Red Phase India Private Limited Daria, Chandigarh

red phase engineer’s, one of the leading quality manufactures of wide range of servo voltage stabilizers, automatic voltage controller, voltage regulator, isolation transformer, l.th.t electrical panel designed & manufactured by highly trained engineers. the name trusted all over india since 1981.this trust is built over shear dedication, hard work & commitment to quality. the learning acquired over 27 years has been harnessed to offer superior quality product at competitive price. being an iso 9001:2008 certified company, our product is manufactured as per iso standards. today with more than 2 decade of experience in the manufacturing of electrical products, red phase engineer’s has grown up in geographical range to become one of the leading manufactures of electrical products. our product comprehensively fulfilled the request of national & international standards specification & their stringent requirement. we manufacture each our equipment under one roof to achieve better quality. we strive to maintain the quality & uniqueness of our product, keeping our price low & deliver it on a schedule. our effect has been awarded with repeat orders from private & public sectors, big industries, educational institutes & big mnc.

This is due to Inductive and SMPS loads, electronic ballasts, PWM switching systems, or even improper earthing. Such electrical noise often damages costly Hi-Tech machinery, unduly interrupt factory operations and increase down time resulting in increased expenses. The lack of adequate protection in such environments results in the steady rise of failure rate in such equipments. Isolated power supply has therefore become a necessity in order to prevent such breakdown time and costs. Ultimate Protection against Electrical Noises RED PHASE Ultra Isolation Transformer is the most powerful solution to help eliminate all types of noise, particularly Common Mode Noise, Spikes, Surges and Transient Noise, which act as silent killers inside factories and commercial parks alike.

We are manufacturing industrial type automatic voltage regulators (servo stabilizers rectifiers) using the differential wound vertical roller type regulators. Manufacturing linear type +- heavy duty regulators with rollers rolling on both the sides of the coil (as illustrated in the brochure enclosed). The size of conductor used is more than three times than used in conventional design regulators. Being + type, the same winding is used for boosting the voltage on one side and bucking the voltage on the other side of the regulator. So, the rating of the regulator required is half of the conventional design regulator. The losses of differential wound linear RED PHASE’ series of Servo voltage stabilizers offer a reliable and tested economic solution to inconveniences caused by voltage fluctuation. To use ‘RED PHASE’ SCVR is a real investment because the elimination of the inconveniences means a reduction in costs and an increase in productivity. Very often it is only necessary to avoid a few minutes machine downtime or just one failure to repay the cost of the stabilizers. ‘RED PHASE’ SCVRs are particularly suitable for applications that require: Silent Feature High reliability   Capability to compensate wide mains voltage variations   High precision of stabilized voltage    Stabilizing of high power services    Simple and limited maintenance   Networking ‘RED PHASE’ SVS regulate through a series transformer. A micro based control circuit drives the variable autotransformer that supplies the required voltage to the series transformer either in phase or phase opposition to bring the mains to the rated value. Unbalanced Load models that, having three separate control circuits, individually regulate each phase and are therefore suitable for unbalanced lines and load unbalance between phases up to 100% phase opposition to bring the mains to the value. Unique Features RED PHASE has developed state of art DSPIC based controller to stabilize utility voltage. Apart from its standard feature it has following unique features to improve reliability, serviceability and reduce system down time.

Servo Voltage Stabilizer in 400kva, 3ph, Oil Cooled Linear Type Warranty 5years on site.

Based on our RED PHASE technical expertise we are able to supply Compact Type Substation is compartmentalized with suitable medium voltage, low voltage sections & transformer section with separate doors for each compartment. Our Packaged Sub-Stations are tested as per latest IEC standard 62271-202. These Packaged Sub-Stations are designed & manufactured as per the tailored requirement of thecustomer. Variety of HV/ LV Switchgear /VCB can be chosen & the CSS is designed accordingly.They are also designed to withstand electrical impulses, thermal and dynamic stresses. They are fully compartmentalized, thus safe to use & require minimum maintenance. One of the biggest advantage of using a PSS is that there’s no need to use abling thus being more economical as well as safer than using bulky non-aesthtic cables.

The RP Series includes the 1 KVA to 200 KVA (1 Phase, 3 Phase) double conversion On-Line UPS with an isolation transformer at Output. The Load is supplied continuously by the inverter with clean, stabilized and regulated sine wave output power. Input & Output filters increase the immunity of load from power disturbances and surges. RP Series is useful for mission critical applications like IT, Call Centres, Hospitals, and Industrial Automation etc. Thanks to state-of-the-art microprocessor / DSP based outstanding advanced technology design. RP Series is supplied with software which can be used for monitoring various parameters of the UPS and also can be useful for remote monitoring / control on the web by adding SNMP Card. SALIENT FEATURES Fully Programmable Rectifier, Inverter, Batteries, Static Switch & Dynamic Behavior. Jumper Selectable O / P Frequency 50 Hz, 60 Hz or 400 Hz Isolation Transformer for Better Performance Latest Microprocessor / DSP Technology 24 MIPS Highest Speed for Better Control Advanced Battery Management Isolated Output Upto 7 Units in Parallel Sixth Generation Low exhaust IGBT GUIDED. PC Testing for Easy Installation

red phase engineer’s, one of the leading quality manufactures of wide range of servo voltage stabilizers, automatic voltage controller, voltage regulator, isolation transformer, l.th.t electrical panel designed & manufactured by highly trained engineers. the name trusted all over india since 1981.this trust is built over shear dedication, hard work & commitment to quality. the learning acquired over 27 years has been harnessed to offer superior quality product at competitive price. being an iso 9001:2008 certified company, our product is manufactured as per iso standards. today with more than 2 decade of experience in the manufacturing of electrical products, red phase engineer’s has grown up in geographical range to become one of the leading manufactures of electrical products. our product comprehensively fulfilled the request of national & international standards specification & their stringent requirement. we manufacture each our equipment under one roof to achieve better quality. we strive to maintain the quality & uniqueness of our product, keeping our price low & deliver it on a schedule. our effect has been awarded with repeat orders from private & public sectors, big industries, educational institutes & big mnc.

The Technology concept of Differential wound linear regulator with Series Transformer in RED PHASE’S make Automatic Voltage Controller. We are manufacturing Industrial type Automatic Voltage Regulators (Stabilizers/Rectifiers) using thedifferential wound Vertical Roller Type Regulators.Manufacturing LINEAR TYPE +/- Heavy Duty Regulators with rollers rolling on both the sides of the coil (as illustrated in the brochure enclosed). The size of conductor used is more than THREE TIMES than used in conventional design regulators. Being + type, the same winding is used for boosting the voltage on one side and bucking the voltage on the other side of the regulator. So, the rating of the regulator required is half of the conventional design regulator. The losses of differential wound linear regulator should be 1/18th of the conventional type regulator and due to heavy section of copper used in our regulator, overall size is more and practically the losses of our regulator are 1/5th of the conventional type regulator. The manufacturing material cost of differential wound linear regulator is almost more than THREE TIMES the cost of conventional design Regulator. As per the Regulator design, the regulator is technically OUT OF CIRCUIT, When the input voltage is LOWEST/HIGHEST as per the voltage range of the stabilizer while in stabilizer with conventional brush type regulators, the regulator is maximum in the circuit and losses are maximum at LOWEST/HIGHEST as per the range of the stabilizer. The Actual Efficiency of our stabilizer in running conditions at 100% Load for the (360-460 V) model will be 99.5% in comparison to less than approx. 95-96% of conventional type stabilizer for the Automatic Voltage Controller of similar rating. WINDINGS linear Coils are manufactured with copper strips of heavy cross sectional area instead of copper wires in conventional design with 4-QPC paper layer cover plus 3 TPC – Polyester film cover for better insulation to resist the high temperatures on continuous duty cycle with Electrolytic grade copper strip while taking the current density of 2 to 2.5 amps/mm2 in oil therefore the maximum temperature rise at full load never goes more than 25 degree centigrade while in conventional design accordingly we use more

HT AUTOMATIC VOLTAGE REGULATOR, this is also a low profile product in the industry and many may not be aware of this product either. But, this product is in existence and successfully serving a huge clientele from past few decades. Now, we at Red Phase has taken the initiative to reintroduce the product in the industry and most importantly manufacturing with its trusted original UK Based mechanism & designing. Red Phase offers revolutionary state of art Transformer with Built In AVR, which is a combination of HT AVR and a standard distribution transformer. The fluctuating HT voltage from Grid supply is initially controlled by the HT AVR with accuracy of +/-1% and then fed to the transformer which transforms in its standard ratio to LT voltage. Subsequently, stabilized HT voltage will result in a stabilized LT voltage with accuracy of +/-1%. Basically, input will be 11/33KV and output will be LT voltage with +/-1% can be obtained through a single product, can be understood better through schematic diagram mentioned below:

red phase engineer’s, one of the leading quality manufactures of wide range of servo voltage stabilizers, automatic voltage controller, voltage regulator, isolation transformer, l.th.t electrical panel designed & manufactured by highly trained engineers. the name trusted all over india since 1981.this trust is built over shear dedication, hard work & commitment to quality. the learning acquired over 27 years has been harnessed to offer superior quality product at competitive price. being an iso 9001:2008 certified company, our product is manufactured as per iso standards. today with more than 2 decade of experience in the manufacturing of electrical products, red phase engineer’s has grown up in geographical range to become one of the leading manufactures of electrical products. our product comprehensively fulfilled the request of national & international standards specification & their stringent requirement. we manufacture each our equipment under one roof to achieve better quality. we strive to maintain the quality & uniqueness of our product, keeping our price low & deliver it on a schedule. our effect has been awarded with repeat orders from private & public sectors, big industries, educational institutes & big mnc.

Red Phase brings you the finest products designed and engineered by the people who have been in the same field for the last 30 years. Rectifier is an economical and most efficient method of obtaining DC from AC supply. Red Phase manufactures a wide range of rectifiers covering 0-500 Volts and upto 15000 Amps. capacity suitable for Electroplating, Anodising, Hydrogenation and many other Electrochemical processes. The entire manufacturing process is under one roof ensuring 100% quality control at every stage of production. We believe in quality & customers satisfaction.

Red phase control panels are well equipped with high-tech machineries, qualified personnel having expertise in control panel design, panels manufacturing and development, project planning, testing & commissioning of all types of electrical panels. Introduction a electrical distribution panel board is a component of an electricity supply system which divides an electrical power feed into subsidiary circuits, while providing a protective fuse or circuit breaker for each circuit in a common enclosure. Our wide range of distribution panels:-- 1. Outdoor feeder panel low-voltage feeder pillars form a basic part of most public and many private distribution networks. Feeder pillars are connected to the distribution board. These pillars are usually made of strong and weather proof materials like galvanized sheet steel, stainless steel. Feeder pillars are mainly used in electrical installations.

The demand of electricity in India has been increasing rapidly in the last few years. There is a mushroom growth in the high rise buildings, shopping areas, CNG and petrol stations, residential colonies, etc. Due to the scarcity of space in cities, installation of conventional oil type transformers in such congested and populated areas is always a big safety risk. The developed as well as many developing countries are installing dry type transformers as a solution for ensuring safety in such scenarios. Types of Dry Type Transformers There are primarily two main manufacturing techniques for dry type transformers; Cast Resin and Vacuum Pressure Impregnated (VPI) with their own typical features. The main difference is their insulation class; Cast Resin is Class F (155°C) and VPI is Class H (180°C). The Vacuum Pressure Impregnated transformers not only offers in-build safety feature but there are many other advantages of using these transformers such as improved reliability, reduced losses, minimal maintenance, enhanced overloading capability etc.

At Red Phase, we maintain the highest levels of customer satisfaction by offering effective customer specific a products at uncompromising quality levels. We offer a widest range of Power & Distribution Transformers that is appreciated all over the world for its strict quality measures and testing standards in all respect. Our transformers are designed and developed using latest technologies and can be provided with a variety of terminations so as to suit the requirements for new installation or replacement. Optimum efficiency is ensured by delicate proportioning of core and winding losses using CRGO M3 to MS MOH lamination, Electrolyte Grade 99.9% pure copper, with transposition in L.V. coil for current sharing in parallel conductors, electric grade press paper, board and mineral oil. Also, these have cooling systems with on load and off load tap changing facility. Thus better regulation is achieved resulting in higher efficiency and longer life. The Power & Distribution Transformers offered by Red Phase find extensive usage in multiple sectors like State electricity boards and housing complexes. Our transformers are available in different ratings and voltages according to the requirements of the client. Below mentioned are few tests on which are applied on our transformers to achieve the

Voltage variations are an increasingly common and dangerous nuisance that can damage electronic components like power supplies, drives, PLCs, controllers etc. Their effects are widely felt in CNC, Printing, Textile machines in addition to Laboratory, Data processing, Medical & Telecommunication equipments. As an effective solution, UCPL has designed state of the art Voltage Stabilizers to protect these equipments against voltage variations and offering improved power quality, thereby minimizing break downs of costly equipments. Our Stabilizers are manufactured out of prime grade of magnetics & electrical conductors, housed in enclosures manufactured on CNC machines & powder coated as per IS/BS standards. Stringent quality assurance programme at various stages of manufacturing ie. raw materials, sub assemblies, assembly & finished goods ensures high reliability & consistent performance. Our Servo voltage stabilizers provide controlled & desired output voltage against wide range of voltage fluctuations. Apart from protecting the equipments from damage, they save energy during high voltage conditions. PROTECTIONS FEATURES Single Phasing Prevention Output Electronic Over Load Protection Phase Reversal Protection Input Short Circuit Protection with MCB Input Over Load Protection with MCB Output Low Voltage Protection Output High Voltage Protection Audio Alarm for Protections

We are manufacturer of servo voltage stabilizer in industry. We offer best after sales service to the customer at an affordable pricing full satisfaction. contact : er. Nikhil red phase engineer's

Red Phase Control Panels are well equipped with high-tech machineries, qualified personnel having expertise in control panel design, panels manufacturing and development, project planning, testing & commissioning of all types of electrical panels. Introduction A Electrical distribution Panel board is a component of an electricity supply system which divides an electrical power feed into subsidiary circuits, while providing a protective fuse or circuit breaker for each circuit in a common enclosure.

tred phase voltage stabilizers come with an experience of 10 years and are renowned for their high quality, reliability and durability automatic voltage stabilizer red phase automatic voltage stabilizer controls and transforms the excessively low or high voltage into the safe operating range, thus protecting electronic equipments like refrigerators, air conditioners, washing machines, bottle coolers, research and laboratory equipments etc. Against excessive voltage variation. salient features it has all solid state electronics circuit which provides reliability, durability and servicing and it operates at all power factors.   minimum energy losses and less heating is another feature of this heavy duty transformer. selection switch provides the facility of input and output voltage reading.   it is sleek, attractive and comes with special stoving paint finish.

We are offering Lt Panels etc.WE ARE THE OF THE L.T PANELS IN THE INDUSTRY. WE OFFER BEST AFTER SALES SERVICE TO THE CUSTOMER WITH FULL SATISFACTION.

We are manufacturer of servo voltage stabilizer in industry. We offer best after sales service to the customer at an affordable pricing full satisfaction. contact : er. Nikhil red phase engineer's
