Check Valves Dealers in Chennai

• Disc Centering Top Cover: Top and bottom covers are designed to seal the body at both ends and to provide disc centering adjustment along the shaft axis.
• Top Flange: All Butterfly Valves are Equipped with Iso Top Flanges for all Types of Actuator Operator Connection
• Shaft Connection: Positive disc to shaft connection by use of key.
• Lifting Holes and Feet: Integral lifting holes provide easy installation and feet ensure strong ground support.
• Shafts: Stub shaft design provides minimal restriction to flow.
• Shaft Sealing: Multiple O-ring shaft sealing system ensures maintenance free sealing for the entire life span

This type of valve, that is, double flanged butterfly valve, is mainly brought to use to regulate the flow sectioning in the supply of water. Butterfly valves mainly process a low head loss as a result of the disc's hydrodynamic design. Butterfly valves are further subdivided into several other parts that have various utilities. FMC is one of the most well-known valve manufacturing companies in Chennai of all time. We ensure high-quality goods and our professionals look into the manufacturing processes with much efficiency. Our versatility is the reason behind our success. Our variation of services includes manufacturing double flanged butterfly valves, ball valves, resilient seat butterfly valves, and a lot more. Apart from that, our technical team also takes special care of the problems of our clients. All our products are well designed and perfectly suited for different industries such as food Industries, Paper Mills, etc.

• Size: 40mm and Above
• Material: Cast Iron
• End Connection: Flanged
• Model Name/Number: Swing Type Check Valve
• Brand: Kirloskar
• Grade: FG 260
• Surface Finish: Smooth
• I Deal In: New Only
• Connection Type: Flange End
• Nominal Pressure: PN10 and PN 16
• Size Range: 40 to 1500 mm
• Pressure Ratings: PN10, PN16
• Media: Water, Gas, Fuel

• Size: 2-10 Inch
• Brand Name: Teleflo
• Material: WCB, CS, CF8, CF3,Brass, Ni Al Brz
• Finishing: Polished
• Type: Double Orifice
• Country of Origin: India
• Connection: Flanged
• Float: SS 304, SS 316, Copper

Double orifice air valve that combines both large orifice & small orifice functions within one unit. The large orifice allows air to be expelled from the system during filling of a pipeline and admit air back into the system whenever sub-atmospheric pressure occurs. Air is vented from the system until water enters the valve and lifts the float against its seat, ensuring a tight seal. In the event of sub-atmospheric pressure in the system, the water level drops causing the float to fall from its seat and allow the admission of air During normal working of the main the small orifice releases the air which accumulates under pressure. With the main in operation, the float is normally against its seat. As air enters the chamber body the water level is depressed until a level is reached when the float drops from its seat, which allows air to escape. The consequent rise in water level returns the float to its seat 40mm (1 1/2”) - 200mm (8”) sizes. GENERAL USE : 1. Disposal of large volumes of air during fill of the pipes of system. 2. Add great amount of air to the system during the purge of the pipes. 3. Release of pressurized air pockets during operation SERVICE CONDITIONS: 1. Potable water, filtered water, Sea water. 2. Working pressures 0.2 bar up to 20 bar. 3. Temperature range 0°C to +90°C. STANDARDS 1. Pressure test according to standard IS.14845.2000, EN 12266-1 2. Flange connection ANSI, DIN, AWWA.

Trustworthy shipping facilities, competent workforce and prompt delivery of the products make us stand out in the industry. With the assistance of our capacious warehouse, we are able to meet the bulk as well as urgent requirements of the buyers. Our unit is supervised by the experts ensuring complete safety of the lot. Features : High productivity Hassle free operations Rugged construction

• Type: Rectangular / Square / Round
• Design Features: Own Design available (or) Client Requirement
• Flanges standard: As per customer requirementv
• Available size: 100mm to 3000mm
• Body: MS IS 2062 / Stainless Steel AISI 304 / 316 / 310
• Liners: Hardox400, Hardox500, Sailhard
• Gate: MS IS 2062 / Stainless Steel AISI 304 / 316 / 310
• Gland: MS IS 2062 / Stainless Steel AISI 304 / 316 / 310
• Shaft: EN 8 / SS AISI 410 / 304 / 316

We offer premium quality Various type Flap Valve that are made from raw material and is known for their strength and long functional life. They are made using the advanced technology which makes them highly useful in the various industries.Mode of Operation Counter weight Gear Motor Pneumatic cylinder Hydraulic Cylinder

• Material: Stainless Steel, Cast Iron, Carbon Steel
• Color: Grey
• Automatic Grade: Manual
• Actuation Type: Double Acting
• Usage: Water Fitting
• Packaging Type: Carton
• Valve Size: As Per Customer Requirements
• Type: Industrial Valves
• Country of Origin: India
