FLUID PUMPS AND EQUIPMENT INDIA PRIVATE LIMITED Pattanam, Coimbatore, Tamil Nadu

MV / HV NOZZLES - FLUID UL listed; Model 212 & 213 Medium velocity & model 230 High velocity nozzles are used for Deluge spray system.  MV Nozzles produces Cone shaped spray pattern & HV Nozzles provide solid full cone pattern with uniform droplet distribution. FLUID UL listed; Model F226 Foam nozzles produces & distribute foam when foam-water solution discharge thru them. Foam nozzles comes with SS 316 screen as standard. Available with various K-factors & Spray angles.  MOC - Brass & SS316

Country of Origin : INDIA

Type : Water Spray Nozzle,MV HV FOAM

Diameter : 1/2", 3/4", 1" END CONNECTIONS

Application : Industrial Use,FIRE FIGHTING

Color : NATURAL BRASS, SS, PLATED

Condition : New

Pressure : 12 BAR

FLUID GROOVED FITTINGS / PIPE SUPPORTS - FLUID UL listed; Grooved pipe fittings are one of the mpst advance pipe connection systems of the day.  MOC - Ductile Iron ASTM A536 with working pressure to 750PSI.  RED Painted.  GROOVED End fittings are UL as well as FM approved. FLUID UL listed; Pipe supports are used in Fire protection system as sprinkler pipe hanger & U bolts.

Country of Origin : INDIA

Type : Grooved Pipe Fitting

Material : DUCTILE IRON ASTM A 536

Shape : GROOVED

Thickness : DIFFERENT SIZES

Application : Pipe Fittings

Grade : ASTM

Color : RED

Feature : Excellent Quality,Fine Finishing,High Strength,Perfect Shape

Condition : New

Finishing : RED PAINTED FINISH

UL LISTED GATE VALVE. Outside Screw & Yoke Rising Stem - Metal Seat, Resilient Seat. Specifications: Comply to BS 5163 Standard. Working pressure: 250 PSI. Cold water pressure (Max.temp 63ºC). Epoxy painted inside & outside as standard, Fusion bonded Epoxy available as optional. Connection: Flanged Ends to ANSI B16.1 Class 125. Other flange types available. Tamper switch notch available for tamper switch mounting. UL LISTED PRESSURE RELIEF VALVE - FLUID Model 513 Pressure Relief Control Valve is a direct-acting, spring loaded, diaphragm type relief valve. Model 513 is available with Brass construction as standard & model 513A is available with stainless steel construction. The PRV is intended to use in fire systems where maintaining pressure limit is critical for smooth operation to open & shut within close differential pressure limits. Available in Globe & Angle type configuration and suitable for vertical & horizontal installation. PRV set pressure is field adjustable with a range from 20psi to 150psi for LP model & 150psi to 300psi for HP model. Pressure gauge port (¼”) is provided for accurate pressure setting.

Country of Origin : India

Type : Gate Valves

Brand Name : FLUID

Material : Stainless Steel

Certification : ISO 9001:2008 Certified

Application : Water Fitting

Color : Red

Temperature Pressure : 80 DEG

Number Of Way : 2way

Packaging Size : 5 Pieces

Condition : New

Finishing : Coated

Corrosion Resistance : No

Mounting Type : Vertical

Warranty : 1 Year

Driving Mode : HANDLE OPERATED

Media : Water

Actuation Type : MANUAL

Automatic Grade : Manual

Diametre (milimetre) : 50-300 NB

Valve Size : 2"-12"

Structure : OS&Y

Specialities : Durable,

Packaging Type : Carton

Voltage Range : NA

Weight : 5Kg,

Diameter (mm) : 50mm

Operating Temperature : 5 TO 80 DEG

Working Pressure : 250 PSI

Current Leakage : ZERO

End Connection : FLANGED

Deluge Valves UL Listed - EX26775 (DN40 - DN250) Operation Deluge Valves Model FX-E/EM Electrically Actuated Deluge Valve Auto Reset/Manual Reset Model FX-H/HM Hydraulically Actuated Deluge Valve Pilot Controlled Auto Reset/Manual Reset Model FX-P/PM Pneumatically Actuated Deluge Valve Auto Reset/Manual Reset Model FX-PE/PEM Electrically and Pneumatically Actuated Deluge Valve Pre-action double interlock System Model FX-HR/ER Flow Regulating Deluge Valve Constant lower preset, downstream pressure.   Deluge & Dry Pipe Systems Foam Systems Single or double Interlock Pre-Action Fresh Water, Sea water, Foam solution or Foam concentrate Offshore platforms and helidecks Ni Al Br body deluge valve available for corrosive environments Remote controlled valves   N.M.M.P. - No Mechanical Moving Parts with Self supporting diaphragm Simple structure - valve is maintenance free Automatic reset - optional manual reset Copper trim tubing and brass fittings optional Maximum working pressure up to 250 psi (17.25 bar) Factory assembled trim package Compatible with hydraulic, electric and pneumatic release Electrical trim with 2-way Solenoid Valve Optional Items: Pressure Switch, Water motor alarm gong External manual reset, without opening the valve Can be used in vertical or horizontal position

Country of Origin : India

Size : 2"-10"

Type : Deluge Valve

Material : Cast Steel,Ductile Iron,Stainless Steel,NI-AL BRONZE

Certification : Iso 9001:2008 Certified

Application : Water Fitting,FIRE FIGHTING

Color : RED

Feature : Good Quality,NON MATERIAL MOVING PART

Condition : New

Pressure : 250 PSI

End Connection : Flanged,GROOVED OPTION

FLUID Deluge skids are pre-assembled packaged unit with Main control valve, actuation trim set, system accessories etc. Deluge skid comes with advance grooved pipe connections providing compact assembly, fast dismantling, assembly of skid components during maintenance.  Quick replacement of components is possible without use of special tool/manpower.  In house design, manufacturing, fabrication and assembled with stringent QA/QC standards.

Country of Origin : India

Size : 2"-10:"

Type : Deluge Valve

Material : Cast Steel,Ductile Iron,Stainless Steel,NI-AL BRONZE

Certification : Iso 9001:2008 Certified

Application : fire fighting

Color : RED

Feature : Durable,Good Quality

Condition : New

Pressure : Medium

End Connection : Flanged

Feature : DIAPHRAGM OPERATED
