VCB Control Panel is used to operate the H.T. breakers from remote place. VCB Control Panel also helps in protecting the system against earth fault overload and short circuit through o/c + EF relay. Many other protection-relays such as differential relay, transformer protection relay, negative sequence relay, over voltage/under voltage relay, neutral displacement relay, etc., may be provided as per the need. In the VCB Control Panel, the alarm circuit and indication for various fault detection are also provided. Highlights Dimensional accuracyLow maintenanceEasy operationConvenient installation

When it comes to PLC Control Panels, the name of Juhi Electricals Pvt. Ltd. is recognized as a dependable Manufacturer, Exporter & Supplier in market. These PLC Control Panels made with the finest materials and components so as to render flawless performance. The valuable customers can avail these PLC Control Panels in different specification and at the market leading prices from us.

PCC Control Panels are backbone of any industry or any organization with the help of which the power is distributed. Power Distribution Boards are designed for the power distribution in different sections of an industry, Big building, organization etc. where only short circuit. Protection and overload protection are required. These protective devices can be fitted with different protective relays which can trip the CB against various types of faults. Maheshwari Electrical Contractors,Gwalior.Dainik Jagaran, Bhopal.(Jagran Pulication P. Ltd.)/li>Oriental Institute Of Science & Technology, Bhopal. MES Project S.R. Builders & Suppliers, Jabalpur (Mes Sagar & Jabalpur)Venus Engineering (Mes Jabalpur)Poonam Electricals & Services (Mes Bhopal & Mahon)Girdharilal Construction (Mes Bhopal) Ircon Bhopal (Mes ,Bhopal)Shanti Enterprises (Mes Panchmadi Sunil Enterprises (Mes Panchmadi)

As we can recognize by name MCC Control Panels are designed to control motor operations from one center. Each motor is provided with starters protected by switchgears. The starters mainly consist of contactors, overload relay or motor protection relay, push buttons, timers, etc. The starters protect against overloads and other faults such as single phasing under voltage, under current, over current phase sequence, etc. But for each protection separate or combined equipments are added with the starters. The starters may be protected against short circuit, overload, etc. with the help of MCB, MCCB, switch fuse unit, motor protection circuit breakers as the need or requirement may be. The starters may be of various types such as Direct on line, Semi Automatic Star Delta Starter, Fully Automatic Star Delta Starter, Auto Transformer Starters, Slip Ring Starters, PLC based Starters, AC Drives, DC Drives, etc. In the MCC Control Panels, the starters are installed in separate compartments and are duly wired ready for connection. Then all the starters are connected to the main circuit breaker through bus bar systems. The Starter may be provided with measuring instruments such as AM, VM, KWh meter, etc.

Power : 15 Kw

Phase : 3

Voltage : 11kV

To maintain power factor using contactor microprocessor based or plc, apfc relays and and capacitors are the requirement. -auto mains failure panel using engine start relay stop relay contactor and various relays -auto transformer starters using contactors timers,auto transformers timers.

AMF Control Panel is used to operate at two source power supply system, one main power supply and the second may be diesel generator power supply. The system of AMF Control Panel works with the fundamental that as the main source supply turns off, the signal goes to the starting system of the alternative power supply and it begins attempting to start it. When it is started and attains full voltage, the alternative circuit breaker gets on. Alternatively, when the main source supply resumes, it breaks the supply from the alternative source and switches over to main source and then it turns off the Alternate source automatically. We make AMF Control Panel available at the best prices in the market. Highlights DurableEasy maintenanceHighly efficientReasonable prices

Auto Transformer Starter, which works in Delta formation, directs online and is used for initial high torque applications. With the help of Auto Transformer Starter, the motor is started at low voltage, in DOL formation, with the help of contactors and auto transformer at 60% /70% / 80%. We make Auto Transformer Starter available in desired specifications, so as to provide clients with maximum satisfaction. Highlights Low maintenanceHighly efficientDurableEasy installation

Slip Ring Starter is also used for high torque motors, but the speed in Slip Ring Starter is gradually increased with the help of contactors and external resistance provided in the rotor circuit. In the Slip Ring Starter, the stator winding is given full voltage from the beginning. Highlights Well-designedEasy installationLow maintenanceHighly efficient
