VRV-100 Vaccum Relief Valve
Get Price Quote
1 Piece (MOQ)
Pressure / vacuum relief valves or breather valves are special types of relief valves which are specifically designed for tank protection. The range includes pressure only, vacuum only and combined pressure / vacuum valves, all available with flanged outlets or vented to atmosphere Pressure / vacuum relief valves are used extensively on bulk storage tanks, including fixed roof tanks with floating covers, to minimize evaporation loss. The valves prevent the buildup of excessive pressure or vacuum which can unbalance the system or damage the storage vessel.The range includes pressure only, vacuum only and combined Pressure/Vacuum Valves, all available with flanged outlets or vented to atmosphere. Pressure/Vacuum Relief Valves are used extensively on bulk storage tanks, including fixed roof tanks with floating covers, to minimize evaporation loss. Pressure/vacuum relief valves prevent emission losses until very close to the set pressure, and prevents air intake until very close to the set vacuum. The geometry of the valves has been developed in order to optimize overall performance in terms of high flow capacity, set pressure, sealing and re-sealing.The Vacuum Relief Valve is an advanced design for vent to atmosphere applications. Utilizing the latest technologies, this relief valve provides protection against negative or positive pressure, prevents air intake, evaporative loss of product and helps contain odorous and potentially hazardous vapors.The Vacuum relief valve is designed to be installed on pressurized tanks static or transportation application. The vacuum relief valves prevent the unallowable entrance of air up to the adjusted set pressure and offer reliable protection against vacuum.OperationTeleflo makes vacuum relief valves (VRV) in various metallic materials, with a wide variety of elastomeric seat seals. There are several sizes available, as well as pressure settings. The purchaser must exercise care to select the most desirable combination of features for the intended service conditions.Since the VRVs are frequently small in size, and are set at very low pressures, these valves cannot withstand much abuse. Although the valve’s sole purpose is to permit air from the atmosphere to be introduced into the tank when a negative pressure (of a prescribed amount) occurs in the tank, it has been used wrongly on occasions to ascertain if positive pressure exists in the tank. As an example, an operator may push the stem down by stepping on it to see if there is pressure in the tank before opening up the man way cover. A likely result of this is to damage the valve by bending the stem, as well as releasing product that could harm the operator.We would supply weather cover for VRV additionally if client requested. This part helps keep rain, cinders and other debris from accumulating in the inside of the valve body, which when the valve opens, will then potentially drop into the tank. A weather cover also serves as a deflector when there is flow out of the VRV to protect personnel near the valve. the threads to facilitate getting a good pressure-tight seal.Do not use a large pipe wrench to install the threaded valve. Care should be taken not to distort the valve body’s internal seat.Remove the fasteners using suitable tools. Note: All work on the valve should be performed by a skilled mechanic with proper tools.MaintenanceThe seal that makes the VRV bubble tight is the resilient seal. Do not try to lap the metal to metal seats between the stem and valve body.The metallic seats on the stem and the valve body are carefully machined at an angle. Do not attempt to reaching them. However, removing rust, solidified product, and other debris by hand, or with emery paper is desirable.The resilient seal of valves are almost always round shaped pressure seals. Replacement pressure seals of whatever material is required should be purchased only from Teleflo.VALVE TESTING PROCEDUREMount the valve on the test stand using proper tools with skilled person.Test the vacuum test three times to verify proper operation. Record all test vacuum readings on the Shop Data Sheet.With the valve mounted on the test stand, slowly increase the vacuum pressure while monitoring the air supply pressure flow rate. For vacuum tests, the block valve is opened sufficiently to allow a steady increase in vacuum condition. To adjust the adjustment screw as the setting is approached, continue to open the valve.The set (vacuum) will be the point at which the test pressure (vacuum) does not increase with a corresponding increase in flow rate. Normally, at this point, the test pressure (vacuum) will fluctuate up and down as the valve relieves, while the flow rate remains steady. The set vacuum is the maximum vacuum achieved during the test.Repeat this test two more times to achieve a total of three measurements of set pressure and vacuum.The acceptable tolerance range for set (vacuum) is +/- 10%. All three test results must fall within the specified tolerances for the vacuum settings listed on the sales order. Record the three set vacuum measurements on the Shop Data Sheet
Pressure Relief Valves
7,400 Per Piece
1 Piece (MOQ)
Best Deals from Gate Valves
vacuum relief valves
9,000 Per Piece
Boiler Safety Valves
Get Price Quote
Pressure Relief Valve
Get Price Quote
We are the manufacturer, supplier and exporter of Pressure Reducing Valves from Chennai-India to Globally that are manufactured from high grade CS, SS and CI as per the client̢۪s requirement. These pressure reducing valves can be operated without any need of external air supply. We are majorly looking inquiries from Dubai, Abu Dhabi, Sharjah, UAE, Kuwait, Oman, Qatar, Egypt, Thailand, Indonesia, Singapore, Malaysia, Myanmar, Vietnam, Brunei, Australlia, Europe, Italy, Belgium.
Pressure Reducing Valve
Get Price Quote
Theses valves are used for the purpose of reducing the downstream pressure and are used for steam, oil, air and other gases Flanges drilled according to BS 10 Table H or J. Can be supplied with other flanges against order. Can be supplied IBR Certificate in Form III-C.
Single Drop Gate Valve
Get Price Quote
Single valve gate nozzle has the drive unit integrated into the nozzle housing. Since there are no external drive components this nozzle is the ideal solution for single applications and stack moulds with symmetrical cavity layout. Â Maintenance is very easy as pins, pistons, and seals are accessible without having to split the platesSimple maintenance tools included with Valve Gate systemsIntegrated valve pin drive unitNo thermal valve pin loadSDVG nozzles are available in DTSV12 to DTSV34 sizes.The valves gate is operated pneumatically
Unloading Valve
4,000 Per Piece
Stainless Steel Relief Valves
7,500 Per Piece
Safety Valves
Get Price Quote
Strainers
Safety Relief Valve
Get Price Quote
We are offering safety relief valve a valve which relieves pressure beyond a specified limit and recloses upon return to normal operating conditions. A pressure-control valve in any fluid system, which limits the pressure in the system by releasing it at a preset value. The pressure is not allowed to be built up above this preset figure. self actuated pressure control valves without any need of external power or air supply. Body cs/ss/ci and the internal should be in ss grade. sizes: 1/2" ,3/4" , 1" , 1 1/2" , 2" screwed type, 1", 1 1/2", 2", 3", 4" flanged type with ptfe, neo-prene, phosphor bronze.
Safety Valve
Get Price Quote
stainers, sight flow indicator valves
Gate Valves
Get Price Quote
Ball Valves
Knife Edge Gate Valve
Get Price Quote
Ball Valve, Foot Valve
Safety Valve
Get Price Quote
breather, Thermowells, Strainer, Orifice Plates, Industrial Products
TYCO Post Indicator Gate Valve UL Listed / FM Approved
Get Price Quote
TYCO Post Indicator Gate Valve UL Listed / FM Approved
Gate Valves
Get Price Quote
Valve Seat Rings
Pressure Reducing Valves
Get Price Quote
Pressure Reducing Valves, Y Type Strainers, duplex type strainers
High Pressure Needle Valve
Get Price Quote
High Pressure Needle Valve, Ball Valve, Multiport Ball Valve
pressure valve
Get Price Quote
Gearboxes, site evaluation, Application Management
