Back Pull Out Pumps Dealers

• Type: Back Pull Out Pumps,CENTRIFUGAL
• Certification: ISO 9001:2008
• Application: Industrial
• Weight: 100-200kg, 200-300kg, 300-400kg, 400-500kg
• Color: Black, Grey
• Voltage: 220V, 380V
• Condition: New
• Power: 3-6kw, 6-9kw, 9-12kw
• Driven Type: Electric
• Warranty: 1year
• Country of Origin: India
• Brand: MONIBA
• Material: SS 316

• Size: 50 mm to 150 mm
• Capacity: 150 M3/hr to 400 M3/hr
• Head Range: 20 M to 100 M
• Specification: IS-6595
• Casting: CI FG 200
• Impeller: CI FG 200 (Options-SS/Bronze)
• Shaft: Carbon Steel (Options-SS)
• Shaft Sleeve: Stainless Steel
• Solid Handling: Upto 40 mm
• Ball Bearing: Heavy Duty anti-friction
• Heads: upto 50 mtrs
• Capacity: upto 7200 L.M.P
• Suction lift: upto 25 ft

• Color: Green
• Voltage: 440V
• Type of end use: Industrial
• Motor Horsepower: 2 HP
• Material: Cast Iron
• Stages: Single Stage
• Motor Phase: Three Phase
• Pump Type: Centrifugal
• Power Source: Electricity
• Frequency: 50Hz
• Automation Grade: Semi-Automatic

• Maximum Flow Rate: 550 m³/h
• Minimum Flow Rate: 2.5 m³/h
• Maximum Head: 102 m
• Minimum Head: 3 m
• Speed of Rotation: 3500/ 2900 / 1400 / 950 revolutions/min
• Maximum Discharge-side Pressure: 10 bar
• Type of Bearing: Ball Bearings
• Frequency: 50 Hz / 60 Hz
• Type of Drive: Electric motor
• Type of Coupling: Direct
• Max. Permissible Fluid Temperature: 140 °C
• Installation Position: Horizontal
• Suction Characteristics: Non- priming
• Shaft Material: SS 410 / SS 316

Centrifugal Pumps are essential for hydraulic mechanisms. The Back Pull Out Type Centrifugal Pumps that we deal in are fabricated using top-notch quality basic materials and the latest technology. Our Back Pull Out Type Centrifugal Pump are energy efficient, robust and performance oriented. They can be obtained from us globally in different specifications as per the requirements. Located in Gujarat (India), we are a reliable Manufacturer, Exporter and Supplier of Back Pull Out Type Centrifugal Pump. Specifications : Series : SCPP Series Type : End-Suction, Back-Pullout Type Centrifugal Pump Operating Range : Capacity : up to 380 m3/hr Head :  up to 150 mtr Pressure :  up to 15 kg/cm2 Size : 32 mm to 150 mm Speed : up to 3500 rpm Temp : up to 300 C M.O.C. : CI, CS, SS304 / 316, SS 304 L/316L, Alloy 20, Hast alloy B or C,CD4MCU, etc. Applications : Water Transfer, Hot & Cold Water, Cooling Tower, Thermic Fluid Boiler, Heat Exchanger, DM water, Steel Ind., Jet dyeing, Chemical process, Pharmaceutical Ind., Dyes & Pigments Ind., Circulation, Transfer, Petroleum Ind., Food Ind., Laminate Ind., Salt Ind.,  Sea Water, Fire fighting, Textile Id., Paper Ind., Ceramic Ind., Solvent Extraction, Solvent Transfer, Distillation etc.

Our company has a convenient and noncomplex payment procedure. Patrons can make payments through a method with they are comfortable. We are open to receiving payment online or offline. Our quality analysis system is headed by experienced quality auditors who check each and every product at different levels. Features : Long service life Good performance Maintenance free Application : Pressure boosting Water treatment Cooling systems

• Certification: CE Certified, ISO 9001:2008
• Application: Industrial
• Weight: 100-200kg, 200-300kg
• Voltage: 110V, 220V
• Power: 1-3kw, 3-6kw, 6-9kw
• Driven Type: Electric
• Warranty: 1year
• Country of Origin: India

• Usage: Water
• Capacity: Up to 1890 LPM
• Design Type: Standard
• Speed: 200-580 r/min
• Diameter: 25-185 mm
• Cooling Method: Air Cooled
• Motor Phase: Three Phase
• Power Source: Electric

• Brand Name: Radial Pumps,Radial Pumps
• Driven Type: Electric
• Application: Industrial
• Certification: CE Certified, ISO 9001:2008
• Type: Back Pull Out Pumps, Back Pull Out End Suction PUMP
• Warranty: 1year
• Country of Origin: India
• Model: ROP Series
• Pressure: Up to 5.5 Kg/cm2
• Capacity: Up to 1200 M3/hr
• Head: Up to 55 mtr
• Discharge Size: 25 mm to 300 mm
• Temperature: Up to 250°C
• Speed: Up to 3500 rpm

• Head: upto 100 mtrs.
• Capacity: upto 400cu.mtr/hr.
• RPM: 2900/1450
• Drive: Motor
• Shaft Seal: Gland/Mechanical Seal
• MOC: Cast Iron, Cast Steel, Stainless Steel & Bronze

Centrifugal Back Pull Out Pump are manufactured by us in compliance with DIN 24255 standards. The Flanges of the Centrifugal Back Pull Out Pump meet the DIN 2533 standards while the Drilling is as per ASA/BS. The submersible type Centrifugal Back Pull Out Pump do not need pump house and the cooling of the motor is done effectively by the water that flows around the casing. Applications : Fire Fighting For pumping Clear or Turbid Water upto 3000rpm Circulation & Systems in Industries Irrigation & Sprinkler System Booster service Pumping Liquids having Temperature in the range of 300C to 1000C

We manufacture and supply back pull out pumps, which are extensively used in air conditioning plants, power station, mine drainage, sprinkler systems fire fighting etc. These pumps are specially designed to perform heavy duty functions and work under high suction pressure conditions. Made from premium quality materials, these pumps are high in performance and have long lasting life.

more than 3mm corrosion allowance (cast iron) for extended use on corrosive applications. Back pull out construction allows rotating assembly to be withdrawn without disturbing the suction and delivery connections. One piece self vented foot mounted , center suction volute casing , single stage , closed / semi open dynamically balanced impeller. • flange drilling standards as per din 24255 / iso 2858 or as per customer’s requirement. • designed for 16 bar working pressure with optional casing for a working pressure of up to 20 bar. • special monoblock versions available on request. • heavy –duty, deep- grooved bearings with minimum 50,000 hours operating life under normal condition. (grease lubricated , oil lubrication available on request) • a robust and solid construction that guarantees long life even under high suction pressure conditions. • heavy –duty , stiff solid shaft design with low l3/d4 ratio ensures less than 0.05 mm shaft deflection at the seal face in all operating condition. This extends the seal life. • seal housing is constructed to accommodate different seal / gland designs, so as to meet the severe heavy-duty requirements. (standard is gland packing , seal version on special request) • excellent parts interchangeability reduces inventory levels for spare parts to a minimum. • special design for high temperature thermic fluid available on request. • motor or engine driven sets.   material of construction cast iron construction with en-8 shaft , ss-410 sleeve, gland packing and special material like wcb , cf-8 , cf-8m, alloy 20 , ss-304 , ss-316 fabricated etc on request applications for pumping clear / turbid water / chemicals & volatile liquids. air conditional plants, power station, mine drainage, sprinkle systems fire fighting, booster service, oils brine. operating range delivery size up to 250 mm, capacity up to 990 m3/hr, head up to 120 meters rpm 500 to 3600
