Decorative Ceiling Dealers in Delhi

84 R ceiling system comprises of 84 mm x 16 mm panels without flush profile (for 100 mm module only) roll formed out of metal coils. Panels are fixed on to roll formed carriers 32 mm wide x 39 mm deep made out of 0.90.7 mm Aluminium or 0.5 mm galvanised steel sheet with cutouts to hold the panels in module of 100 mm at maximum 1.7 m cc without insulation and at maximum 1.5 m cc with insulation. Carriers are suspended from the roof or truss by 4 mm dia. galvanized steel wire rod hanger with special height adjustment suspension clip at max. 1.3 m cc. Hangers are fixed to the roof by ceiling bracket. Panels are available in max. Lengths up to maximum 6 m to suit site dimensions.. Edge profiles or wall angles are 24 mm X 24 mm X 0.5 mm thick and match the colour of the panel. Flush profile can be use in between 2 panels to fill gap of 16mm.
