Boiler Bed Material Dealers

REFRACTORY BED MATERIAL. IS 8 & IS 6 composition with refractory silica sand and other minerals. Generally used in FBC & CFBC boilers. Also called as boiler sand or bed materials. Our Refractory Bed Material of Low Ferric High Temperature product, is processed from selected super heat duty refractory aggregates of moderate alumina contents and of highly dense texture. This very special Bed Material of Refractory Aggregates fired at a temperature of 1400 Centigrade has many special characteristics that make it a perfect material for obtaining smooth and perfect fluidization in Fluidized Bed Combustion boilers with high economy of operations.   Special Characteristics : Fully Screened Material with Accurately Controlled Particle Size Distribution Free From Dust/ Fine & Over Sized Particles Highly Resistant Material Against Clinker Formation Perfect Product For Obtaining Smooth Fluidized Action Exceptional Chemical Purity with Low Alkali and Low Iron Contents High I.D.T. (Initial Deformation Temperature) No Free Iron Particles - Passed Through Iron Separators Perfectly Controlled Particle Density and Bulk Density   BED MATERIAL SPECIFICATIONS FOR FBC BOILER CHEMICAL PROPERTIES : Alumina as Al2O3 : 30% - 40% Silica as SiO2 : 50-60% Max. Alkalies Na2O + K2O : Less Than 1% Iron as Fe2O3 : Less Than 2.5% Titanium Oxide TiO : Less Than 1%   PHYSICAL PROPERTIES : Particle Density : 2.00 gm/cc Bulk Density : 1000-1100 kg/m³ Initial Deformation Temperature : > 1300° C Maximum Particle Size : 2.80 mm Minimum Particle Size : 0.85 mm   Note : Other Sizes also available on Request

• Packaging Size: 50 Kg,PP Bag
• Color: Brown
• Type: Boiler Bed Material
• Application: Inside Furnaces, Kilns, Reactors And Incinerators
• Form: Granular
• Alkalis: Less than 1 %

• Brand Name: Alchem
• Color: Beige
• Form: Powder,Sub Angular Particles
• Application: FBC Boilers
• Type: Boiler Bed Material
• Country of Origin: India
• Purity: High Alumina

The Boiler Bed Material is a very critical product and is considered as the lifeline for fluidized bed boilers. We have carved a niche as one of the prime Manufacturers and Suppliers of Refractory Bed Material for both FBC & CFBC boilers.

• Country of Origin: India
• Moistureq: 2%
• Purity: 99%
• Fusion Temperature: 1300 Degree C
• Bulk Density: 1000 to 1250 kg/M
• Water Absorption: 5% Max

• Color: Brown
• Form: Granules
• Alumina as Al2O3: 30% - 40%
• Silica as SiO2: 50-60% Max.
• Alkalies Na2O + K2O: Less Than 1%
• Iron as Fe2O3: Less Than 2.5%
• Titanium Oxide TiO: Less Than 1%

FBC Bed material - with alkaline properties

• Application: Bed Use
• Form: Powder, Crystal
• Density: 1000 to 1100 g/cm3
• Silica: 60% to 50%
• Particle Size: 0.85 to 2.36mm
• Melting Points: 1300 Degree C

Your search for Silica Ramming Mass Manufacturers India is over with us. Our company Kirti Mineral Works is popular and successful in the market today. We have Silica ramming mass, also known as acidic ramming mass or quartzite powder or quartz powder. Silica ramming mass is a product to be used in Coreless Induction Furnaces for melting of scrap to liquid steel. It is a dry lining refractory that can be used for all types of iron, steel, aluminium and foundries. The raw material of silica ramming mass is high-quality quartz, mixed with high-quality boric acid. The silica content of its raw material is more than 99%. Generally, we will add 1 % to 1.5 % to premix with quartz, but it can be changed as per customers’ requirements. This is one of the most popular products in our company, according to customers’ feedback, this product can be used for 20 heats to 40 heats on furnace capacity from 10MT to 40MT. Advantages: • High erosion resistance • High bonding strength • Short lead time • Free engineering services to guarantee service life. Choose to deal with us and get our services today. Speak to our executives if you have any questions or queries about our services. We take orders in bulk and deliver them to our customers always on time. Contact us and order our products today. We are the best Premix Silica Ramming Mass Suppliers.

• Color: Red
• Form: Granules
• Type: Boiler Bed Material
• Country of Origin: India
• Resistance Durability: Heat Resistance, Fire Resistance
• Al2o3%: 16-22
• SIo2%: 56-58
• Packing Type: 35 to 40 kg bag Approx, 1000 to 1200 kg Jambo bag

We are the well-recognized Manufacturer, Exporter & Supplier of excellent quality Boiler Bed Material. Made using quality refractory aggregates of high alumina contents & dense texture, our Boiler Bed Material is known for its low ferric high temperature and zero impurities. Moreover, we make use of such raw materials which limits the clinker formation. Owing to its special characteristics, our Boiler Bed Material is ideal for achieving smooth and perfect fluidization in boilers like Circulating Fluidized Bed Combustion Boilers (CFBC) and Fluidized Bed Combustion Boilers (FBC).

• Packaging Size: 40 Kg. HDPE Bag / 1 MT Jumbo Bag
• Color: Brownish
• Brand Name: Jainco
• Grade: SHD
• Usage/Application: In AFBC and CFBC Boilers
• State: Granules
• Packaging Type: Bag
• Bulk Density: 1.00 - 1.10 gm/cc
• Moisture: Less Than 1%
• Particle Size: 2.36 Mm to 0.85 Mm / 2.00 Mm 0.85 Mm / as per Demand
• IDT: Greater than 1400 Deg. Celsius
• Alumina: 28-32% Min.
• Chemical Nature: Dry
• Iron: Less than 2.0%
• Alkalis: Less than 1.0%
• Silica: 60-65% Max.
