Basket Centrifuges Dealers

• Capacity: 1000 gms
• Model Name/Number: LI-LE-547
• Material: Stainless Steel

• Type: Automatic
• Certification: CE Certified
• Voltage: 380V
• Power: 3-6kw
• Warranty: 1 Year
• Driven: Electric
• After-Sales Service Provided: Spare Parts

Application :Rotofilt Vertical Basket Centrifuge is ideally suited for processing Atrazine, vegetable extracts, quinine Sulphate, hydrazine, antibiotics, citric acid, pentaerythritol, etc.Design Features : Design and connection as per IS/API/BS. 3 point / 4 Point anti-vibration suspension, alternatively. VISCO damper suspension. Gas tight up to 0.04 bars over pressure. With lip or glide ring seals Cake Removal by Bag lifting/ Manual Scrapping/ Pneumatic top discharge / or Bottom discharge. Grease lubricated bearings. Oil lubrication for demanding use in chemical industry. Hydraulic Variable speed drive for direct coupling, through V-Belts Through cake wash Discharge with negligible crystal breakage Residual heel removal Optional : Automatic and Manual operation with either micro processor or pneumatic controller with the exception of unloading operation. Explosion Proofing and safety devices. Through the floor construction. Pneumatic drive for the cover and scraper unit for use in a clean Room. Materials of Construction :Standard Machines: Contact parts in Stainless steel, rubber-lined with non-coatable parts in Hastelloy C. Other materials on request.Working Principle Batch operation Variable speeds for filling, spinning, washing and scraping Feed controlled by filling valve through feed pipe or distribution funnel Filling by gravity or pump or by rotating cone to affect gentle acceleration of suspension. Basket filling monitored by filling level controller Intensive cake washing with one or more fluids after spinning Separation of mother liquor from wash liquor by valves Cake discharge.

• Certification: CE Certified, ISO 9001:2008
• Weight: 100-200kg, 200-300kg, 300-400kg, 400-500kg, 500-600kg, 600-700kg, 700-800kg, 800-900kg, 900-1000kg
• Color: Blue, Brown, Grey, LIght White, White
• Voltage: 110V, 220V, 380V
• Condition: New, Used
• Automatic Grade: Automatic, Fully Automatic, Semi Automatic
• Power: 1-3kw, 12-15kw, 15-18Kw, 18-21Kw, 21-24Kw, 3-6kw, 6-9kw, 9-12kw
• Warranty: 1 Year, 2 Years, 5 Years
• Driven: Electric

• Country of Origin: Made in India
• Voltage: 220 V
• Features: Seamless Finish,Durability
• Capacity: 50 kg/Batch
• Speed: 1260 RPM
• Model: FFS 36TL
• Size/Dimension: 64 inch
• Material: Mild Steel
• Frequency: 50 Hz
• Usage/Application: Industrial

The horizontally arranged MBE CMTI vibrating Screen Basket Centrifuge, the material to be dewatered is fed into the inlet cone through the feed pipe. While flowing through the inlet cone, the material is slowly accelerated and uniformly distributed on the circumference of the slot type Screen Basket. The rotating basket is made to perform axial vibration by a vibrator unit with unbalanced drive.Due to the combination of Centrifugal & Vibratory components, these axial vibrations have the material transported inside the conical screen basket along the inclined basket will. This movement entails a reduced friction between the feed & basket wall.The Centrifuge is mounted on Rubber Buffers for preventing the transmission of vibrations to the foundation. Vibration may occur as a result of fluctuating feed rates.The horizontal design permits fitting the drive components to the outside of the machine housing. This means that all drive parts and consequently the basket inside the machine housing is easily accessible. The one piece Screen Basket and the inlet cone have been fastened to the Basket Shaft in an overhung position by means of the load bearing ring. This ensures easy assembly & dismantling. The vibrator with out of balance weight is accommodated in the bearing housing of the basket shaft. The complete drive mechanism has been suspended by the guide linkage spring. The axial vibrations are transmitted to the screen basket direct on the basket shaft and the load bearing ring without resilient element having been interposed. This results in a very simple & robust design. The vibrating mass is made up of the Screen Basket, Inlet cone, Load Bearing Ring & Basket Shaft as well as of the drive mechanism. It exceeds by further mass of material accumulating. Due to this fact and the horizontal arrangement, the centrifuge is insensitive towards the overload or fluctuating feed rates. The Screen Basket & Vibrator are each driven by a standard motor and V Belt.The MBE Basket Centrifuge is particularly suitable for continuous separation of solid/ liquid mixtures of grainy bulk materials. The standardized design of mechanical & Centrifugal components enables optimum adaption to the specific requirement. Details of this standardized design, of the dewatering process & design criterion have been given on the following pages. Coal Fines • Fine Tailings • Coarse Slurry • Washed Coal & middling • Fine Gravel • Sand • Potash dissolving residue

• Capacity: 1000 ltr
• Brand/Make: Jagtap
• Material: SS

Basket Centrifuge facilitates separating the solids and liquids of a solution by centrifugal force using a filter media (usually cloth) mounted over supporting mesh of the rotating basket.DU's Lab Basket Centrifuges (desktop type) are invaluable for Process Automation, Product Formulation, Process Research, Product Modeling, and Chemical Compound Washing etc. for R&D laboratory. Wide range of extraction quantity: upto 1000 gms, Compact, portable, desktop and lightweight design, Use of high quality material (SS 316) for all wetted parts, High centrifugal acceleration (Max. 1050g)variable to ensure quick and effective filtration.

We offer Vertical basket the Vertical Basket Centrifuge. Vertical Basket The Vertical Basket Centrifuge The Vertical Basket Centrifuge operates under a discontinuous filtration process and is well suited to the efficient separation of Pharmaceutical products and of fine and bulk chemicals. This type of centrifuge is used with small batch sizes and where products are changed frequently with low process costs, this enables versatile usage for processing numerous products with one centrifuge There is no crystal breakage, as the peeling is performed at the reduced speed. They can handle freely and none freely filtering slurries with equal facility. Rotofilt Vertical Basket centrifuges are built by making it easy to load from the top so that solids can then be extracted with knife or by hand. The equipment has been developed to operate the centrifuge with the exact same filter cake thickness as if it were a production size machine to enable gives a precise scale for each and every process from beginning to end. Rotofilt Vertical Basket Centrifuge is ideally suited of: Amino acids, benzoic acid, benzene, hexachloride, calcium hypo chloride hexachlorocyclohexane insulin, potassium bisulphate, sodium perborate, penicillin, sulphur, starch, etc.

We offer basket centrifuge. We manufacture basket centrifuge up to 60" size, max. Rpm 1400, applications - stp, etp anywhere in solid to liquid separation.
