Air Jet Cleaning Machine Dealers

Heavy duty base with robust construction off S.S. matt finished body Suitable for Inner and Outer wash for glass and pet bottle and vial High speed latest digital PLC technology No timing setting is required and less change over time for change parts Containers fed in the upright position via an unscrambler are inverted in mouth down position and linearly feed through starwheel to the chamber which is under negative pressure. A series of nozzles blow air in the container for cleaning and are re-erected in mouth upright position at outfeed Machine can be synchronized with filling machine Vibration Free, Jerk Free, Noise less construction with the help of different motors

Machine having four / six / Eight  nozzles for vacuum cleaning with INFEED, OUT FEED Tunnel & Dust Collector Mechanism.

• Brand Name: LAXUS,LAXUS
• Material: SS 316L,SS316L
• Finishing: Polished, Chrome Finish, Powder Coated
• Shape: Rectangular
• Color: STEEL COLOUR
• Condition: New
• Power: 1-3kw
• Pressure: High Pressure
• Power Consumption: 3 KW
• Speciality: Rust Proof, Long Life, High Performance, Easy To Operate
• Usage: Rust Removal, Rust Cleaning, Industrial, Auto Part Clean
• Certification: ISO 9001:2008
• Voltage: 415V
• Density: 1
• Packaging Type: WODDEN BOX
• Tank Capacity: 25 LTR
• Air Pressure: 6 TO 8 KG
• Type: Ultrasonic Cleaner,AUTOMATIC
• Diameter: 25 TO 80
• Thickness: NA
• Appearance: NA
• Machine Weight: 100-1000kg
• Frequency: NA
• Phase: Three Phase
• Warranty: 1 Year
• After-Sales Service Provided: YES
• Air Consumption: 6 TO 8 KG
• Country of Origin: India
• Operating Mode: Automatic
• Corrosion Resistance: Yes
• Machine Structure: Horizontal
• Direction Of Movement: LEFT TO RIGHT
• Main Brush Width: NA
• Dirt Container Volume: NA
• Maximum Moisture: NA
• Quick Wash Time: NA

The Automatic Four Head Air Jet & Vacuum Cleaning Machine Model HAVC-100having speed of 100 bottles per minute (depend on size). The Air Jet & vacuum Cleaning Machine applies Compressed Air through Jets and also sucks through Vacuum. Machine can be used to clean Glass/Plastic/PET Bottles, Jars etc. Machine suitable for cleaning of non-sterile products like Dry Syrups, and Bulk Packing of Tables and Capsules uses in pharmaceutical, Neutracetuicals, healthcare, food and cosmetics industry. Machine with built-in in feed Turn Table which feeds bottles in vertical position through conveyor to air jet cleaning station, where cleaning heads hold the bottle through cup holder and starts the Compressed Air and then instant Vacuum to clean the bottles. Machine in Stainless Steel Finish with all contact parts in SS316 and Nylon Materials. Machine also having overload clutch system to avoid jamming during the operation. The manifold comprises of inner nozzles which jets compressed air in the bottle and an outer socket, which cover the mouth of the bottle and is connected to an exhaust, ensures perfect cleaning. SPECIAL FEATURES: No Container - No Air - No Vacuum System Four Air Jet Nozzle with Vacuum Mouth Holder for Cleaning Fully Stainless Steel Finish Complete operation in Vertical position Overload Clutch for Jamming Variable frequency drive for easy speed operating. Automatic Infeed and Outfeed of bottles Linear compact model

BHAGWATI’s Airjet Bottle Cleaning Machine is compact and highly efficient machine with elegant look. This multi featured machine meets the GMP requirements of clean glass and plastic bottles & Jars for non-sterile products like Dry Syrup, Bulk Packing for Tablets & Capsules etc and found a method of cleaning each individual Bottle/Jar by air jet & vacuum.     Containers are fed in upright position on a scrambler and further fed to feed worm, where containers are automatically inverted. The synchronized mechanism feed the container one by one through a chamber which is under negative pressure. A series of nozzles blow air in the container at a high pressure. The dust is collected in dust collector box through exhaust fan. The container is further fed through the synchronized mechanism and feed worm. It is once again upright position and comes out duly cleaned for further operation.

• Brand: Ashirwad
• Direction of Movement: Left to Right
• Output: Upto 100 BPM Depending On Bottle Size
• Output Hour: 6000 BPH
• Air Consumption: 80 CFM PROVIDE FROM CUSTOMER
• Electric Load: 5 HP

Some of them are given below: Multi Jet Ampoule Vial Washing Machine Bottle Washing Machine Automatic Linear Vial Washing Machine Automatic External Ampoule Washing Machine Automatic Linear Bottle Rinsing Machine Semi Automatic Rotary Bottle Washing Machine   Specifications:   The machine is suitable to handle wash of 5,10,15,20 & 30 mm Output capacity: 40, 15 & 250 bottles/minutes Water re-cycling arrangement is possible as per clients’ requirement Inbuilt SS Pumps & SS tanks 2 no. Specification can be changed as per clients’ requirement

• Country of Origin: India
• Operating Mode: Automatic
• Usage/application: Bottle Cleaning
• Head: 2,4,Or 6 Heads
• Output per Hour: 2400 to 7200
• Directon of Movement: Left to Right
• Motor Power: 0.5 HP/ 415 V/ 50 Hz
• Blower Motor: 0.5 HP X 2= 2HP/ 415 V/ 50 Hz
• Cleaning Cycle: Positive air Pressure and Vacuum Cleaning
• Working Desk Height: 860 to 910 mm

• working height: 860to910mm

Positive air pressure and vacuum cleaning.Operator friendly.Stationary S.S. nozzles.Automatic loading and unloading of container.Separate control for air pressure and vacuum cleaning.Higher capacity blower to clean properly.

“FILSILPEK” provides air jet cleaning machine. This machine uses high-ve locity air to remove dust and contami nants, ensuring thorough cleaning of glass, plastic, and HDPE bottles. It o ers customizable cycles which is suitable for various industries, and promotes eco-friendly practices. Semi-Automatic Air Jet Bottle Washing Machine is a small item constructed entirely of stainless steel with height adjustment legs that allow you to alter the machine’s height. and an elegantly designed machine that is very efficient. This versatile, multi-featured equipment complies with GMP standards for washing glass and plastic bottles. The machine works on a linear principal mechanism and requires manual bottle filling and emptying.

• Model :: NAVAJC-100
• Out put / Hour* :: 1000 to 5000
• No. of Cleaning Nozzles :: 4
• Direction of Movement :: Left to Right
• Electrical Specification** :: 0.5 HP / 415 Volts / 50 Hz. 0.5 HP x 2 = 2 HP / 415 Volts / 50 Hz.
• Cleaning Cycle :: Positive air pressure and vacuum cleaning
• Working height :: 860 to 910 mm
• Electrical Supply :: Three Phase + Neutral + Earthing
• Air Consumptions :: 400 Ltrs. / Hr / Cycle / Pressure 2.5 Kg @ 20 CFM

• Air Consumption: 12 CFM
• Overall Dimension: 5' (L)x 5' (W) x 4' (H) Feet
• Model: MCS-AJC-100
• Output Speed: 40 to 60 Bottle per Minute
• Suitable Product: Bottle
• Product Range: 50ml to 250ml
• Water Consumption: As per Titration
• Electric Load: 2 HP, 3 Phase, 440 Volts, AC, 50 Hz

• Speciality: The machine is fully covered with an acrylic cover. ,Speed of the machine can be regulated through the variable frequency drive unit.

The Air Jet Bottle cleaning machine is suitable for cleaning bottles with compressed air and vacuum for dust collection. Bottles are fed through the S.S. slat conveyor which in turn feeds the bottle to the synchronized rotary carrousel wheel. Bottles are subjected to positive pressure with stage-wise filtered compressed air for blowing & loosening particulate matter, if any. Dust particles that are set loose will be collected under negative pressure by the suction blower provided.

• Air Consumption: 12 CFM
• Overall Dimension: 5 (L) x 5 (W) x 4 (H) Feet
• Automatic Grade: Semi Automatic
• Model: MCS-AJC-100
• Output Speed: 40 to 60 Bottle Per Minute
• Suitable Product: Flat Shaped Glass, PET, Plastic Bottles
• Product Range: 50ml to 250ml
• Water Consumption: As per Titration
• Electric Load: 4 HP, 3 Phase 440 Volts AC, 50Hz

• Brand Name: ASHIRVAD
• Model No.: AISAAC-20
• Production Speed: 10 to 40 Bottles/ min. (Depend on Operator’s Skill)
• Overall Dimension: 1220 mm (L) X 910 mm (W) X 910 mm (H)
• Power Characteristics: 415 Volts/3 Phase/50 Hz./ 1440 RPM (Four Wire System)
• Cleaning Nozzles: 4 Nos.
• Cleaning Type: Vacuum Type
• Loading and Unloading Type: Manual

Salient Features: Total cGMP model. Total contact parts are of S.S. 316, and other surface parts are of S.S. 304. Positive air pressure and vacuum cleaning. Adjustable & diving type cleaning nozzles. Individual control for air pressure and vacuum cleaning. Higher capacity blower to clean properly. S.S. pressure meter. Standard in quality & economical in price.

We are the leading manufacturer and supplier of Air Jet Vacuum Cleaning Machine. The offered product is manufactured using best quality raw material. Our product are known for their high performance and durability. We offer these machine in various sizes and specifications. Low maintenance cost.The unbeatable performance of Bottle Cleaning Machine provided by us has helped us to gain huge accolades from the clients. This machine is very useful for cleaning of bottles. Vacuum Cleaning Machine offered by us is of exceptional quality and known in the market for its easy functioning and long functional life. Today, our company is ranked as one of the renowned Vacuum Cleaning Machine Manufacturers and Suppliers in India.We can deal in special application as per coustmer requirement. Specifications: Suitable for Tablet Line & Powder Line. Capable of handling 30ml to 150ml bottle with no parts. Output will be 20 to 100 GlassPet Bottles Attributes: Smooth operation. Easy to use. Long service life. Flawless performance.

The Automatic Air Jet Cleaning Machine, Model : HAVC-200  is suitable for Round shaped Glass, PET, Plastic Bottles and Jar of various sizes with maximum speed of 200 containers per minute by Air Jets and Blower  Machine construction in fully Stainless Steel finish including machine frame structure.Machine with applications in Pharmaceutical, Food, Distilleries and many more industries.   Containers fed in upright position via an unscrambler are inverted in mouth down position and linearly feed through starwheel to the chamber which is under negative pressure.   A series of nozzles blow air in the container for cleaning and are re-erected in mouth upright position at outfeed. SPECIAL FEATURES: 2 Needles for cleaning All contact parts made of SS 316 materials Machine construction in SS 304 material Suitable for 30ml to 200ml containers (with the help of change parts)

• Power: 2 HP
• Material: Stainless Steel
• Voltage: 220 V
• Power Source: Electric
• Working Height: 860-910 mm
