Bar Threading Machine Dealers

• Brand Name: Unicorn
• Model: Metric UNI 600
• Suitable Bar Diameter: 16-40mm
• Thread Pitch: 1.75, 2.0, 2.5, 3.0
• Thread Angle: 75 Degree or 60 Degree, Helix Angle
• Motor: 3 kw
• main shaft speed: 40-62r/min
• Max Rolling Length: 100mm
• Packing: iron frame and carton box
• NW/GW: 380KG, 420 KG

• Usage/application: Used to Cut Threads On the Ends of Metal Bars
• Machine Type: Fully Automatic
• Discharging Volume: 3500 VPM
• Suitable Bar Diameter: 16-40mm
• Motor: 3kw
• Max Rolling Length: 10omm
• Thread Angle: 70* or 6o0*,Helix Angle

One of the foremost Suppliers, we are a known for the exceptional Rod Bar Threading Machine in the market. Our dedicated staff and quality auditors take care of the complete manufacturing of the products, even the raw material sourced at the initial stages are checked on the grounds of quality.

• Automatic Grade: Automatic
• Voltage: 380-440 V
• Frequency: 50-60 Hz
• Phase: Three Phase
• Body Material: MS
• Power Source: Electric

• Pipe Internal: 300 / 120 mm
• Pipe Lenght Minimum: 250 mm

Threading by removable of Material on both ends (internal thread on one end & external thread on other end) by planetary rotating carbide saw.

• Color: Blue & Grey
• Condition: New
• Automatic Grade: Automatic
• Warranty: 5years
• Power: 3 Kw
• Voltage: 220 V
• Material: Mild Steel
• Usage/Application: Construction
• Capacity: 500 Kg
• Frequency: 50 Hz
• Packaging Details: Wooden packaging (on request)

• Color: Blue

Industrial Machinery offer well designed Bar Threading Machine in India and abroad. The Bar Threading Machine is use to cut the external threads on the bar with the help of Tangential chaser. Bar Thread cutting Chaser is use as a cutter in machine. Bar remain still, Die-head rotates. Different types of threads can be cut on the bar such as BSW, NPT, UNF, METRIC, UNC, ACME, BSF Threads etc. Such a company will offer you the amenity of customization, wherein the bar thread cutting machinery will be designed and fabricated as per your specifications. These can vary on aspects such as saddle movement, range of spindle speed, capacity , the number of units a it can produce in an hour and the requirement of power to operate the machinery. As is the case with most bar threading machinery, this works with sub parts such as saddles, aprons and beds. These are all designed and fitted in such a manner that they provide hassle free operation and require minimal attention, post purchase. This not only ensures actual value for money, but also reduces the time spent on regular maintenance and servicing. Range of IMC Bar Threading Die-Head.1/4" to 1" do/-3/8" to 1.1/2" do/-1/2" to 2.1/2" do/- Bar Threading Machine Specifications   MODEL 1/4" TO 1" (6MM to 25MM)   (BED TYPE)   3/8" TO 1.1/2" (10MM to 40MM)   (BED TYPE)   1/2" TO 2.1/2" (12MM to 65MM)   (BED TYPE)   Saddle Movement 10" 13" 22" Spindle Speed Range 75-140 75 -140 45 - 90 Number of Spindle Speed 2 2 2 Threading Capacity 1/4" to 1" 3/8" to 1.1/2" 1/2" to 2.1/2" Production per Hour 60-80 60-80 70-90 H.P. Required 3 H.P. 3 H.P. 7.5 H.P. Lead Screw Optional Optional Optional Weight (KG) Approx. 500 550 990

• Weight: 100-1000kg
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw
• Driven Type: Electric
• Warranty: 1year

Bar Threading Machine which is manufactured from Industrial Machinery Corporation is made of high quality material and required less maintenance. The Bar threading machine can be availed in two varieties – Bed type and Pillar type, while there are four specifications in which these machines can be manufactured. These specifications vary on the basis of things like saddle movement, spindle speed range, capacity, production per hour and requirement of power. Bar Threading Machine which is manufactured from Industrial Machinery Corporation is made of high quality material and required less maintenance. The Bar threading machine can be availed in two varieties – Bed type and Pillar type, while there are four specifications in which these machines can be manufactured. These specifications vary on the basis of things like saddle movement, spindle speed range, capacity, production per hour and requirement of power. Being in the business of industrial machine producing for over 7 years, what we would advise all of the purchasers with respect to Bar Threading Machine is to have a point by point discussion on what are the customization’s that you really require in your Bar Threading Machine.What’s more, to get the Bar Threading Machine according to your redid necessities, it is constantly best to purchase this machine from an accomplished Bar Threading Machine in India and when it happens to best, there is no name in front of industrial machinery corporation. With its manufacturing unit situated in Ludhiana, we have over seven years of involvement in making best quality Bar Threading Machine. We have been serving every one of our customers with best of industrial threading machines and not just this; we have been giving excellent after deals benefit, in the event that, any of our machines face any technical issue which is extremely rare. We have from time to time, demonstrated that the Bar Threading Machine worked by us is the best in the lot and the explanation for this is we make this Bar Threading Machine with international guidelines and keeps all the international trends and parameters. Bar Threading Machine is used for Cutting External Thread on Bars by Chasing method. HSS Tangential Chasers are used as cutters. The bar remains stationery and Die Head rotates. Matric, BSP, BSPT, NPT, UNF,UNC, BSW, Acme Threads B.S.F etc. threads can be cut on this machine depending upon Base Head Stock Saddle Bed or Pillar Type Clamping Vice Die Head. BAR THREADING MACHINE is designed to give maximum efficiency and reliable performance under the most severe conditions of service with minimum maintenance cost. All the necessary requirements are combined in this model to from the basic fundamentals of correct threading. All the gears are made of case hardened steel with extra large face with and tooth thickness and cut on hobbing machine for noiseless operation even at high speed. Naturally the are built with high standards of workmanship, material and quality so closely associated with COMPANY TRADITION. DESIGN & WORKMANSHIP: The Industrial Machinery Corporation Bar threading machines are designed to produce quality threads within the tolerance for which they were intended. HEAD STOCK: A heavy duty geared Head Box is of best quality casting providing support to the spindle bearings. The box is of gear type, lubricated, fitted with three extra heavy duty bearings. THE BED: The bed is pillar type having two pillars made of best quality steel nicely finished & duly hard chrome plated in the most modern hard chrome plating unit. THE SADDLE: The Saddle is fitted on two pillars very precisely. It runs on pillars very smoothly and accurately to the Head Stock alignment. The APRON: The apron gives movement to the saddle with head transfer along with pillars through steel rack and pinion arrangements. It’s all gears are made of best quality steel. VICE JAWS: The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy duty box type vice. The jaws are heat treated. The movements of jaws are controlled by a screw on the saddle. Range of IMC Threading Die Heads.1/4″ to 1″ do/-3/8″ to 1.1/2″ do/-1/2″ to 2.1/2″ do/-

We have latest machines and cutting-edge technology thus, we ensure that the raw materials used are as per set standards and meet the international norms as well. We deliver only quality products, manufactured using the raw material. We maintain proper schedules for the delivery of bulk or urgent consignments so as to deliver the range in set time and gain utmost customer satisfaction.   Design : The National Cutting Tool Bar threading machines are designed to produce quality threads within the tolerance for which they were intended. Head Stock : A heavy duty geared Head Box is of best quality casting providing support to the spindle bearings. The box is of gear type, lubricated, and fitted with three extra heavy duty bearings. The Bed : The bed is pillar type having two pillars made of best quality steel nicely finished & duly hard chrome plated in the most modern hard chrome plating unit. The Saddle : The Saddle is fitted on two pillars very precisely. It runs on pillars very smoothly and accurately to the Head Stock alignment. The Apron : The apron gives movement to the saddle with head transfer along with pillars through steel rack and pinion arrangements. It's all gears are made of best quality steel. Vice Jaws : The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy duty box type vice. The jaws are heat treated. The movements of jaws are controlled by a screw on the saddle. Range 3/8'' to 1.12'' do/- 1/2'' to 2 .1/2" do/-

• Automatic Grade: Semi-Automatic
• Weight: 430kg
• Voltage: 415 volt
• Power: 5 hp
• Model Name/Number: SSI-BT-40
• Capacity: 8mm to 40mm
• Phase Type: three phase
• Motor Power: 5 hp three phase

• Brand Name: imported
• Color: Grey
• Condition: New
• Automatic Grade: Fully Automatic
• Power: 1-3kw
• Application: threaded post
• Material: ms

Pin threading machine automatic machine for the production of threaded studs for earrings or rolled. Rod diameter from 0.6 to 1.5 mm. The machine has the function of achieving rolled pins and threade employable in jewelery sector ( eg for closures of earrings). Machine part from wire that is automatically loaded, perform the rolling, cutting and unloading of the finished product into container. E also installs the device issuing the stamp. The machine allows to realize threaded pins through the use of special wheels rolling without generating any waste of material. The machine settings by means of mechanical and functional ( plc)| allows a fast and easy variation of the working parameters. The machine is also equipped with automatic stroke counter set in the control panel. dimensions: 470x390, h=1150 weight: 85kg productivity: 45piecesmin size to work pin diameter from: 0.6 mm to 1.5 mm
