Mellcon Engineers Pvt. Ltd. Okhla, Delhi

we offer refrigerated air dryer. a refrigerated air dryer is the most commonly used. type of compressed air dryer gas dryer for most plant applications for the drying of plant air and other utility gases like seal gas , hydrogen gas for generator cooling , nitrogen gas drying etc. where a dew point of (+2) deg. c. at line pressure i.e. (-22 )deg. c. at atmospheric pressure) is an acceptable norm. this type of dryer finds application in fly ash conveying , seal gas drying . general plant air , hydrogen gas dryer used in generator cooling application & pneumatic tools operation. as much as 2300 gallons of moisture can be removed from a100 cfm pneumatic system operating at 100 psi in 12 months of 3 shift operation, moisture which without a refrigerant air dryer, would have passed through the delicate pneumatic equipments & instruments features of refrigerated air dryer a full range of aircooled as well as water cooled refrigerant air dryers are available for moisture removal & to provide dry clean air to any size and type of compressed air & pneumatic systems

Ellcon offers fully automatic and effective ready to use effecient refrigerant recovery system with power range from 120 watts to 1200 watts. It has a volumetric capacity range from 4-6kghr to 40-45kghr. To start the unit connect the service hose to the lower side of the refrigeration system and press the start button. The unit will start operating and the refrigerant gas gets extracted and distilled. It will turn off automatically after all the gas is removed. It will pull a 10 degree vacuum and if a positive pressure is sensed the unit will start automatically.

We offer liquid dryer. Mellcon Engineers are the manufacturers of complete range of Liquid Dryers, solvent dryers dehydration equipments & dehydrators Designed for removal of dissolved water from a variety of liquids critical to Industry. These dryer are designed for a continuous duty like Twin tower liquid dryer system or single tower liquid dryer system for batch operation i.e. Desiccant systems for liquid dehydration have two basic cycles:- Drying- The removal of dissolved water from liquids is accomplished by passage of the wet liquid through a freshly reactivated packed column of granular desiccant material like silica gel, activated alumina or molecular sieves. Continuous operation is accomplished by the use of dual adsorbers, with one tower on the process stream while the other is being reactivated. Reactivation- Reactivation is accomplished in the following steps: Drain the tower of liquid product Heat the desiccant to release water. Remove released water from the tower. Cool and refill.

We offer Hot Air Blowing Equipment. Mellcon Engineers are specialized manufacturers of Industrial Hot Air Blowers & Air Heaters equipments for Bus Ducts dehydration & moisture removal technology during long shut down periods. We have supplied large number of Hot Air Blowing Equipments to various projects e.g. Neyveli Lignite Corporation, NALCO Angul, GMDC Ahmedabad, NTPC Rihand, Panipat Thermal Project, DVC Mejia, Pendent Cement Bhutan etc. Inspection was carried by leading consultants like MECON, M.N Dastur, DCL, Desein, Tata Projects etc. Mellcon make Hot Air blowing Heaters are equipped with Digital Temperature Indicating Controller (TIC), Blind Temperature Controller (BTC). TIC and BTC are having individual set points, by which the temperature of the Air Heater can be controlled. Set temperature of TIC is at outlet temperature can b maintained as required, So that this will maintain the temperature of heater at this temperature by energizing & de energizing the Heater according to the temperature. BTC which is provided as extra safety device is set at 10 degree C above desired outlet temperature.This will cut off the heater if the temperature increases more than its set temperature and alert the operator by an audio alarm so that the temperature will not increase beyond control.

We offer hoc type air dryer. Energy conservation by heat of compression type compressed air dryer is a breakthrough in compressed air drying technology. The hot air from the oil-free air compressor at 120°c or higher temp, is used directly for regeneration of the desiccant bed in the compressed air dryer. After regeneration, this air is cooled down to 40°c in the water cooled after cooler and then it is dried in second tower. Thus the use of heaters is eliminated. For eg. In the 6 + 6 hrs. Cycle the hot air is fed for regeneration of desiccant bed for 4 hrs. And for balance 2 hr. A changeover takes place where the air is first cooled in an after cooler, then dried and before going to the outlet, cools the regenerated desiccant bed, thus bringing it down to ambient temperature. This cycle is reversed for the next 6 hrs. Where the adsorber drying the air in the previous cycle goes for regeneration and vice versa. There is considerable power saving in these type of compressed air dryers and the dew point is also better than the refrigerated type of compressed air dryers . Main advantage of heat of compression type compressed air dryer is the energy conservation and heat recovery achieved which is being wasted in after cooler in the conventional air dryers is now used to reactivate the desiccant.

We are offering high pressure gas dryer. Mellcon high pressure air gas are available in operating pressure ranges i.e. 60 bar g (900 psig) to 400 bar g 6000 psig) and in flows ranging. From 50 to 500 m3 per hour (30 to 300 scfm) for compressed air and process gases. The unique high pressure design provides unparalleled reliability, easy maintenance and safety from dangerous high pressure leaks. Integrated pre-filter and after filters with differential pressure gauges and manual drains are provided as standard equipment making installation an easy and quick job. Suitable controls for offshore or hazardous duty applications are available upon request. Activated carbon filters are also incorporated to remove oil vapors upto 99.99 percent efficiency. An optional dew point meter can also be offered as an integral unit. for various industrial applications where air gas at high pressure in dry form is required, mellcon offers high pressure air gas dryers. It is suitable for such application and is one of the best choice. High pressure air gas dryers are mainly used in marine & defense applications. Some of the other high pressure industrial applications are. :- 1. Air circuit breakers. 2. High pressure generator starting 3. High pressure air for aircraft engine starting 4. Scuba diving and breathing air applications 5. High pressure gas filling 6. High pressure h2 for turbine cooling 7. High pressure testing 8. High pressure process gas applications etc.

We are offering heatless air dryer. Pet blowing machine air circuit breaker high pressure gas filling high pressure pneumatics testing of various equipment and components. high pressure h2 gas dryer for turbine cooling high pressure generator compressed air starting high pressure process gas applications.

Mellcon dew point apparatus is the most economical, simple, errorless system for the spot checking of dew point temperature of any compressed air gases. This consists of a closed cylindrical glass with two chrome plated tubes, a low range thermometer (-50+40 deg.c) and a dry ice maker. Air gas enters to cylindrical glass through one chrome plated tube and exhausts. The other chrome plated tube is centrally placed in the cylindrical glass and thermometer is placed in it. Make dry ice (solid c02 ) with the help of dry ice maker & a co2 gas cylinder. Pour some ether acetone in the chrome plated tube having thermometer, and slowly put dry ice pieces into this liquid to reduce the wall temperature of the chrome plated tube. At a particular temperature the dew frost will start forming on the walls of the tube and the same temperature can be noted from the thermometer. This is the dew point temperature of that particular air gas.

We are offering auto drain trap. Mellcon auto drains are most economical, simple & maintenance free systems. The compressed air gas contains inherent moisture which will condense in receiver tanks, filters and pipelines, which requires regular draining systems. Auto drains are available in two options namely: 1) electronic timer drain. 2) level based zero loss condensate drain

Mellcon Compressed Air and Gas Filters being manufactured are best Tested for simultaneous mechanical separation of liquid droplets and of solid dust from compressed gases. Tested with oil mist, these filters will have to be followed by adsorber units which have the double function of removing the remaining mist particles and of adsorbing the dissolved gases and vapours. Such "Adsorbers" contain granular adsorption media, usually activated carbon or silica gel. The granules nearer to depth filter and liquid mist particles, meanwhile the farther granules adsorb the dissolved vapours. Working pressure : 10 kgcm2. Material : Carbon Steel. Finish : Inside black bituminious paint. Flanges according to ASA-150 RT Ceramic filter cylinders of grain size 120. All sizes are supplied with separately packed carbon except the In-Line Adsorber, which is supplied with filled-in carbon.
