Adams Technologies Private Limited Mahalingapuram, Chennai, Tamil Nadu

All related Signal conditioners for Accelerometers, Force sensors, Microphones and Pressure sensors are supplied. Miniature In-line chare amplifiers and ICP power supply source for airborne applications are also available.

Pressure sensors with ranges from -1 bar to 1000 bars are offered for measuring pressures of different fluid media. Different mounting configurations are available. The sensors offered are of thin film type(made by EFE) and charge and integrated electronics type(made by Dytran). EFE sensors can take excitation ranging from 9.5 V to 27 V. Different output options are available. One can choose either voltage or current output depending on his requirements. Dytran sensors don’t need any excitation and any standard signal conditioning front end will be able to acquire data from these sensors.

All types of microphones required for accurate measurement of sound from GRAS are available. Any type of microphone, Pressure field, Free Field or Random Incidence, Polarised or prepolarised, high sensitivity or low sensitivity is available. Products include Surface Microphone, Array microphones, Intensity Probes, Calibrators, Pistonphones, Kemar, Artificial Ears and Pinna Simulators.

The EMA (Electro-Magnetic Actuated) damper dynamometer is a serious tool for racers and damper manufacturers alike. It’s versatile, and boasts performance features like a 0.010 to 7 inch (.25 – 177mm) stroke range, frequency response above 100 Hz, and velocities in excess of 3 meters per second. This machine is a must-have piece of equipment for any research and development facility. The EMA is a true linear actuator. It provides extremely fast response as well as excellent positioning accuracy, while eliminating backlash, windup, and wear. Two models are available to fit your testing needs EMA2k-2000lb (8.8Kn). force, EMA4k-4000lb (17.6Kn) force The EMA can play back track data collected from a number of commonly used onboard, automotive data acquisition systems. Partial, full, or multiple lap play back is possible. EMA is also fully capable of reproducing sinusoidal waveforms identical in comparison to our industry-standard crank-style dynamometers. In addition, triangle, square, and composite custom waveforms can also be generated and driven through the EMA system, which is used in conjunction with our Shock6.0™ Test Control and Damper Analysis software.

Feature : Drive position resolution of 1 micron.,16-bit motion control card.

The 10VS damper dynamometer is a faster and more powerful version of the 5VS. The 10VS is commonly used in a research and development facility, portable damper development support trailer, or a race team’s shop. The 10VS is fully computer controlled using the SHOCK™ Test Control and Damper Analysis software. The standard 10VS features six English or Metric strokes up to 4 inches (100mm). It has a force capacity to +- 3,500 lbs. and velocities up to +- 62 ips (1.6 msec). Higher velocities are available as an option. The 10VS is the system of choice by many of the world’s leading automotive companies and OEM damper manufacturers for their vehicle ride and handling activities. The 10VS damper dynamometer is a faster and more powerful version of the 5VS. The 10VS is commonly used in a research and development facility, portable damper development support trailer, or a race team’s shop. The 10VS is fully computer controlled using the SHOCK™ Test Control and Damper Analysis software. The standard 10VS features six English or Metric strokes up to 4 inches (100mm). It has a force capacity to +- 3,500 lbs. and velocities up to +- 62 ips (1.6 msec). Higher velocities are available as an option. The 10VS is the system of choice by many of the world’s leading automotive companies and OEM damper manufacturers for their vehicle ride and handling activities.

Brand Name : Adams

Adams supply different type accelerometers for different applications. Accelerometers with different mounting configurations, different sizes and weights are available to suit the applications. Both Charge and Integrated electronics type (ICPIEPE) accelerometers are available. Variable capacitance accelerometers are offered for the applications requiring high sensitivity measurements. Accelerometers for special applications like airborne and seismic accelerometers are also available.
