ABB MCB Dealers in Delhi

We are offering miniature circuit breakers - mcb. please contact for quality product.

BCH MCB is high-performance device, able to disconnect Short circuit currents upto 10KA and conforms to Standards: IS/IEC 60898-1.   The MCB meets the requirement across all sectors namely Commercial, Industrial , Residential & Agriculture.

• Type: Electrical
• Brand Name: SCHNEIDER / SIEMENS / ABB / L&T
• Color: White
• Frequency: 50/60 Hz
• Voltage: 415 V AC
• Breaking Capacity: 10KA
• Poles Number: 1Pole, 2Pole, 3Pole, 4Pole
• Voltage Capacity: 240/415 V AC
• Terminal Capacity: 20 sq. mm
• Operating temp: -50C to +550C

We have a wide range of circuit breaker equipment, both MCB and MCCB. The range of MCB boards are highly durable and allow the installer maximum flexibility. There is a huge number of variations with Current ratings from 6 Amps to 40 Amps. Different series including High rupture capacity, Single to four Pole. High breaking capacity: 20 - 15 - 10 - 6 K A Nominal rated currents from 0.5 to 63 A Wide range of the executions for both the MCBs and the accessories combined main contacts.

The circuit breaker must detect a fault condition; in low voltage circuit breakers this is usually done within the breaker enclosure. Once a fault is detected, contacts within the circuit breaker must open to interrupt the circuit; some mechanically stored energy (using something such as springs or compressed air) contained within the breaker is used to separate the contacts, although some of the energy required may be obtained from the fault current itself. Small circuit breakers may be manually operated; larger units have solenoids to trip the mechanism, and electric motors to restore energy to the springs. At Adhunik basics of the all the devices are very strong and unique. Body is made of “Polybutaline terapythalate Polyesterpolymer chip ”which has highly desirable thermal & electrical properties such as fire get extinguished when it moves from one molecule to another in such kind of material. “Action is look like of Fire proof materials” Making Breaking Fixed and Moving Contact- Moving- Brass plate inlayed by Pure Silver Making room for electrons to flow in a large area with minimum resilience. Fixed contact specially designed to make sure that there is no air gap between the two contacts even after large no of operations, Make brake is perfect ,No secondary Arc can develop - “Action is a weld Free mechanism” A common problem with many other designs Arc chute Tri coating (once with Zinc twice with Nickel Gold) on Arc splinters creates a suction effect quenching arc much faster than other MCBs -“Action is a Safe MCB”.

Our company is a renowned Manufacturer and Supplier of Miniature Circuit Breakers. The Miniature Circuit Breakers are manufactured using graded raw materials. The Miniature Circuit Breakers work automatically and switch off the power during abnormal or faulty conditions in the electrical circuit. Our Miniature Circuit Breakers are strong, sturdy, and durable and offer efficient performance. We supply Miniature Circuit Breakers in various parts of the country at affordable prices. Highlights : Used in low voltage electrical networkAutomatic functioningEfficient performanceDurableCompetitive price Minimum Order Quantity : 500 pieces

Newtech MCB's are among the best available designed with proven, trusted and reliable German Technology to provide enhanced operating safety, Installations for domestic, commercial and industrial applications. Some of the salient features of these MCB's are as below. Miniature Circuit Breakers are housed in injection moulded flame retardant, high strength thermo plastic material having high melting point, high dielectric strength and temperature with stand. Trip free Mechanism i.e. the breaker trips internally even if the operating knob is held in ON position. The Tripping Mechanism is thermal magnetic type : » Finger Protection MCB's are finger protected to IP 20 as per IS : 8828 : 1996 the live current carrying parts cannot be touched accidentially. » Magnetic Protection When overload values exceed the value specified for different characteristic curves i.e. B & C strong Magnetic field is induced which results into instantaneous tripping of MCB. » Effective Quenching Arc produced of contacts is rapidly pushed Magnetically into a 12 plates arc chamber where it is broken down effectively & cooled. » Trip Free Mechanism Trip free Mechanism ensure tripping of MCB even if the knob is kept in 'ON' position. » Special Silver Alloy Contacts The contacts are made out of special silver alloy inlaid strips which gives low contact resistance resulting in low voltage drop & hence very low power consumption and temperature rise. These contacts have very excellent anti weld properties.

• Brand Name: Allwin Electric
• Current Rating: 63 A
• Poles Number: 1 Pole, 1pole+N
• Classification: Type B
• Reference Standard: IS/IEC 60898-1:2008
• Capacity: 10 kA
• Series: AX (Center Knob), LX (Top Knob)
• Construction and Features: Trip free mechanism. High speed and high breaking capacity mechanism. High speed wiping contact structure. Environment-Friendly.

• Type: Miniature Circuit Breaker
• Material: Ceramic
• Color: Creamy
• Condition: New
• Feature: Best Quality, Durable, Easy To Fir, High Performance, Stable Performance, Use Friendly
• Warranty: 1year
• Current Type: AC
•  Connection Type: 4way

• Features: Longer service life , Positive isolation , Ergonomic design

• Configurations: 1P, 1P+N, 2P, 3P, 3P+N, 4P
• Breaking capacities: up to 25 kA
• Rated currents: up to 63A

• Voltage: 230/400AC
• Frequency: 50-60 Hz
• No.Of Poles: 1P, 2P, 3P, 4P
• Rated Current: 0.5-63A
• Usage/Application: Industrial
• Phase: Three

he circuit breaker must detect a fault condition; in low voltage circuit breakers this is usually done within the breaker enclosure. Once a fault is detected, contacts within the circuit breaker must open to interrupt the circuit; some mechanically stored energy (using something such as springs or compressed air) contained within the breaker is used to separate the contacts, although some of the energy required may be obtained from the fault current itself.
