Stability Chamber Dealers in Chennai

• Power: 230V &110V
• Color: Blue
• Usage: Environmental Purpose
• Certificate: CE, WHO, ISO-9001, ISO-14O01, ISO-13485
• Compressor: DC Compressor

Details: Stability Chamber manufactured by Meditech Technology for safe testing of specimens Touch Screen and PLC based controller Inbuilt USB and Data logger ICH Guideline Q1AR2 Stability testing for Pharmacy, Cosmetics, Tablets, Beverages and Food 21 CFR Part 11 Ready Software Web Based Software (SAIFIN53) – Remote Management 25 years of knowledge, expertise and experience Features of 21 CFR part 11 Stability Chamber : 21 CFR part 11 USFDA compliant software with validation documents. Multi level security password with aging and history. Electronic signature. Secured audit Trail. GSM alarm system for mobile alert. Web based Ethernet and WIFI online remote monitoring. Data of door access security system in software with remote options. All the events, utility, working status, all the alarms are logged in the software. Reports of mean Kinetic Temperature Reading. Records in graphical and in tabular form. Complete with extensive DQ, IQ, OQ and PQ protocols as per the International guidelines along with calibration certificates. Works on 230V AC single phase 50Hz (country specific).

Owing to years of experience, we are involved in providing best quality of Stability Chamber, which are highly appreciated for their highly durable and reliable nature. Stability Chamber is highly demanded amongst our customers due to their optimum uses in various industrial applications.

• Phase: Single
• Voltage: 230VAC
• Humidity Range: 40 to 90 percent
• Frequency: 50Hz
• Capacity: 50 to 1000 Litres
• Temperature: +5 degC to 60 degC

Technico environmental / stability chamber is a doubled walled chamber. The inner chamber is made of 304 stainless steel material with mirror finish. The outer wall is made of mild steel with powder coating finish or alternately stainless steel 304 with or without epoxy powder coating finish for excellent looks. This is a double walled construction, interior made of thick gauge stainless steel sheets of 304 grade and exterior made of cold rolled mild steel sheets finished in powder coat. Inter space in between the walls is packed with glass puff. The door is doubled walled having toughened glass window and seals against atmospheric infiltration by rubber gasket. The inner chamber accommodates stainless steel trays at adjustable height. Heating elements are made of nichrome heating coils evenly distributed at the back side of the chamber. Forced Air circulation fan assembly is incorporated to maintain uniform temperature inside the working chamber. Temperature below ambient is achieved by refrigeration system consists of evaporator coils, compressor, condenser, fan motor and accessories. Humidity is attained by the mist of water that is circulated inside the chamber for maintaining 40 % to 95 % humidity. A water reservoir will be provided with auto law level water cut off device and alarm. Humidity is controlled by a microprocessor based PID humidity controller, with sensitivity of 3 %. Temperature below controlled by microprocessor based PID temperature controller from + 10 to 60 °C with an accuracy of 1 ° C. A compact control panel with switches, indicating lamps, digital PID controllers etc, is located at the side of the chamber for operational convenience. Illumiation is provided with Fluroscent lamps with cyclic timer.   Technical Specification: No. trays : 2 or 3   MOC of Trays : SS 304   Temp. controller : Microprocessor based PID type   RH Controller : Microprocessor based PID type   Power supply : 230 V AC, single phase / 415 V, 3 phase, 50 cys.   Temperature Range : 15 to 60 degs C ± 1 degs C   Humidity Range : 45 % to 95 % ± 3% RH   Temp.range for RH operation : 20 to 60 Degs C only.   Options: Timer, voltage stabilizer, Programmable controller, Recorder, PC interface small & bigger sizes also available based on request.   Standard Chamber size (L ) x ( W) x (H) mm Power Rating kw 455 x 455 x 710 3.0 605 x 605 x 605 4.0 605 x 605 x 910 4.5

• Voltage: 380 V
• Usage/Application: Commercial
• Temperature Range: 20 to 60 Degree C
• Humidity Range: 95% RH
• Phase: 2
• Frequency: 50 Hz
• Material: Stainless steel
• Capacity: 15000 Litre
• Power Source: Electric
