Shrinking Machines Dealers in Chennai

• Material: Stainless Steel
• Power: 5 HP
• Type: Packaged Type/ Compact Type
• Plant Capacity: 24 BPM bottle Filling machine
• Make: Acroama
• Operation: Automatic Filling Machine
• Features: It is cheap than carton box, Easy to operate, less Area required

• Power Supply: 230V,50Hz Single Ph 230V,50Hz Single Ph 230V,50Hz Single Ph
• Max. Sealing Size: 430mmx290mm 550mmx420mm 800mmx600mm
• Max. Packing Size: 400mmx270mm 520mmx400mm 780mmx580mm
• Product Height: 200mm 250mm 300mm
• Max. Installed power: 3.5 Kw 4.5 Kw 7.5 Kw
• Real consumption: 1.75 Kwh 2.25 Kwh 3.75 Kwh

• Application: Industrial
• Driven Type: Electric
• Warranty: 1 Year
• Packaging Details: In wooden packing

Applications High Speed Aero - Dynamic Blower Design Works with polyolefin, PVC, LDPE & Shrink Films Automatic Cooling Dual Mechanical Air Velocity Control DC Motor Drive with variable speed conveyor Teflon Coated ROD / BELT conveyor Heavy duty high temperature blower motor Heavy gauge steel construction >> Mounted castor wheels for easy mobility

• Brand Name: VEPT,VEPT
• Material: Stainless Steel
• Driven Type: Electric
• Color: Grey
• Condition: New
• Operating Type: Automatic
• Certification: ISO 9001:2008
• Voltage: 440V
• Packaging Type: Wooden Box
• Specialities: Rust Proof, Long Life, High Performance, Easy To Operate
• Type: Stretch Wrapping,Automatic & Semi-Automatic
• Weight: 400-500 Kg
• Warranty: 1 Year
• Country of Origin: India
• Corrosion Resistance: Yes
• Machine Structure: Vertical
• Warranty: 1 Year

The bundler contains customized product in feed and collating system Bottom and top film dispensers with auto unwinding mechanism. sealing with improved Teflon sealers Fully controlled through plc and pneumatic components of Festo/SMC make. Size of the shrink tunnel : length x width x height : 2500 x 650 x 500 mm Main drive : 1 hp bonfiglioli geared motor heater capacity : 18 KW The heaters are designed with fins and are easily replaceable Duct is insulated with mineral wool. circulation fan in duct whirls the hot air around Circulation fan capacity : 0.5 KW and cooling fan capacity : 0.5 KW PLC : Allen bradley pneumatics : Festo make PID temperature controllers Machine is suitably safety guarded with latch type limit switches

• Power: 6.5KW
• Warranty: 1year
• Model: SW900
• Length: 900mm
• Width: 450mm
• Height: 50 to 250mm adjustable
• External Dimension L*W*H: 1200*650

We are dealing best Shrink Wrapping Machine supplying company.

• Application: Packing
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw
• Driven Type: Electric
• Warranty: 1year
• Weight: 100-1000kg

Shrink tunneling machines helps to shrink the shrink wraps wrapped around the products. It uses a heated air system which circulates hot air inside the tunnel, there by shrink wrapping the products. Shrink packaging makes a product more secure and also gives it a highly finished look.

• Country of Origin: India
• Brand Name: Canadian Crystalline
• Voltage: 220-240 V
• Material: Stainless Steel
• Phase: 2 Phase
• Frequency: 50 Hz
• Country of Origin: Made in India
• Capacity: 9000 Bottles per Hour
• Usage/Application: Industrial, Commercial
• Packaging Material: Plastic
• Automation Grade: Semi-Automatic

• Film: max.100microns

Fully automatic sleeve wrapper Ideal for cartons, cans, bottles etc. Supplied along with shrink tunnel Output ; 20 packs/min Film : max.100microns Also supplied with all side sealing. Max.product size:600mm*400mm

Printech Chamber Shrink Wrapping Machine wraps individual products or bundles of all shapes, for product protection and excellent appeal. To operate these machines, the product is manually placed into the chamber. The chamber hood is brought down by the operator. The product which is wrapped with shrink film is applied with a brief current of hot air shrinks the film forcing it to form the product shape. One the cycle is finished the operator retrieves the product and repeats. This machine is efficient as to provide uniform shrinkage at low power cost and widely used for PVC, PE and POF films.

• Material: Mild Steel
• Brand Name: Pioneer
• Frequency: 50 Hz
• Phase: 1 Phase
• Usage/Application: Industrial
• Model Name/Number: Combo 55
• Sealing Area: 420 x 550 mm
• Machine Dimensions: 710 x 1220 x 1350 mm
• Max Product Dimensions: 380 x 500 x 150 mm
• Max Power: 2.6 KW
• Net Weight: 83 Kg
• Max Film Width: 550 mm
• Min Product Length: 25 mm
• Output Speed of Packing: Upto 300/hr

• Brand Name: Taurean Pac
• Material: Stainless Steel
• Air Pressure: 6 Kg.sq.cm
• Power: 230V, 50Hz, 15 Amps
• Automation Grade: Manual, Semi-Automatic
• Sealing Watts: 0.5 K.W X 2 Nos (Side sealing)

• Specialities: High quality heating element, long lifetime and low noise

TY-136 (Servo) & TY-137 (Cylinder) middle speed sleeve sealing machine (not including shrink tunnel) is suitable for products in one tray pack, single carton or some simple collections of large products. Available with transparent PE shrink film (each Top and Bottom film cradle) OR printed PE film (only Top film cradle) Its speed could up to 35 packs per minute depends on the product dimensions. (Please select the suitable shrink tunnel to co-operation with sleeve sealing machine) Features Machine constructions: use S-41 steel materials. Frames formed up by model. Specified spare parts kit. HMI control allows for easy change of machine speed and reciprocation. Safety device for cutting blade: a micro-sensor combined with automatic blade return provide safety protection in cut a hard object. Employs constant temperature one-piece fabricated bronze sealing blade. Draw-out type constant temperature heater combined with SSR constant temperature control features maximum stability of temperature, power saving and easy replacement. The sealing modes including seal type and reciprocating type. Sealing device:heating sealing knife, equipped with picked-up type heating tube & SSR temperature control. Double-rod film holders:fitted with micro-sensing film drive motor Film in roll replaced easily. CE model available. Applications Suitable for products in one tray pack, single carton or some simple collections of large products.

• FILM USED: LDPE
• FILM WIDTH: 580 to 600mm
• FILM THICKNESS: 100 MICRONS
• SEALING SYSTEM: IMPULSE SEALING
• COMPRESSED AIR: 7 BAR
• PRODUCTION CAPACITY: 10 to 12 Shrink wrapping per minute
• POWER SUPPLY: 3PHASE 220V/60HZ
• POWER CONSUMPTION: 20KW

These compact and user-friendly shrink tunnels are used to pack products using PVC/POF/LDPE shrink films. The basic features of the tunnels are variable speed drive to control the speed of the conveyor, high velocity air cutter blowers for Uniform Airflow System, faster heating system, and variable temperature control. Some of the other optional features, which are available, are silicon sleeves for the conveyor rods, fully stainless steel construction, variable speed drive for the blower, in feed and out-feed extension conveyors, Mesh type conveyor, Roller type, Tefllon belt conveyor, etc., A speed of 2-4 packs / Minute. Sleeve Wrapper with Shrink tunnel :These model machines are custom made system for packaging of Products with Shrink Films with all sides sealing. The machine is automatic in process, with automatic conveying of the product, sealing, and heat shrinkage. The product to be packed will be sealed in first wrapping unit, and then advance to second stage where the sides of the pack will be sealed. These units are designed upon the size and quality item and the requirement of the customer. The system is suitable either for Independent use or can be utilized in automated production line. A speed of 4-8 packs / Minute. Sleeve wrapper for 4-side seal : These model machines are custom made system for packaging of products with Thick Shrink Films with all sides sealing. The machine is an automatic machine in process, with automatic coveying of the product, sealing, and heat shrinkage. The product to be packed will be sealed in first wrapping unit, and then advance to second stage where the side of the pack will be sealed. These units are designed upon the size and quality item and the requirement of the customer. The system is suitable for either for Independent use or can be utilized in automated production line. A speed of 2-20 packs / minute.   Automatic Cup Filling Machine is designed to fill and seal plastic cups automatically with speeds of 20 cups/min to 100 cups/min. Various model of machine are there to achieve the above speeds. The machine comes with either a linear conveyor or rotary plate.   The cups are loaded to the cup holders from the cups stack automatically. The cup holder carries to the filling stations where the cups are filled accurately. The filled cups are then provided with seals by a Pick & Place System. After which the sealing of cups are done by the cup sealer. The system is in-built with PLC control and Safety Protection Devices. Shrink Tunnel - Heavy Duty :These machines are rugged ones, which can run continuous for long hours without gap for chamber cooling. These machines are used to wrap heavy products with LOPE/LLOPE shrink film with higher thickness. Live roller rod conveyors are provided in the machines, variable speed drive system for adjusting conveyor speed, fully re-circulating heating air system enable lesser power consumption, highly efficient heat-up with heaters provided on three sides of the chamber, temperature controlled automatically, variable temperature controller, cooling chamber. A speed of 6-20 packs / Minute.

Adhisakthi design and deliver a wide range of custom designed bundling and shrink wrapping machines suiting to various needs of customers. The machine finds it applications in end of line automation and to shrink wrap individual products like container, cartons, shrink labels etc. Machine is used to shrink various types of PVC shrinkable sleeves, poly olefin films, LD films etc. BUNDLERS The machine contains customized product infeed and collating system. Bottom and top film dispensers with auto unwinding mechanism. Sealing with improved PTFE sealers Fully controlled through PLC Pneumatic components of FESTO/SMC Make. Optional SS 304 Construction. SHRINK WRAPPING MACHINE Heating chamber is an insulated construction fitted with suitable heaters. Size of the tunnel would depend upon the requirements. OPTION OF IN FEED CONVEYOR MODELS. 1. Chain Based 2. PTFE Mesh Belt Based. 3. PUC Based Temperature setting up to 300 deg. Controlled with PID Temperature controllers. Conveyor speed is variable with the help of AC variable frequency drive. Uninterrupted running with simple system for heater replacement. Main Conveyor drive with Bonfiglioli geared motors. Options of Single duct, double duct and triple duct available matching to pre shrinking and final shrinking needs.

Green pac –HD  thermal shrink packaging machine is suitable for shrink films such as PVC, POF, etc. The shrink packaged products can be sealed, moisture-proof, cranshproof and applicable for multiple items tied tight and tray packaging. 1. Compact construction, High efficiency2. The use of intra-red Quartz heater tube results in lower the power consumption. 3. Great air-flow provides escellent heat distribution for an even shrink4. Temperature meter control temperature 5. Automatic Temperature Control: The system features automatic temperature     variation for convenient operation 6. Variable speed live-roller(mesh) conveyor is easily adjusted. 7. Any Size

• Material: Stainless Steel, Mild Steel
• Sealing bar: 55X40 cm
• Tunnel passage cm: 40X25 h
• Electric power: 6 kw
• Output: 8-15 packs/minute

We manufacture special high performance Shrink Wrapping Machines, which is made from fine quality components which help the Shrink Wrapping Machines to work for longer durations of time with very easy handling. Specifications Voltage : 220v/380vPower : 10KWSeal-cut time : 0-3 SecondsMax. sealing dimension : (L)450 (W)350mm Max.Packaging dimension : (L)450 (W)350mm (H) 200mm Working efficiency : 500-700 times/h Machine size : L2450 * W700 * H1400mm Machine Weight : 215KGs

 Semi Automatic / Automatic   6 To 9 Packets Per Minute / Inline With The Bottle Filling Machine Output   MOC – MS powder Coated   EB Requirement – 25 KW   Reliable | Low Maintenance
