigid pillar drilling machine. jay industries, leading mfrs. Of drilling machines. model : jip25h spec: 10" inch center. 8" inch spindle travel. ram dia.: 72mm column dia: 90mm. mt-3 mt-4 available. approx weight: 230 kg.

• Country of Origin: India
• Type: Drill
• Weight: 100-1000kg, 1000-2000kg
• Condition: New
• Automatic Grade: Semi Automatic, Manual
• Power Source: Mechanical
• Warranty: 1 Year
• Brand Name: Sp

• Weight: 100 kg
• Diameter of Column Pilling: 74.20mm
• Spindle Center to Pillar: 204mm
• Max. Spindle Travel: 130mm
• Table Size: 260*235mm
• Base Size: 465*315mm
• Max. Distance Spindle Nose to Table: 660mm
• Max. Distance Spindle Nose to Base: 910mm
• Spindle Nose Taper Bore: MT-2/3

The Pillar Type Drilling Machine provided by us is widely used by various companies across India. The Pillar Type Drilling Machine that we provide to our clients is known for its efficient performance and long life. Moreover, this Pillar Type Drilling Machine requires low maintenance. We provide Pillar Type Drilling Machines at the market leading price. Minimum order Quantity : 10 Metric ton

• Certification: ISO 9001:2008
• Weight: 100-200kg
• Voltage: 110V
• Automatic Grade: Automatic
• Power: 1-3kw
• Driven Type: Electric
• Warranty: 1year
• Item code: SE-4

We are a well reckoned Manufacturer, Supplier and Exporter of Pillar Drilling Machine (SE-4). Customers from all over the world acclaim our machine because of its rigid make, dimensional accuracy, high speed output, and precise results. To cater to bulk requirement of the buyers, we stock the Pillar Drilling Machine in our large warehouses. Some Important Features : Important parts are made from close graded casting. Main Spindle made from EN steel with 6 slots in machined by hobbler machine and Morse taper bore is provided internally grinded. Provision of window for change of gear on top cover. Spindle sleeve is properly guided in honed drill head bore on 6 ball & roller bearing for smooth & accurate running. Main Quill and spindle are hardened and grounded and spindle tapper bore is also internal grinded. Main spindle run out of tolerance as per IS:2199 Drill Head are made from best quality martial and boring on imported boring machine of Japan. Precision anti-friction bearing for all rotating members. Standard Accessories : Motor Pulley, Fine feed Attachments & Drift Key. Optional Accessories : Electric Motor, Reversible Switch, V-Belt, Coolant Pump with Tank & Fitting.

•  :
• Drilling Capacity in M.S.: 40 AA
• Drilling Capacity in C.I.: 45
• Tapping in M.S.: 25
• Spindle Hole Taper: MT-4
• Spindle Travel: 250
• Spindle Speeds (RPMxStep): 88x1404x9
• Diameter of RAM: 78
• Max. Dist. Spindle Nose to Table: 530
• Spindle center to column: 345
• Table Size: 450x455
• Column Diameter: 130
• Dist. from Spindle Nose To Base: 1000
• Motor 1440 RPM: 2 HP
• V-Belt:
• Weight Approx: 410 KG.

We are engaged in manufacturing and supplying of pillar drilling machine, which is manufactured in accordance with set industrial standards. Our range of pillar drilling machines is widely appreciated for its high performance and longer working life among the clients.

V.p. Machine tools - we are ranked amongst the distinguished manufacturers, suppliers, and exporters of pillar drilling machine in india.

Over the years we have been catering to the requirements of our clients manufacturing and exporting a quality 38 mm Fine Feed Pillar Drilling Machine (P38). These offer drilling capacity of 38 mm in M.S. and 42 mm in C.I. Available in customized form, these machines bear maximum distance of 760 mm from spindle nose to table.
