Bed Milling Machine Dealers

• Table Size: 5000 X 1500 mm
• X travel: 6000 mm
• Y travel: 2500 mm

• Brand Name: Butler Elgamill
• Condition: Used

butler elgamill cs 10 bed milling   weare a trusted importer and trader that offers a wide range of used butler elgamill cs 10 bed milling our offered machines are used in many industrial applications. ourrange of product is sternly verified on many parameters before delivering. weare offering these machines in standard specifications. we provide our range ofproducts to our clients ate economical price in the market.   description: machine type: bed milling machine make: butler elgamill machine model: cs 10   technical specifications:  table size  5000 mm x 1200 mm  long travel  4300 mm  vertical  travel  1300 mm  cross traverse  1300 mm  spindle power  15 hp  speeds  30 to 2080 rpm  feed rate  6-500 mm/min                 buy used butler  elgamill cs 10 bed milling in verygood working condition at a very competitive price.

• MAKE: SCHMAN
• Price: Rs. 9009

We are supported by a team of professionals who ensure that the offered lot is prepared using the best quality raw material. Also, they confirm that the material is sourced from the certified places. Wide distribution network, exceptional connectivity, reliable transportation facilities are some of the attributes that help us in delivering the goods on time. Features : Precision engineered User-friendly & energy-efficient High Productivity BED MILLING. make : SACHMAN.  Table size / tavola : 560 x 2000 mm. Longitudinal travel : 1800 mm. Trasversal travel : 775 mm. Vertical travel: 990 mm.  weight : 6500 Kg.

• Type: CNC Bed Type Milling Machine-KNC-U1000
• Country of Origin: Korea
• Manufacturer: KIHEUNG
• Model: KNC-U1000
• Stock-no.: S2018010801

Description:- 1)U1000 is designed for heavy machining and variety sized parts! 2)it can support work piece up to 13,000kg and milling performances, power 42kw and torque 1636Nm. 3)For the high accuracy, cross Y-axis ball screw has the internal oil cooling system. 4)For the perfect movement cross Y-axis, there is the box way saddle with anti-friction material(turcite or biplast). 5)For the no "Ram drooping" of Y-axis 1250mm, there are the combination of box way design, INA steel way on the column and INA roller shoes on the saddle. 6)For the smooth movement of vertical Z-axis, there are the hydraulic cylinder weight balance with French Olaer accumulator and anti-friction material(turcite or biplast). 7)LM ball screw support system with the ball screw vibration absorber can make vibration-free running, noise reduction and also the no accuracy deformation. 7)Together with the wide choice of heads(vertical, A2, A4 and orthogonal etc..) and accessories(4th axis rotary table, sub angle table and special head change station etc..) available, makes this machine reliable and suitable for a variety of applications.

Make : jabre bed size : 2000 x 560 mm longitudinal travel (x) : 1800 mm cross travel (y) : 700 mm vertical travel (z) : 6000 mm with huron iso 50 milling head which can work veertical,horizontally, universally pendant controlled photos attached awaiting for your response.

• Brand: Butler HNC 29/5
• Model Name/Number: HNC 29/5
• Controller: HEIDENHAIN TNC 145
• Automation Grade: CONTROLLER :HEIDENHAIN TNC145
• Brand/Make: Butler HNC 29/5
• Product Type: BUTLER CNC Bed Mill ELGAMILL

• Condition: Used Machines
• Warranty: Paid Warranty
• Specialities: Eco-friendly
• Advantage: Easy operation

• Table size: 1525x320mm,1400x400mm,2000×400

Milling machine plays an important role in automobile and aerospace industries. It is preferred for its adaptability in applying in different working atmospheres. It stays an efficient workshop tool to support some of the most demanding and challenging machining requirements. Considering these factors We have designed bed type mills, which is ideal for continuous milling applications. It is designed with sliding table which is mounted on the machine bed and the depth of cutting can be obtained as per the requirement based on adjusting the spindle. There are 3 different types of tool with exclusive specifications.

• Type: Bed Milling Machine
• Certification: CE Certified, ISO 9001:2008
• Color: Brown, Grey, Light White
• Voltage: 110V, 220V, 380V, 440V
• Condition: New, Used
• Power: 1-2kw, 1-3kw, 10-12kw, 2-4kw, 3-6kw, 4-6kw, 6-8kw, 6-9kw, 8-10kw, 9-12kw
• Driven Type: Electric, Hydraulic, Mechanical
• Warranty: 2years
• Weight: 10-20kg, 20-30kg, 30-40kg, 40-50kg, 50-60kg, 60-70kg, 70-80kg, 80-90kg, 90-100kg
• Feature: Durable, Easy To Use, Fine Finished, Flawless Functioning, High Performance, Reliable, Rust Proof
• Application: Home Use, Industry Use, Office Use
• Automation Grade: Automatic, Fully Automatic, Manual, Semi Automatic

TR Model  X Axis: 2500 - 3500 mmY Axis: 1400 mmZ Axis: 1200 mmAutomatic indexing head: 28kw

• Spindle Motor: 5HP
• Spindle Speed: 5000RPM (60Hz)
• Model Name/Number: IB 800
• Brand: S&T
• Spindle taper: NST#40
• Machine Condition: New
• X/Y/Z travel: 850/500/450mm
• Max. table load: 500kgs
• Table size: 1270 x 305mm
• Coolant pump: 1/6HP

• Phase: Three Phase
• Brand: PAMA
• Model Name/Number: SpeedMill
• Brand/Make: PAMA
• Material: Mild Steel
• Layout: Horizontal
• Controller: Fanuc / Siemens / Heidenhain
• Automation Grade: Automatic, CNC

• Weight: 2,350.00 Kg
• Brand: S&T
• Variable Speed: 75 - 42000 rpm
• Spindle Travel: 127 mm
• Longitudinal: 1020 mm
• Vertical: 510 mm
• Cross: 510 mm
• Infinitely Variable Speed: 3.7 kW, 3PH
• Spindle Nose To Table Surface: 160 - 630 mm
• Swivel Angle To Right Left: 90°
• Features: high processing efficiency and high-accuracy machining, high speed and high-precision design mode.

FEATURES:- MEEHANITE CAST IRON CONSTRUCTION- RECTANGULAR GUIDEWAYS Y, Z� WITH HIGH RIGIDITY- HARDENED AND ROUND TABLE SURFACE- HEADSTOCK SIWVELS �30�- INFINITELY VARIABLE SPEED

CME CNC Bed Mill Serial No. 03 – 106Year of manufacture 1996 approx.Spindle taper 50 ISO/DIN 69871Table size, working area 2200 x 850Main motor 22 kw 30 hpSpindle speeds 3000 rpmRange of speeds 50 to 3000 rpmNumber of feeds 0 to 4000 mm – minFeed rates:- Rapid 10 m – minTraverse:Cross Y 900 (3.5 kw)X long 2000 (5.7 kw)Z vert 900 (5.7 kw)Accessories:4th axis Seymour Eng.Machine CME BF 0316" Ø 3 jaw.Weight of machine 16,000 kgMax. table load 5,700 kgControl Heidenhain 42630 ATCPositioning ± 0.01 mmRepeatability ± 0.01 mm

Bed milling machine Indigenously designed & manufactured patterns & high quality FG32 grade castings, Linear motion Guideways and C3 class ballscrews.

Features   MEEHANITE Cast -Iron Construction. Rectangular Guideways y.z With High Rigidity. Hardended And Ground Table Surface. Haedstock Swivels +30. Infinitely Variable Speed.

• Country of Origin: Made in India
• Material: Mild Steel
• Layout: Horizontal
• Automation Grade: Automatic
• Usage: Industrial
• Size: 6 X 6 Feet

Bed Milling Machine, machining centre spindle units, gear spindle
