PUF Insulated Panels Dealers in Delhi

• Material: PUF
• Shape: Plain
• Application: Roofing
• Thickness: 0.5-1mm
• Finishing: Polished
• Feature: Corrosion Resistant, Durable, Good Quality
• Thickness Range: 30 mm to 100 mm

Pre-fabricated Composite Panels or Insulated Panels for Roofing & Cladding are Sandwich Panels manufactured with profiled Color Coated Metal - Zinc Coated / Galvalume Coated Steel Sheets or FRP / GRP Profiled Sheets duly Sandwiched with PUF (Polyurethane Foam) as the insulation material.The Panels are available in various colors and total thickness of panel range from 30 mm to 100 mm. The PUF Panels are ready-to-install and self supporting with high overall stiffness. Advantages & Essential Features Very high thermal insulation - Superb thermal efficiency & rigidity. Ready-to-Install and self supporting. Inner and outer skin in Pre-coated GI / Galvalume / FRP Sheets are resistant to extremes of Weather & corrosion. Very light weight to high strength ratio. Ease of handling & installation. For Roofmg & Cladding provision of specially designed overlap system to ensure water leak proof & airtight joints. Vertical & horizontal Panels are provided with Tongue & groove joints to ensure air tight assembly. Monolithically Constructed Panels, hence saving on support structure, no use of wire mesh or loose insulation / Glass wool to be fixed separately and ease of handling & installation with less of labour. Withstand against storm, heavy rainfall, wind. Sturdy enough for temperature (-180°C to +140°C). Fire retardant and Self extinguishing. Low maintenance.   Applications Industrial Building & Sheds - Automobile, chemical, steel, cement, power plants, pharamaceutical, commercial building, godown, etc. Telecom Shelters Cold Storage & rooms. Pre-fabricated Shelters / Defense Shelters. Range of Insulated Composite Panels Insulated Roofing & Cladding Panels for pitched Roofs with minimum slope of 7 - 8%. Insulated Roofing & Cladding Accoustic Panels. Insulated Wall Panels with Tongue & Groove jointing system for use in Industrial, commercial, refrigerated rooms & Cold Storage. Fixing accessories like flashings, corner joints and customized fittings. Insulated Wall Panels with Tongue & Groove jointing system for use in Industrial, Commercial, Refrigerated Rooms & Cold Storage : Insulated with PUF and are self supporting panels for use in Industrial Building Partition, Telecom. Shelter, Cold Storage, Defense Shelters, Porta Cabins, High Altitude Cabins,' Commercial Buildings etc.The Panels are provided with tongue and groove systems for jointing Air tight system. Fixing accessories like flashings, corner joints and customized fittings : All the above panels are available in required thickness as per customers requirements and site conditions. All necessary standard accessories are provided for proper fixing & erection of complete system. Specification Density - 40 ± 2 Kgs m3 Compressive Strength at 10% deformation - 2.1 Kgs/cm3 Tensile Strength - 4.0 Kgs/cm2 Bending Strength - 4.2 Kgs/cm3 Adhesion Strength (Foam to Steel) - 3.0 Kgs/cm2 Dimensional Stability (48 hours)  - -25°C 0.1% +38°C & 90% RH 0.1% + 100°C 0.4 Closed Cell Content - 90-95% Temperature Range - -180°C to +140°C Temperature Conductivity at 0°C (design value 0.020 k Cal/m-hr/°C or 0.023 w/m - 0.018k Cal/m-hm/°C k) Water Absorption - 0.2% volume at 100% RH Vapour Permeability (At 90% RH & 38°C) -  0.8/0.12 GMS/HR m2 as per IS 11239 Fire property extent to burn as per BS 4735 - Max. 100 mm Type - Self extinguishing

• Color: Blue
• Country of Origin: Made in India
• Usage/Application: Residential and Commercial
• Surface Treatment: Color Coated
• Material Grade: Industrial or commercial
• Insulation material: Rockwool
• Core Thickness: 50,60,80,100,120 mm
•  :

• Type: Puf Panel
• Material: Puf
• Shape: Plain
• Thickness: 0.5-1mm, 1.5-2mm
• Color: Available all color
• Feature: Durable, Good Quality, Water Proof
• Finishing: Polished

• Country of Origin: India
• Size: Standard
• Type: Insulated
• Material: PUF
• Shape: Rectangle
• Color: Grey
• Finishing: Polished
• Brand Name: Bright Star
• Certification: ISI Certified
• Application: Industrial

• Type: Puf Panel
• Material: Puf
• Application: Roofing, Wall Insulations
• Thickness: 0.5-1mm, 1.5-2mm
• Color: White
• Finishing: Polished
• Feature: Corrosion Resistant, Durable, Fine Finish

• Application: Use to cover your roofs,Bungalow, Farm House, Industrial Shed, Cold Storage , Terraces
• Feature: No thermal bridges, high mechanical strength, maintains insulation effectively
• Color: Silver, Black, etc.
• Durability: Long Life

• Thickness of Sheet: 50-70 Mm
• Wall Width: 1200 Mm
• Material: PUF
• Application: Roofing
• Thickness: 30 TO 100 MM
• Usage/Application: ALL OF THEM
• Roof Width: 980 mm
• Pitch: 199 mm

• Size: 600mm X 1200mm
• Type: Thermal Insulation Panels
• Material: Woodfibre & Thermocole
• Shape: Rectangular, Square
• Thickness: 35mm - 75mm
• Application: Roof & Ceiling Insulation

Thermal Insulation Products are used  for the reduction of the effects of the various processes of heat transfer between objects in thermal contact or in range of radiative influence. Thermal insulation provides a means to maintain a gradient of temperature, by providing a region of insulation in which heat flow is reduced or thermal radiation is reflected rather than absorbed.

• Thickness: 30 to 50 mm
• Material: PUF
• Features: Flawless finish, Robustness, Chemical resistance.
• Uses: Suitable for cold storage rooms and food processing industry
• Usage/Application: Cold Storage
• Density: 40+/- 2kg/m3
• Is It Water Proof: Water Proof
• Effective Width: 400 - 1120 mm

Colour Coated metal sheet facing on both sides, Crown type overlapping joints on external facing, Excellent weatherproof cladding, External facing profile overlaps over the adjacent panel, Unique fitting arrangement to prevent water leakage from the roof, Thickness available 30mm, 40mm, 50mm, 75mm & 100mm.

• Feature: Very quick delivery and completion

We offer extensive range of PUF insulated Panels, which are suited for applications such as, cold storages, pack houses, CA chambers, banana ripening chambers, freezer rooms. PUF panels are manufactured in a computerized plant and come in pre painted galvanized steel sheets (PPGS) and stainless steel fascias. In this, the density of Poly Urethane Foam (PUF) sandwiched between two fascias is 40 + 2 Kg M3.These insulated panels offer long lasting value with controlled quality, accuracy & speed of construction.

• Temperature: + 1500C to - 2000C

PUF materials are suitable for temperature range between -200°C to +110°C. PIR Slabs & Pipe Sections are suitable for use between -200°C to +145°C. It has low thermal conductivity value of maximum 0.021 wmk at 10°C. It is not easily ignitable and has negligible water permeability. It is suitable for cold chilled pipelines, building roof & wall insulation, equipment insulation and horton sphere insulation. PUF PIR is available in boards, pipe sections, radiused and beveled lags, with or without factory laminated facings.

PUF Pipe Supports PUF is one of the major components of pre-insulated pipe supports.Polyurethane is different from most plastic materials in that it can be tailored to meet various load requirements of varying applications. Insulated pipe supports are designed to prevent direct heat transfer between pipes and their supports. Thus, they reduce heat loss due to conduction at each support. They serve the following purposes: 1. Carry the load and allow necessary movement at each suppose point. 2. Provide insulation in the support area where the regular pipe insulation cannot be installed. 3. Minimize the cost of field installation by reducing installation time.

we are a delhi based company engaged in manufacturing, exporting and supplying puf sandwich panel. We make available puf sandwich panel that is fabricated using quality material under the supervision of experts. Our puf sandwich panel is widely used and demanded owing to its supreme quality and performance. We offer puf sandwich panel at reasonable prices. used in cold roomsrefrigeration systemsporta cabinsrefigerated truck bodiesclean roomscottagetiolet shelter, security cabin, telecom shelters features various thickness ranging from 50-200 mmlength upto 1170 mm, max up to 200 mm and width min 6000mmsheet thickness of 0.5, 0.6, 0.8 and 1 mm.stainless steel sheets panels finish –pre-painting galvanized sheetspolyurethane panel’s uniform density is over 40 kgm3, which provide structural rigidity and stability.cam action edges, groove and joining mechanism with tongue offers ease and flexibility to a strong unit of constructionour panels are equipped with self closing hinges to reduce unnecessary loss of refrigerated airthe concealed heater wire circuit inside the door frame prevents condensation and frost formation at the edges of doors and frames.reinforced roof panelslong life with zero maintenancemortise lock and stainless steel hingeswater proofing to the joints of the ceiling panelsprojected roof of 150mm on all sides for rain protectiontorque groove configuration with inbuilt unpick able eccentric cam lockstime savingsafe as it has the best fire rating among all materialsfree from termite attack properties of puf panel puff density 40kgm3 or as specified by customercompressive strength 2.1kgcm2(at 10% deformation)adhesive strength (foam to sheet) 3kg cm2tensile strength 4kg cm2thermal conductivity

• Thickness: 30 mm, 40 mm
• Material: PUF
• Usage/Application: Industrial
• Density: 40 +/- 2 Kg / Cu. Mtr
• Temperature Range: -80 Deg C to 100 Deg C
