Tire Changer Machine Dealers in Delhi

Suitable for 12 inch to 24 inch stiff,wide,flat and low-profile tyres; •    With self-centering function •    Clamping system with stepping function; •    With quick inflation device for tubeless tires •    Air reserve tank build- in the vertical column •    With adjusting & calibrating functions in the 4 clamps on the turntable •    Rubber-pad mount/demount g head •    Angles of mount/demount head can be adjusted & calibrated •    Robotic arm (Optional) •    Polymer mount/demount head of high quality prevent damage to the rim (Optional)

• Rim diameter: 14" to 26"

Apply to rim dimension between 14" to 26". Lifting arm and universal chuck are all driven by the hydraulic pressure. King jaws with different gripping possibilities. Universal tool carrier arm with pendulous bead braking disc and hook.Operation voltage 24V. safety stable.

• Features: Rigid design, Compact structural design, Optimum functionality

• Weight: 100 Kg
• Condition: New
• Usage: Tyre Changer
• Material: Cast iron
• Maximum Wheel Diameter: 960mm
• Working Air Pressure: 8-10 bar
• Power Supply: 230V, 1 Ph. 50/60 HZ
• Outside Clamping Range: 10-20"
• Inside Clamping Range: 12-22"
• Maximum Tire Width: 13" (330 mm)
• Maximum Tire Diameter: 1,000 mm
• Maximum Bead Breaking Width: 330 mm
• Chuck Speed: 6.5 RPM
• Compressed Air Supply: 8-10 bar
• Number of Pedals: 3
• Clamping Cylinder Diameter: 70 mm

• Type: Tire Changer Machine
• Application: Changing Tire
• Color: Red
• Condition: New
• Automatic Grade: Automatic
• Driven Type: Electric
• Warranty: 1year
• Country of Origin: India
• Material: Iron

• Type: Tyre Changers
• Certification: ISO 9001:2008 Certified
• Weight: 0-200 Kg
• Voltage: 220-380V
• Condition: New
• Power: 1000-2000 W
• Warranty: 1year
• Operating Pressure: 0-10 Bar
• Color: red
• Rim Size: 10
• Single: Piece Rim Only.
• Swinging: Vertical Arm.
• Motor: 1.5hp 220V, 50Hz
• Four Jaws: Double Cylinder.
• Bead Breaking Force: 2500 kg
• Machine Weight: 190 kg
• Rotation Speed: 7 rpm

Tyre Changer is the necessity of every Automotive Workshop. So to cater the wider necessity of the people, Our Company Hyco Products manufactures high quality Tyer Changer Equipments, which comprises Head Lifting Lever, Hold Down Cone, Brush, Tyre Lube, Container, Valve and Valve box etc. Our Offered Tyre Changer are widely appreciated by the end users of our products for high efficiency in use, sturdy construction, low maintenance and longer service life. Tyre Changers are available in various sizes, design and specifications and thereby offers wider choice for the customers. For further detail, a brief description of Tyre Changer is given below:

• Net Weight: 259 kg
• Dimensions LxDxH: 1600 x 1950 x 2150 mm

Rugged and robust design to withstand the demanding environment of a workshop. Swing-arm design that is suitable for a wide range of rim and wheel sizes. 14mmthick square tumtable to withstand the increased bending forces when handling large and low-profile tires.

• Voltage: 220 V
• Warranty: 2 Years
• Automation Grade: Automatic
• Material: Mild Steel
• Color: Red
• Phase: Single Phase
• Frequency: 50 HZ
• Usage/Application: Automobile Industry
• Brand Name: Ecotech

Handles both standard steel wheels and delicate alloy wheels High torque turntable with reversible direction Tilt – back arm design Pneumatic lock for tower Can be equipped with Motorcycle adaptor

• Operating Pressure: 0.7-0.8MPa
• Power Voltage: 220V/380V
• Motor Power: 1.5/1.1 KW
• Average Rotate speed: 6.8rpm
• Rim Clamping Outside: 11" to 22"
• Max wheel Diameter: 42"
• Max wheel width: 4"-15"
• Gross Weight: 350kg
• Packing Dimension: 1150 x1000 x960mm`

Tilt back tyre changer for handling RFT(profile) tyres. Equipped with Auto-helper vertical post tilt back for easy adaptability, Pull and push arm with pneumatic locking design.  Tool for RFT(profile) tyres to avoid damage to rim and tyre. Bead-breaker blade tool moves with inside rim contour to avoid damage to bead.  Aluminium - alloy valve bodies with durable corrosion resistant stainless-steel valve rod

We offer a precision engineered range of semi automatic tyre changers which is widely used in workshops. These changers are available with tyre changer swinging arm, high power bead beaker, twin cylinder and asymmetric 4 jaw chucks. Also, the range is highly suitable for alloy rims, and is widely used for changing tyres of cars and lcv's.

• Warranty: 1 YEAR
• Color: RED,BLUE
• Model Number: SA11021
• I deal in: New and Second Hand
• Type Of Vehicle: UNIVERSAL
• Automation Grade: Automatic
• Brand: SHAH AUTO

• Tyre size upto: 12" to 21"
• High power motor: 75hp
• Features: alloy wheel compatible, inbuilt tyre inflation gun, heavy duty gear box.

• Model : Jet Fit: Jet Fit-500
• Rim clamping from outside: 14-26
• Rim clamping from inside: Truck/Bus Tyre
• Max. wheel diameter: 1500mm
• Max wheel width: 760mm

It can handle TruckBus tyre between 14-26� and Tractor tyre between 14-42� with deep ground rim, tube less tyre and tyre with rings. It works on Electro Hydraulic power. Good tool for STUs, Army Trucks, Large fleet owners and HCV tyre shops.

Technical Specification Motor : 1 HP/220V Clamping : 10” – 20” Wheel diameter : up to 38” Wheel width : 3” – 12” Rotation speed : 7rpm Space – saving and cost-efficient swing arm Noise level < 70db Machine weight : 190kg Motorcycle adapter (optional) Plastic tool for alloys (optional) Standard Accessories : Air filter, regulator and lubricator   Standard Accessories: Helper arm Air filter, regulator and lubricator Tyre lever Brush with mounting gel box Tyre inflator with gauge Tyre lever Tyre inflator with guage Brush with mounting gel box Motor : 5HP/ 220v Clamping : 10” – 24” Wheel diameter : up to 49” Rotation speed : 7 rpm Space – saving and cost- efficient swing arm Plastic clamping jaw covers , prevents damage to alloys Noise level < 70 db Machine weight : 230 kg Quick inflation air blast system with jets Motorcycle adaptor (optional). Plastic tool for alloys (optional)

• Features: Accurate functioning, Dimensionally accurate, Durable, Robust, Efficient, Convenient market rate
• Electro Pneumatic: Semi Automatic
• Rim Size: 11” – 24”
• Rotation Speed: 7 RPM
• Electric Motor: 1.5HP, 220V
• Bead Breaking Force: 2500kg
• Machine Weight: 230kg
• Item Code: T-24

• Features: Rust proof,Accurate dimension,Less maintenance
