Reduction Gear Boxes Dealers in Coimbatore

• Type: Worm
• Power: Power Capacity- 139 kw
• Material: Cast Iron
• Orientation: Horizontal, Vertical
• Mounting: Universal
• Application: Conveyors, Cane Shredders, Extruder Drive, Slurry Pump Etc
• Output: Output Ratio- Min. 5 Ratio 1 to Max 70 Ratio 1

We are offering worm reduction gear box. Conveyor gearbox

With vast industrial experience, we have made ourselves emerged in offering a wide range of Reduction Gearbox. Offered product range is manufactured by using high grade material which makes it long lasting and durable. This Reduction Gearbox is delivered to client within safe packaging in given time frame.

ESSARR TRANSMISSION ‘FU’ & ‘FV’ series worm gear reducers is its well known quality and reliability and its ability in meeting the needs of industries worldwide. This is achieved by the most effective combination of the very best engineering design, highest quality material and excellence in manufacturing. ESSARR worm gear reducers bore testimony to our commitment for excellence and boost of such inherent features. Compact High efficiency High thermal capacity Strength and resistance to shock Long life Unrivalled economy High torque capacity Smooth operation without trouble Our worm gears generally conform to BS 721 / 1963 for worm gearing and accuracy to class “A” limits of those specifications. Standard output shafts are of carbon steel, En9 carefully selected to take the desire torsional stresses and bending load which may be induced by over hung drives.  High tensile steel shaft or double extended shaft for specialized application are also available on request.Toleranc eon input & output shaft extension dia conforming to DI N 7160 & key, keyway conforming to DI N 6885.

The worm is of high quality casehardening steel very accurately generated and ground finished for the better performance. The worm wheel is of extremely high quality phosphor bronze spin cast with a considerably substantial section, rigidly held to a strong hub with eutectic welding technology Sandwich Casting.

Adaptable Worm Reduction gear Boxes upto 3 ⅜ (85.7mm)CD. In single & Double Reduction models Types : Under Driven Over Driven Vertical Input or Output Shaft Version Shaft Mounted Version All types with motor mounting adaptor motor – optional
