Casemaking binding Machine (3219)
350,000 - 425,000 Per Piece
1 piece (MOQ)
Seyon Casemaker Machine (3219) has diverse technical specifications to suit your needs. These include a maximum Case size of 480mm x 752mm and minimum of 100mm x 150mm. The Paper thickness is about 60gsm to 1.5mm (Board) and the Board Thickness is 1mm to 7mm. You can be assured of getting some of the best rates in the industry for a premium finish.
Technical Specification
Case size Max - 480mm x 752mm
Case size Min - 100mm x 150mm
Paper thickness - 60gsm to 1.5mm(Board)
Board Thickness - 1mm to 7mm
Turning-in Width - 15mm to 40mm
Production - 300 casesHr
Glue - Hotmelt Cold
Power - 1.25Hp (3Phase)
Heater - 2Kw (Single Phase)
Pneumatic - 6 – 10 bar
Dimensions - H 1150 x L 2700 x W 800 mm
Weight - 750Kgs (approx).
Gluing system - Bottom
Man Power - Two
Materials - Paper, Laminated Paper, Paper Coated sheet, Rexin etc.,
Salient Feature
No Adjustment for any thickness board.
0.0 stainless steel rollers for permanent life.
Job makes ready time is less.
90deg spine registration systems with pneumatic system.
4 Rubber rollers with self heavy tension spring no need for adjustment for any thickness of board.
Temperature control systems for glue melting.
All motors are geared motors for long life.
4 stainless steel rollers are provided for straight feeding.
Board gluing systems will be provided.( instead of paper gluing system).
