Horizontal Rectangular Autoclave Dealers in Delhi

Horizontal rectangular autoclave is a triple walled chamber consist of the safety valve, pressure gauge as well as steam release valve also provides for an optimum functional interface. The autoclave is placed over a tubular stand to provide optimum functional stability.

• Weight: 100-200kg
• Color: Silver
• Voltage: 220V
• Condition: New
• Driven Type: Electric
• Warranty: 1year

• Brand Name: REW
• Driven Type: Electric, Hydraulic
• Color: Stainless Steel
• Condition: New
• Automatic Grade: Automatic, Fully Automatic, Semi Automatic
• Power: 9-12kw, 27 Kw
• Application: Hospital, Laboratory, Pharma Industry
• Certification: CE Certified, ISO 9001:2008
• Voltage: 440V
• Capacity: 100 Liter To 3000 Liter
• Type: Horizontal Rectangular Autoclave
• Weight: 400-500kg
• Warranty: 1year
• Country of Origin: India

• Model: ALABS-A100-002
• Categories: Sterilization Equipment
• WORKING CHAMBER (W x H x D): 600x600x1200mm, 600x900x1500mm
• Material: Stainless steel

We manufacture Horizontal Autoclave (Rectangular) and cylindrical horizontal autoclave systems, Laboratory autoclave, autoclave / sterilizer , autoclaves , vertical autoclave , sterilizer , horizontal autoclave , cylindrical autoclave , medical autoclave , laboratory autoclave plasma sterilizers, dry heat sterilizer and dental class B ISO 13485 : 2009 autoclave , high pressure autoclave, front loading autoclave etc. Laboratory Autoclave pre-engineered ISO / GMP/ CE standard models, we are manufacture autoclaves with provided specifications as per customer requirement with a choice of optional accessories that must be used to add flexibility. which can be further customized in order to match specific requirements of our customers. The scope of customization includes construction material, inner tank volume, valves and printer options. These units can also be constructed with vacuum drying option; for this purpose a provision of vacuum (through vacuum pump) dry cycle , pre vacuuming cycle in the chamber is applied. Our each horizontal autoclave unit provides highly satisfactory performance and competitive price guarantee. The middle wall is additionally created from the stong and durable untarnished stell sheet of ss-304 grade chrome steel sheet. These square measure steam stocking models connected with a 3 manner valve to regulate the sterilization cycle within the autoclave. Generous mineral glass as wool is additionally been insulated to form it tolerable enough instrumentality among the users. The Steam generator of the autoclave is additionally created from chrome steel sheet of grade ss-304. Our horizontal autoclaves area unit ideally ideally fitted to hospitals and analysis labs wherever safety is that the firest priority of the users, since. it's equipped with a double safety reease valve. To give it the same and international lcok we have a tendency to in the main emphasize on its technical options and this includes. advanced radial lock lockup machanism for final simple operation and safety steam, Realease valve of stainless-steel making certain an extended a lifetime of the instrumentality, Huger grade spring loaded relief valve of brass, punctually chrome plated, Water Indication Gauge with stainless-steel enclosure, High accuracy and reliable pressure gage, Multiple in operation valve for the management of the sterilization cycle, Accedental Vacuum Break Device: making certain vacuum break attributable to equipment failure or the other usage, Water Level bring to a halt Device, CUT Hammer Contractor for long hassle free usage, Specially designed international intelligence agency marked stailess steel heaters, Plug screen to stop line Choking attributable to sediment discharge and extremely correct temperature and pressure gauges for boiler chamver and jacket.

• Working Temperature: 121°C (up graded up to 135°C)
• Sterilization Period: 20 to 25 Minutes
• Working Temperature: 121°C (up graded up to 135°C)

Horizontal Autoclaves, manufactured by Bionics Scientific are smart investment for hospitals and laboratories, where large volume of sterilization is required. Designed ergonomically, our range of high pressure horizontal autoclave sterilizers is ideal for academic facilities, biotech industries, pharmaceutical industries, hospitals, research centers and food and beverage industries. These units efficiently meet stringent sterilization requirements and well suited for sterilizing hospital dressings and surgical instruments, rubber and plastic goods, glassware and utensils etc. We manufacture both rectangular and cylindrical horizontal autoclave systems, which can be further customized in order to match specific requirements of our customers. The scope of customization includes construction material, inner tank volume, valves and printer options. These units can also be constructed with vacuum drying option; for this purpose a provision of vacuum (through vacuum pump) in the chamber is applied. Our each horizontal autoclave unit provides highly satisfactory performance and competitive price guarantee.

• Working Size(L X H X D)_: 450 X 450 X 900 mm (18" x 18" x 36")

Inner chamber jacket & boiler is made of stainless steel. Lid is made of mild steel lined with S.S. Duly polishedFully S.S.304. Outer Body is made of Mild steel S.S. 304 Sterilization cycle is controlled by three way valve or multi-port valve Fitted with automatic pressure control switch, safety valve, vacuum breaker valve, water level indicator indfoss piezostat with cord and plug. Vacuum breaker to break vacuum in case of formation of vacuum due to steam condensation. Two separate valves are provided with for evacuating steam from inner chamber and jacket as and when desired. To work on 440 volts, 3 phase supply .

• Brand Name: APS

We offer Horizontal Rectangular Autoclave - (Triple walled with steam jacket and separate Boiler). The Autoclave is mounted on a M.S. tubular stand. This Autoclave’s Inner & Outer chamber & steam jacket are made of S.S. 304. Steam jacket allows Dry sterilization. Hinged door is made of Stainless steel. Radial locking arms prevent opening of the door while steam is inside the chamber. Gasket is of synthetic neoprene, Steam is generated in a separate boiler which is placed below the Main body. The steam generator is fitted with easily replaceable Heaters and water level indicator. Autoclave hold pressure at selected Point between 10 to 20 psi +- 3 psi pressure control switch has Markings which are approximate, correct pressure is as shown by the pressure gauge Hydraulically tested at 40psi. Fitted with safety Valves, pressure gauge. Hydraulically tested at 40psi. Fitted With safety valves, pressure gauges, air filter, steam release valve, Stream trap, and one tray. 1Kg. Cm2 = 14.7 psi. • Available in following capacities Size Litter Capacity Load • 450mmX600mmX900mm 240 Litters 18 kw • 600mmX600mmX1200mm 435 Litters 24 kw • 600mmX900mmX1500mm 810 Litters 36 kw

The Pressure on the Industries,Hospitals Pharma & Chemical Industries to properly manage the quality of life and developing sustainable fitness by generating vaccines and Inoculation . Secondly In today’s world, Hospital, Medical & Industrial waste Management is a big responsibility as well . Bio Gene makes conscious efforts and produced dedicated sterilizer autoclaves for complete sterile vaccine and Inoculation of medical, Hospital waste Sterilization under strict guidelines, Bio Gene Sliding Double Door Autoclaves are thus an eminent choice in development of vaccines approved by world Health Organisations and central Pollution Board.

JINDAL Fully Automatic Microprocessor based high pressure, high vacuum autoclave is designed to fulfill the needs of CS.S.D. unit & various other microbiology works. The sterilizer is designed for sterilizing hospital materials including agars, sterilization of solutions in open & closed bottles, disinfection of materials and waste decontamination.

Roch Mechatronics Inc. Autoclave have inner chamber of S Steel, Boiler, Lid and Jacket - all made of 304 grade stainless Steel, outer chamber of thick gauge mild steel. For controlling sterilization cycle, a three way valve or a multiport valve - made of S.S. is provided. It is supplied complete with vacuum breaker, water level indicator, steam trap and automatic pressure control switch. The whole unit is mounted on a robust tubular stand. It is available in the following standard sizes. Operatable on 3 Phases, 440 Volts A.C. Supply. Single Phase optional on request.  The pressure inside the chamber is variable from 5 psi. to 30 psi.Working Temperature : 121° CHydro test Pressure : 2.5 kgf/cm2 ( 35 psi)

• WIDTH X HEIGHT X DEPTH: 450 X 450 X 900 m.m.,

Inner Chamber is made up of thick non-magnetic steel of 304316 quality and jacket is made out of rolled steel. Single door made of rolled steel lined with S.S. sheet has radial locking system. All units are hydraulically tested upto 40 psi. The space between outer cover made of thick rolled steel sheet and steam jacket is filled with asbestos sheet or glass wool to minimize thermal losses. Boiler is made of thick S.S. sheet and is located under the sterilizer. It is fitted with water level indicator, safety valve, pressure gauge, and water inlet and drain valves. Unit is fitted with low-water level cut-off device and automatic pressure control device. All "UNIVERSAL" rectangular sterilizers are fitted with SELF LOCKING SAFETY DOOR device. The door cannot be opened when chamber is under pressure. Two separate valves are provided for evacuating steam from inner chamber and jacket, as and when desired. Fitted with a dial thermometer and automatic vacuum breaker. To work on 440 volts, 3Phase, A.C. supply Triple Walled with Steam jacket and Separate Boiler. Sterilization cycle is controlled by Multiport Valve. The unit is fitted with all standard accessories.
