Oil Cooled Voltage Stabilizer Dealers in Coimbatore

• Type: Oil Cooled Voltage Stabilizer
• Brand Name: Servo
• Certification: ISO 9001:2008
• Color: White
• Voltage: 220V
• Condition: New
• Output Type: AC Single Phase
• Frequency: 50hz
• Automatic Grade: Automatic
• Feature: Stable Performance
• Cooling System: Oil Cooled
• Power Capacity: 15-20kw
• Warrenty: 2years
• Application: Prevent From Voltage Fluctuations
• Phase: 1
• Name: Single Phase Oil Cooled Servo Stabilize

We are offering 3 phase oil cooled servo stabiliser. Stabilizer is the automatic voltage regulator. It regulates the output power. It produces the output 230 v ± 1% (variable 5%) or 415 ± 1% (variable 5%) or as per customer demand for your appliance.

Servocom Features:  97 to 98.5% efficiency (Achieved by use of hi-quality core and copper Transformers)   Speed of correction up to 60v/sec    Immune to load power factor and frequency variations    Very high reliability, easy and simple maintenance    Life expectancy 20-25 years   System conforms to IS 9815-1994    Transformer oil: IS 335,IEC 296

• Output Voltage: 400 V 1% (Adjustable)
• Output Voltage: 400 V 1% (Adjustable)
• Capacity: 3 KVA to 1000 KVA
• Operating Frequency: 47 - 53Hz
• Parameter: Three Phase
• Capacity: 3 KVA to 1000 KVA
• Operating Frequency: 47 - 53Hz
• Input Voltage Range: Range I :340 - 465V
• Range II :295 - 465V: Range III :240 -465V
• Output Volts Regulation: 1%
• Type of Cooling: Oil Cooled
• Working Temperature: 0 to 50° C
• Insulation: Class “B”
• Output Wave: Form True Reproduction of Input
• Wave Form Distortion: Nil
• Efficiency: 98% at Nominal Load
• Correction Rate: 25/35/60 V per second
• Relative Humidity: 60%
• Effect of Load Power Factor: Nil
• Environment: Indoor &out door

• Automation Grade: Automatic
• Input Voltage: 300 V - 460 VAC
• Output Voltage: 440 V
• Material: SS
• Frequency: 50/60 Hz
• Display: Digital
• Phase: Three Phase
• Operating Temperature: 0 to 45 deg C
• Brand: Sakthi Electrical Control

We manufacture and supply oil cooled servo stabilizer that are very effective in controlling power and voltage. Our oil cooled servo stabilizers are designed and supervised by a team of qualified engineers to give the best output. These stabilizers work well under high voltage fluctuations and helps in obtaining single output. features and specifications:- range 300 v – 460 v ac 50 hz 3 ph other input ranges 245 v- 460 v ac 3ph 340 v- 460 v ac 3ph 360 v- 460 v ac 3ph other ranges as per customer requirement 47hz to 53 hz output voltage 380 v 400 v 415 v ac 3ph 50 hz system unbalanced 4 wire : r y b n connections star output voltage adjustable 380 v to 415 v ac in 3ph 220 v to 240 v ac in 1ph output voltage regulation ± 1% over load capacity 120.00% correction rate 15 v 20 v 35 v sec-1ph 25 v 35 v 60 v sec-3ph 110vsec for d.c. Motor controlled waveform distortion nil output waveform true reproduction of input insulation class 'b' short ckt period & percentage 300 % for 250 m. Sec. Normal operating temperature 0ºc to 45ºc climatic conditions 90 % rh. Max. Non-condensing at 35º c mode of system fully automatic manual system construction as per is : 9815 of 1994

We are offering three phase oil cooled servo stabiliser which comprise highly functional voltage stabilizers that are designed using latest technology support so as to provide for optimum functional usage. These voltage stabilizers find extensive usage in controlling voltage fluctuations using solid state electronic circuitry. Being oil cooled stabilizers, these function as automatic line voltage correctors that use synchronous motor that provides for optimum functional usage.
