Balanced Seal Dealers

• Country of Origin: India
• Applications: Corrosive Chemicals, Hydrocarbons, General & Light Chemicals.
• Shaft Dia: 20 to 100 mm / 0.750 to 2.500 Inch
• Pressure: 25 Bars (max))
• Temperature: -45 to +180°C
• Velocity: Up to 20 m/sec

Multi Spring Reverse Pressure Balanced Seal MSRPB 50 Series is a multiple spring externally mounted reverse balanced seal with O ring as elastomer. Various seal face materials and elastomers can be offered for wide service application. This seal can also be used for corrosive services as the metallic components do not come in contact with liquid to be sealed. This seal can also be installed in double back to back arrangement as an internal seal. Even if barrier fluid pressure goes down this seal will not allow process fluid to mix with barrier fluid.   Seal Components/Face: Carbon / Ceramic Carbon / Silicon Carbide Silicon Carbide / Silicon Carbide Tungsten Carbide / Tungsten Carbide Secondary Seal : Elastomers, TCV Metal Parts: SS 304, SS 316, Hastelloy-C, Monel, Alloy-20   Seal Characteristics: Single Acting Reverse Balanced Outside Mounted Independent of Direction of Rotation

• Brand Name: Jain Seals
• Material: Steel
• Finishing: Polished
• Material Grade: SS316
• Shape: Round
• Condition: New
• Packaging Type: Carton Box
• Working Pressure: Upto 25 Bar
• Sealing Type: Multi Spring
• Specialities: Unbreakable, Heat Resistant, Good Quality, Fine Finish, Easy To Install
• Type: Multi Spring Mechanical Seal
• Working Temperature: Upto 25 Bar
• Shaft Diameter: 18 To 100 Mm
• Country of Origin: India
• Chemical Resistance: Yes
• Pressure (Bar): 20 Bar
• Temperature Range Deg C: -20 To 250
• I Deal In: New Only

• Country of Origin: India
• Size: Up to 200 Mm
• Faces Material: Carbon, Silicon, Tungsten Carbide
• Elastomer: Nitrile, NBR, Viton, EPDM, Aflas, Karlez, TCV, GFT, PTFE, FEP
• Hardware M.O.C: SS304, SS316, Hast-C, Alloy-20
• Pressure: Up to 10 Bar
• Temperature: -50° to 280° C
• Suitable Speed: Up to 6000 rpm
• Group: D-71/77

Multi Spring our D71 & D77 Group is widely used in Clear Lubricating , Light Hydrocarbon, Non Corrosive, Dirth, Petrochemicals, volatile liquids, General Chemicals, , lubricating liquids, toxic, Hazards, Petroleum Refinery, etc. . .

• Material: Stainless Steel
• Finishing: Polished
• Usage: Industrial Use
• Packaging Type: Carton Box
• Specialities: Good Quality
• Country of Origin: India
• Product Code: LB R23

LB R23 Multi Spring Reversed Balanced Seal that we are offering is an advanced mechanical component and is widely used in several pumps and hydraulic systems for sealing applications. A series of springs make sure the air-tight sealing while heavy duty applications. The springs have a high spring constant and therefore it remains intact and in place to completely seal the valve. The material of which LB R23 Multi Spring Reversed Balanced Seal is manufactured is worn and tear resistively responsible for the long working life of the product. Our clients can get this product in different specifications from us.

• Shaft Diameter: 19 mm to 190 mm
• Temperature: -20 to 280 C
• Pressure: 10 kg/cm2
• Speed: 4000 RPM
• Metal Parts: SS316, Hastelloy-C, Alloy 20
• O Ring: Elastomers
• Seal Faces: Carbon, SiC, Tung. Carbide

• Shape: Round
• Color: Grey
• Pressure: Up To 40 Kg/cm2
• Usage: Petrochemicals, General Chemicals, Oil Refiners, Food and Beverages
• Size (Inches): 0.5" to 6"
• Country of Origin: India
• Temp: -40° to 200° C

M.O.C of Secondary Seal According to Fluid & Temp. Various Hard & Soft Faces As Per Liquid. No need to maintain a step on Sleeve for balancing

• Thickness: 40-50mm
• Packaging Type: Carton Box
• Inner Diameter: 50mm
• Brand Name: Globe Star
• Color: Silver
• Finishing: Polished
• Warranty: 1 Year
• Country of Origin: India
• Material Grade: SS316l
• Suitable For: High Temperature
• Sealing Type: Mechanical
• Automation Grade: Automatic
• Chemical Resistance: Yes
• Working Temperature: -20-400
• Working Pressure: 25Bar
• Temperature Range Deg C: -20-400
• Color: Silver
• Type: Mud pump
• Certification: ISO 9001- 2015
• Material: CI,SS304,SS316
• Pump RPM [Speed]: 2900rpm /1440rpm

• Shape: Round
• Color: Silver
• Country of Origin: India
• Application: Industrial
• Style: Bellow Seal
• Material: Metal
• Function: Manual
• Hardness: Rigid

• Brand Name: STS
• Material: Stainless Steel
• Finishing: Polished
• Shape: Round
• Color: Silver & Black
• Usage: Gas Industry
• Packaging Type: Carton Box
• Specialities: Good Quality
• Country of Origin: India
• Pressure: 15 Kg/cm2
• Temperature: 280 Degree C
• Speed: 4500 RPM

• Seal Size: 025 to 0100
• Temperature Limit: -20° C to 180° C
• Pressure Limit: Up to 15 kg
• Seal Faces: Carbon, Sic, TC
• O Rings: Viton, PTFE
• Material of Constructions: SS316, SS304
• Application: High Vacuum, Corrosive and Clogging Type Liquids
• Features: Reverse Balanced, Externally Mounted

• Specialities: Easy To Install
• Type: Industrial Seals
• Brand Name: MATOS
• Material: SS
• Shape: Round
• Certification: ISO 9001:2015
• Condition: New
• Material Grade: Any
• Suitable For: Any
• Sealing Type: Mechanical
• Usage: Any
• Chemical Resistance: Yes

• Country of Origin: India
• Specialities: Good Quality, Fine Finish
• Certification: ISI Certified
• Usage: Industrial
• Shape: Round
• Material Grade: S.S 304, S.S 316.
• Finishing: Polished
• Pressure: 10 Bar
• Temperature: 20 Degree to +220 Degree
• Speed: 2900 RPM
• Secondary Seal: Viton, TTV, FKM, NBR, EPR, PTFE
• Service: Process Industries, Oil Refinery, Pharmaceutical, Distilleries, Paper & Pulp Industries etc
• Face Materials: Tungsten Carbide, Carbon, Silicon Carbide, Ceramic, Bronch

• Brand Name: Nandodyne
• Material: Stainless Steel
• Finishing: Polished
• Material Grade: S316
• Shape: Round
• Usage: Industrial
• Country of Origin: India
• Note: Shipping Charges Will Be Pay By Buyers

We are engaged in offering Multi Spring Reverse Balance Seal to our clients. Our range of all products is widely appreciated by our clients. Please note that the prices listed are subject to change based on the level of customization chosen for each product. Contact us directly for a personalized quote tailored to your specific requirements.

• Material: Stainless Steel
• Finishing: Polished
• Shape: Round
• Color: Silver & Black
• Condition: New
• Sealing Type: Mechanical
• Country of Origin: India
• Brand Name: Etannor

Model: E8MB- O Ring Type Multi Spring Balance Mechanical seals E8MTB- PTFE Wedge Type Multi Spring Balance Mechanical seals   Description: Single-end, multiple springs, Balanced Seal E8MB (O Ring) and E8MBT (PTFE Wedge), the independent direction of rotation, drive sleeve transmission. This component has a compact structure with a small axial dimension and equal force on the sealing surface. Their compact design makes them suitable for use in all types of Centrifugal pumps.

• Brand Name: Dormount
• Material: ALUMIINUM 6063
• Shape: STANDARD
• Country of Origin: India
• Condition: New
• Packaging Type: POLY PACKING
• Door Thickness: more than 30 mm
• Fixing Type: CONSEALED

A spring-loaded mechanism, ensures easy door operation & effective sealing when closed.    Spring-loaded mechanism lifts the seal clear of the floor as soon as the door is opened by a few millimeters.Self-leveling on uneven floors, seal height can be adjusted independently of fixing screws.MOC : Pure aluminium ingot, i.e. Alumimium 6063.   Gasket are silicon food grade as per WHO, USFDA, CGMP,   NABH .   Quick and hassle free installation.   No-maintenance .   Cost effective.       Tested upto 10,00,000 cycles. Additional Information: Item Code: DSIII Production Capacity: 10000 Delivery Time: IMMEGIATE Packaging Details: EVERY DROP SEAL ALONG WITH SCREWS PLY PACKED IN AND THEN SUMMED UP IN A CARTON BOX

• Material: Stainless Steel
• Finishing: Polished
• Shape: Round
• Condition: New
• Automation Grade: Automatic
• Usage: Industrial
• Sealing Type: Mechanical
• Specialities: Unbreakable, Heat Resistant, Good Quality, Fine Finish, Easy To Install
• Type: Industrial Seals
• Country of Origin: India
• Brand Name: Elite

• Material: Metal
• Finishing: Polished
• Color: Silver
• Packaging Type: Carton Box
• Warranty: 1 Year
• Specialities: Good Quality, Fine Finish

Standard balanced single cartridge seal with protected spring and pentagonal drive. The protected-spring design makes this seal suitable for a wide range of applications: pumps conveying slurries for the sugar industry, paper industry, extracting industry, for heavy industries. All simple assemblies possible (cartridge, tandem, quench, etc.). Standard balanced mechanical seal with protected spring and pentagonal drive. Imperial version available.   Friction faces :  Friction faces Carbon impregnated resin (B1) Silicon carbide (U6). For the most difficult cases use friction faces made of nickel-tungsten carbide (U2). Supplied with FKM seals.   Fluids : All corrosive, abrasive and slightly clogging fluids.   Material : Centrifugal pumps

• Pressure: 8 Bars(max)
• Type: Multi Spring, Balance, Externally Mounted
• Shaft Diameter: 16 To 70 Mm
• Country of Origin: India
• Temperature: Up To 120°C
• Velocity: Up To 20 M/sec / 3000 R.p.m
• Usage: Chemical & Hot Oil Pumps
• Seal Ring Face: Carbon, SiC & GFT
• Seat Face: Ceramic & SiC
• Elastomer: Viton, EPDM, TTV, FEP & FFKM
• MOC:: SS 316 / SS 304

• Size: 0.5 inch To 4 inch
• Pressure: Vacuum To 25kg/cm2
• Temp.: -40 Degree To 200 Degree C
• Application: Corrosive Chemicals, Hydrocarbon, Abrasive Services
• MOC: Of Secondary Seal According To Fluid & Temp. Various Hard & Soft Faces As Per Liquid
• Use with: Independent Direction Of Rotation(outside Mounted)

• Size: 4inch, 5inch
• Type: Balanced Seal
• Material: Metal
• Shape: Round
• Thickness: 10-15mm, 5-10mm
• Color: Silver
• Feature: Easy To Fit, Fine Finish
• Temperature :: -60°c to 260°c

Das Engineering Works is a leading multi-spring balanced seal manufacturer. Our seals are made to be as dependable and effective as possible. Seals with several spring balances are perfect for high-pressure sealing applications. We offer seals that are appropriate for several industry applications. Minimal leakage is guaranteed by the design of every seal. Our seals are designed to withstand strong chemicals and extreme conditions. We make use of premium materials to ensure durability. Installing and maintaining our multi-spring balanced seals is a simple task. They offer superior resistance to rust and wear. At Das Engineering Works, client happiness is our priority. To satisfy specific operating demands, we provide specialised solutions. Every product is guaranteed to satisfy industry standards by our staff. Our main goal is to provide seals with exceptional performance. Because of our reasonable price, you will receive value for your money. Put your trust in Das Engineering Works, the maker of multi-spring balanced seals. Reach out to us for trustworthy sealing services. Allow us to supply seals that improve your equipment's efficiency. The food processing, pharmaceutical, and petrochemical sectors are the perfect fit for our seals. Our main goal is to create seals that can withstand harsh environments. Strict quality tests are performed on every seal to ensure guaranteed functionality. We offer specialised sealing solutions depending on the demands of particular industries. When looking for cutting-edge multi-spring balanced seals, pick Das Engineering Works.
