Input Output Cards Dealers in Chennai

• Color: Light Green
• Voltage: 24VDC
• Driven Type: Eelectric
• Warranty: 2yrs
• Chipset: North Bridge Intel GM45 Chipset
• Graphic Card: Integrated

We are one of the most trusted Suppliers of Serial Output/Input Control Card. This STM8S microcontroller based control card can be used to switch ON & OFF 17 relays via serial communication (RS232 or UART TTL). It can also read the status of 8 digital inputs. The relay output status & digital input status is continuously sent out as RS232 data string. It operates in 9600BPS, 8-N-1 mode. This control card can be controlled via our weighing scale PCB or via PC. This board is very useful for industrial control & automation. Simple control commands is sent to card to switch ON & OFF the Controllers output pins. For example sending ASCII character A will make the connector PIN marked A on the PCB to go high(5 volts) & sending ASCII character a will make the same pin to go low(0 volts). Sending ASCII B will switch ON the pin marked B on the PCB & so on. You can control 17 pins from A to Q & read 8 pins from R to Y.
