Beam Saw Dealers

  Higher production out-put with excellent cutting of multiple panels, made easy with a high level of computer control.     Advanced saw carriage with high feed rate driven by rack / pinion that ensures high cutting accuracy. The roust gripers ensure perfect panel clamping without damaging the material surface. The aligner sliding on guides ensures precision on cross-way cuts. A uniform holding pneumatic clamping beam ensuring synchronized cylinder actuation at both ends. Automatic device for the optimisation of the blade projection in relation to any material thickness. Equipped with infeed air floating tables.

• * Maximum Cutting Length: 2680mm
• * Maximum Cutting Thickness: 76mm
• * Diameter of Main Saw Blade: Ø350mm
• * Diameter of Main Saw Spindle: Ø30mm
• * Rotation speed of scoring saw blade: 4800 RPM
• * Diameter of Scoring Saw Blade: Ø180mm
• * Diameter of Scoring Saw Spindle: Ø30mm
• * Rotation Speed of Main Saw Blade: 6500 RPM
• * Forward Speed of Saw Carriage: 0-37 m/ min
• * Backward Speed of Saw Carriage: 45 m/min
• * Drive motor of Main Saw Blade: 13 HP
• * Drive Motor of Saw Carriage: 2 HP
• * Pneumatic Pressure: 5-6 KG/cm2
• * Table Height from Floor: 900mm
• * Net Weight: 2760 KG
• * Overall Dimensions (L x W x H): 5230 x 3950 x 1700mm

• Brand Name: Felder
• Usage/Application: Industrial
• Material: MS
• Cutting Length: 4300 mm
• Automation Grade: Automatic
• Saw Blade Diameter: 320 mm
• Motor Power: 10 HP
• Model Number: Kappa Classic Format 4

Salient Features :   Advanced saw carriage with high feed rate driven by rack / pinion that ensures high cutting accuracy. The roust gripers ensure perfect panel clamping without damaging the material surface. The aligner sliding on guides ensures precision on cross-way cuts. A uniform holding pneumatic clamping beam ensuring synchronized cylinder actuation at both ends. Automatic device for the optimisation of the blade projection in relation to any material thickness. Equipped with infeed air floating tables.

• MODEL: NS - 252
• Maximum Cutting Height: 75 mm
• Maximum Cutting Length: 3 mtrs
• Maximum Cutting Width: 3 mtrs
• Diameter of Main Saw Blade: 350 mm
• Bore of Main Saw Blade: 30 mm
• Diameter of Scoring Saw Blade: 150 mm
• Bore of Scoring Saw Blade: 45 mm
• No of Stopper: 4 pcs
• Mode of Measurement: Digital Readout
• Motor Power of Main Saw Blade: 5 hp
• Motor Power of Scoring Saw Blade: 1 hp
• Feed motor power: 1/2 hp
• Air Table Motor Power: 1/2 hp
• Table Type: Air Table
• Compressed Air Required: 8 bar

• MODEL: NS - 252
• Maximum Cutting Height: 75 mm
• Maximum Cutting Length: 3 mtrs
• Maximum Cutting Width: 3 mtrs
• Diameter of Main Saw Blade: 350 mm
• Bore of Main Saw Blade: 30 mm
• Diameter of Scoring Saw Blade: 150 mm
• Bore of Scoring Saw Blade: 45 mm
• No of Stopper: 4 pcs
• Mode of Measurement: Digital Readout
• Motor Power of Main Saw Blade: 5 hp
• Motor Power of Scoring Saw Blade: 1 hp
• Feed motor power: 1/2 hp
• Air Table Motor Power: 1/2 hp
• Table Type: Air Table
• Compressed Air Required: 8 bar

Higher production output with excellent cutting of multiple panels is made easy with this cost effective manual Beam saws.

• Brand Name: Gorsan
• Country of Origin: Made in India
• Voltage: 380 V
• Usage/Application: Industrial
• Automation Grade: Automatic
• Weight.: 5500 kg
• Main Saw Motor Power: 18.5 kW
• Scoring Saw Motor Power: 2.2 kW
• Frequency: 50 Hz
• Air Compression: 6 Bar
• Air Capacity: 150 Litre/min
• Main Speed Of Dust Collection: 26 m/s
• Model Number: GB 330 G Prime

• Maximum Cutting Length: 2680mm
• Rotation speed of scoring saw blade: 4800 RPM

The optimal high Cutting Capacity and advanced features at an exceptional price. Class leading performance achieved through pioneering technology define the automatic Panel Saw. Quality and Reliability are second to non, making this the saw you can count on. • The Machine frame made from welded quality steel at low temperature, aged treatment and precisely machined, ensuring a stable and reliable performance. • The Saw carriage adopts imported superior straight-line guide way, high accuracy, wear resistance, self-cleaning. • The Saw Carriage of Sandeep Beam Saws is driven by an imported power torque reducer. • The Pressure Beam adopts sway bar synchronous design to guarantee the pressure beam synchronous elevation, ensuring no panel excursion. • The Machine is designed with Multiple Positioning Fence. • Emergency Stop Device guarantees the safety of people and machine.

Salient Features :   Advanced saw carriage with high feed rate driven by rack / pinion and guided on hard guide rods that ensures high cutting accuracy Precision saw stroke control by sensor A uniform holding pneumatic clamping beam ensuring synchronized cylinder actuation at both ends. Equipped with infeed air floting tables

• Speed: 3500/6000/8000/10000 Rpm
• Power: 1 HP
• Brand Name: SCM Italy
• Model Name/Number: SKU : STAR-2.9HS(1360736)
• Usage/Application: Industrial
• Cutting height: 60 MM
• Blades feed speed : 10 to 45 m/min
• Motor power : 7,5 HP
• Blade diameter: 290 x 4,2 MM
•  Weight : 2300 KG
• Frequency: 50Hz

• Motor Power: 17.38 KW
• Cutting Speed: 16/20/24 M/min
• Net Weight: 3200 Kg
• Main saw speed: 4500rpm
• Max. panel thickness: 75 Mm
• Scoring saw speed: 6050rpm
• Max. panel length: 3850 Mm
• Main saw blade diameter: 350d X 30d Mm
• Saw motor power: 11 Kw
• Driver motor power: 1.5 Kw
• Country of Origin: India
• Type: Beam Saw
• Application: Industrial

• Feed Speed: 5-50m/min
• Maximum Cutting Length: 2600mm
• Maximum Cutting Depth: 100mm
• Main Blade Speed: 3600(50Hz) / 4300(60Hz)
• Main Sawblade Motor: 15HP (18HP option)
• High Pressure Blower Motor: 3HP

• Brand Name: Select
• Rated Power: 25.2kw-27.7kw
• Country of Origin: Made in India
• Voltage: 440 V
• Cutting Length: 2700-3300mm
• Size/Dimension: 5200 X 5300 X 1750mm
• Saw Blade Size: 405mm
• Automation Grade: Automatic
• Phase: Three Phase
• Compressed Air Requirement: 5-7kg/cm2
• Main Saw Motor: 16kw-18.5kw
• Speed Saw Carriage: 0-100m/min
• Frequency: 50 Hz

• Usage/Application: Industrial
• Size/Dimension: 6630 x 4110 x 1620 Mm
• Saw Blade Size: 350d x 30d Mm
• Operating System: Touch Display
•  :
