Vibro Sifter Dealers in Delhi

• Material: Stainless Steel
• Capacity: 50 Kg
• Usage/Application: Grains, Steel Shots, Seed, PVC, Food, Slurry, Paints, Talcum Powder, Starch, Foundry, Salt
• Finish: Bead, Mirror
• Automation Grade: Manual

Reckoned for the offering outstanding array of products, we are headquartered in New Delhi(India). In order to keep the products in safe condition during handling, warehousing and transit, we make use of only premium packaging materials. Moreover, our skilled personnel are employed for carrying out the task of packing.

• SS: SILVER

Stainless Steel Vibro Sieve Separator offered comes with free swinging sieve as well as unidirectional screen motion. With the system driven using vibrator support with adjustable angle of throw & adjustable stroke, it also features presetting of screen inclination as per the application needs. The system finds suitability in removal of coarse & fine impurities like sticks, gunny threads, sand. Features: Low power consumtion No screen chokingclogging Flexible Layout Low maintenance Moduler design Compact and elegant

• Certification: CE
• Weight: 100-1000kg
• Color: Metallic
• Automatic Grade: Automatic
• Power: 1-3kw
• Warranty: 1year

Vibro separators are circular unitary gyratory screens used to separate mass composition of solids from solids, liquid from solid and for gradation of materials as per particle size, having a very wide range applications. This is accomplished by vibrating the screens in three different planes along the vertical axis by means of a specially designed vibratory motor having off centered weights at the top and bottom end of the motor shaft. The top weight causes vibration in the horizontal plane which causes the material to move across the screen towards the periphery. The lower weight acts to tilt the machine which causes vibration in the vertical tangential axis.    The angle of lead of the lower weight with relation to the upper weight provides variable control of the screening pattern. Thus the material moves across the screens and also in the vertical and tangential planes enabling maximum screening. YADAV PHARMA MACHINERY’ Vibro sifter are available with a wide range of possible screen sizes (mesh) Option for multiple deck separation is also possible.   The unit consist of Specially designed vibratory motor to run on 400 / 440V, suitable HP, 3 phase, 50 cycles electric supply ,with adjustable eccentric weights at the top and bottom of the motor shafts mounted vertically at the centre of the base plate of screening unit. Screening unit consists of SS 304 screen sandwiched between SS 304 hopper and bowl with the help of special clamp with gasket. Rugged Springs placed over the circular motor base amplify the vibration and at the same time restrict the vibration from being transferred to the floor.Salient Features : Noiseless, Maintenance free & high speeds   Details Available in various models providing screening diameter of 12”, 20”, 30” , 36”, 48”, 72” etc Portable and compact Electric power requirement less than other machine of the kind in the industries & lower energy consumption compared to reciprocating vibratory system Standard machine are with TEFC motor explosion proof / flame proof motor material. All contact parts and screen of SS 304/316 AISI stainless steel material. SS 316 quality contact parts optional. Easy dismantling and cleaning facility for contact parts. Wide range of screen sizes 4-200 Mesh. Double & Triple deck screens with outlet and hopper for bottom deck available on request.

• Automatic Grade: AUTOMATIC
• Brand Name: BMG
• Material: MIX MATERIALS
• Finishing: Powder Coated
• Driven Type: Electric
• Shape: Rectangular
• Color: Light White
• Condition: New
• Power: 1-3kw
• Pressure: Low Pressure
• Operating Type: Automatic
• Application: FOOD MILLING
• Certification: ISO 9001:2008 Certified
• Voltage: 440V
• Feature: Easy To Use
• Phase: Three Phase
• Warranty: 2 Years
• After-Sales Service Provided: YES
• Country of Origin: India
• Corrosion Resistance: Yes

We offer Gyro Screen.

• Type: Sifter
• Weight: 100-1000kg
• Color: Silver
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw, 3-6kw, 6-9kw
• Driven Type: Electric
• Warranty: 1year

Assisted by our industrial expertise accumulated over time, we have established ourselves as a leading figure in the industry. We offer lucrative deals of Vibro Sifter to our esteemed customers at attractive price. It boasts striking features such as low maintenance, high performance and fine finish. Our excellent distribution system enables you to get it delivered to your doorstep in no time at affordable prices.

We are offering vibro shifter. the shifter is a versatile sieving and grading machine for separation of solids, liquid from solids and production of graded materials in proportion to their size. The vibro shifter is designed on the principle of ‘gyratory motion’. The material is fed on to the centre of the screen and then travels on a spiral path to the periphery whilst the fine particles fall through. The material being screened is therefore drawn apart automatically and no additional force us exerted to separate coarser particles. The sieving is done gently and with little abrasion. The external vibrator is a three phase asynchronous motor which has eccentric weights mounted at the end of the rotor shafter. The rotating shaft causes centrifugal forces which can be adjusted by moving the weights. The motor is special designed with high stability m. S. Body special bearing with increased load capacity and vibration proof winding. features: · design as per stringent c’gmp requirements. · powerful vibration. · side outlet fines discharge · easy movable. · easy to clean · all contact parts of s. S. 304 quality · special vibro motor · noiseless machine technical specifications: single decker available in models: 30", 36" , 42", 48" dia

• Country of Origin: India
• Feature: Low energy consumption, high capacity, and operating efficiency., Easy and minimum maintenance, the hassle-free procedure by using Vibro-motors., Toughness and long lifetime., Soundless working.
• Product Code: CM-VS

• Power: 0.2 kw
• Model: BST/ZS-400
• Capacity: 50
• Dimensions (mm): 650x 500x800
• Ideal for dry and wet grading: Accurate screening and better yield
• Rubber suspension enables lower noise: Meet cGMP norms
• Available in up to 5 layers: High capacity flow-through design
• Easy to clean and maintain: Available in 30”, 40”, 48” and 60”
• Available in single / multiple screening: Painted or steel base

Vibro Sifter is a Circular vibratory sifting machine, which is designed to perform separation, scalping and grading processes for both dry and wet applications in pharmaceutical, chemical, food and cement industries. We offer an innovative range of such round separator machines that feature enhanced screening capability, lower noise and rugged construction. Meet Food and Pharmaceutical Requirements Our Vibro sifters are carefully designed meeting cGMP requirements and have been acclaimed by industry experts worldwide. Whether there is production line or R & D center, where particulate matter and / or dusts are generated these vibrating screens proved to be best fit for accurate screening in order to achieve better yield. Not only accuracy and working performance, our vibro sifters offer easy to clean and maintain structure. Frames can be opened easily and cleaned. These separators are available in four different diameters: 30 inch (750mm), 40 inch (1000mm), 48 inch (1200mm) and 60 inches (1500mm). Each unit is made with 316 grades high quality stainless steel. Every joint is fully tested and nuts and bolts are of superior quality assuring you a machine that is built for years of excellent performance. Our vibro sifters are spring mounted double closed sifting machines, fitted with vertical vibration motor, mesh frame and sieve room. Customers have options to choose from stainless steel base of painted base, whereas steel base is perfect for paint industries and can be clean easily. Along with standard models, we can also make customize sifter machines with single or multi-sieves configurations.   As we are manufacturing company, we supply our vibrating screens with specialized options in order to make the machine best suitable for your specific application. Whether there is choice of screen numbers or capacity (kg/h), we have technology and engineering to design a vibrating screen that will exactly match to your specifications. Our customers also get advantage of good after sales service; all spare parts are also available ensuring minimum downtime of your production or research. We supply these units to all over India and overseas at factory price. If you want to know how our vibro sifters are capable to meet you screening or grading needs, please send us an email with all the details you want to know from us.

• Material: SS
• Item Code: VS-01
• Model Name/Number: VS-01
• Material Grade: SS 304
• Automation Grade: Semi-Automatic
• Usage/Application: Pharmaceutical Industry

The Vibro sifter unit consist of Specially designed vibratory motor to run on 400/440V, suitable HP, 3 phase, 50 cycles electric supply .

This high performance gyro sifter, or vibro sifter separator, is engineered to handle all screening problems such as sieving, grading, separating, screening or scalping bulk materials. It can easily be installed into production lines, providing the best screening capacity without demanding excessive floor area. It has been designed to adjust easily allowing complete material control to optimize separation quality. Discharge outlets can also be moved around the machine giving greater flexibility in the positioning of collection bins or containers. Its modular nature segregates it from other models in terms of flexibility and optimum use of space.

• Improves your product quality: Increase your productivity
• Operator friendly: Reduces your costs

We are offering vibro separator. a cost effective vibratory equipment for solids removal or product recovery for wet or dry application the high performance russell eco separator is engineered to handle screening problems experienced by customers throughout the processing industries.

• Weight: 100-1000kg, 1000-2000kg, 2000-3000kg, 3000-4000kg
• Color: Brown, Grey, Light White
• Voltage: 110V, 220V, 380V
• Condition: New, Used
• Power: 1-3kw, 3-6kw, 6-9kw, 9-12kw
• Fetures: Good Quality, Durable
• Use: Industrial

Our Company, Mix-Well Industries manufactures world Class Quality Mix-Well Vibro Shifter Machine which is widely used in segregation from liquid to solid and from solid to liquid. Our offered Vibro Sifter Machines find use and application in many industries such as Pharmaceuticals, Chemicals Dyestuff, Pigments, Ceramics, Food Product, Detergents, Cosmetics, Paints Polyester Chip and Rubber Compounds etc. The Sifter machines are made of finest quality of raw material and components, under the supervision of highly qualified and experienced professionals of the company. The quality of our machine is widely appreciated by the end users of our machine. Offered Machine is available in various sizes, designs and Specifications, so as to meet wider needs of our valued customers. The Special features of our machines are as: APPLICATION:- Pharmaceuticals, Chemical, Dyestuff, Pigments, Ceramics, Food product, detergent, Cosmetics, Paints, polyester chip, Rubber Compound etc. Salient Features of our machines are as :- Faster in Production Faster in Production. Portable end compact design. Lower energy consumption compared to reciprocating vibrator system. Easy dismantling &cleaning facility contact parts. All contact parts & screen of S.S. 304/316 Qlty. & Non-contact parts S.S. 304 /MS Qlty. Material Available in various size 12" ,20" ,30" ,36" 48" & 60" (Single Deck , Double Deck & Triple Deck)

• Warranty: 1 yr
• Phase: 3
• Is It Portable: Portable
• Usage/Application: Industrial
• Automation Grade: Automatic
