Master Controller Dealers in Delhi

Owing to our sophisticated production unit and rich industrial experience and knowledge, we bring forth a wide range of Master Controllers. They are used for remote operation of contractor equipment controlling heavy-duty E.O.T. cranes and rolling mill drives etc. The enclosures of our Master Controllers are fabricated from different grade materials like reinforced sheet metal and aluminium. The covers of these controllers can be easily removed and have proper space to allow easy maintenance. They are mounted on the housing on modeled bushes.   Features Long life Easy maintenance Wide electric Clearance

Application: “SPEEDAGE” Master controllers  / Cam controllers are used for remote operation (Cabin Operation) of contactor equipment controlling Heavy duty E.O.T. Cranes & Rolling Mill Drives , on power and control circuit upto 500Volts a.c. , 50 cycles at 40Amps. continuous current and 2.5 amps. at 220 Volts D.C. when handling inductive loads. SALIENT   FEATURES Long Life Simple Maintenance Wide Electrical Clearance    Master controllers can also be supplied with following arrangements. Deadman’s control : This consists of one auxillary contact of two circuit block (1 NO+ 1 NC) operated through a spring loaded push button provided on joystick handle in case of operator looses the grip over button during operation, motion will come to stop as main contactor will be de-energised. Spring Return arrangenment : The master / cam controller can be provided with spring return arrangement whereby handle returns to the neutral position when it is released. Dual Master Controller   “Speedage” Twin master controller with one universal handle allows a crane operator to operate both bridge and trolley motions with one handle. Simultaneous operation of bridge and trolley motions provides greater spotting accuracy and faster movement of loads. The handle of joystick can be moved into any quadrant and any position within that quadrant. By controlling both motions simultaneously the operator is free to devote more attention to controlling the hoist motion with is other hand.
