Bond Tester Dealers

• Material: Metal
• Application: Industrial
• Feature: Durable, Easy To Use, High Quality
• Voltage: 220V
• Finishing: Polished
• Power Source: Electric
• Warranty: 1 Yr
• Automation Grade: Automatic

• Material: Mild Still
• Voltage: 240 V
• Power Source: Electric
• Capacity: 0-0.25 FT/LB and 0.1-0.5 FT/LB.
• Model: PAP-2072
• Range: 50-200
• Brand: PAP-TECH

Description: Internal Ply Bond Tester is used for determining the internal bond strength of paper,Board and Laminates with Dual capacity pendulam. Reading are taken directly on calibrated scale.   Measuring range :  0.0- 250ft/lb, 100 to 500 ft/lb in thousand.clamping pressure 50 to 200 psi with supplied spacer ring.   Accessories : we will provide following item along with manual intenal ply bond tester with the max. range of 500 ft.lbs in thousands.  1. calibration jig attachment with different range of STD. Cal. Weight. 2. Spacer for pressing the sample

• Type: Automatic
• Voltage: 220 V
• Feature: Easy to Use
• Certification: CE Certified
• Warranty: 1 Year
• Power: 1-5 Kw

Our Internal Ply Bond Tester is designed for determining the internal bonding strength of paper, paperboard and laminates, by measuring the average energy, in thousands of foot pound required to delaminate the specimen in two piles. Our product has five number specimen preparation unit, which allow for variations of specimen thicknesses, with different clamping pressures on the specimen from 50 to 200 PSI. Specification Dual capacity pendulum of 0-0.25 FT/LB and 0.1-0.5 FT/LB Readings directly on calibrated scale Standard calibration sliding weight with sample holder Double side adhesive tape width 1

• Type: Internal Ply Bond Tester
• Application: Industrial
• Weight: 10-15 Kg
• Color: Blue
• Feature: High Quality
• Finishing: Coated
• Country of Origin: India
• Automation Grade: Semi Automatic
• Brand Name: Global Engineering Corporation
• Certification: ISO
• Brand Name: Global Engineering Corporation
• Production Capacity: 5000 Unit
• Packaging Material: Wooden

• Material: Steel
• Power Source: Electric
• Automation Grade: Automatic
• Application: Determines the Internal Bonding of Paper and Board
• Brand Name: STIPL
• Standardization: TAPPI 569
• Sample Size: 1. x 1.inch
• Measuring range: 0-0.25 Ft/lb to 0-1.05 Ft/lb
• Clamping Pressure: 50 to 200 Psi with Supplied Spacer Ring

Device Description : Internal bond strength is the maximum load that single or multiply of paper or box board can with stand when loaded with a force applied directly at right angle to surface of the sample . Made of Heavy cast iron base with built-in leveling device pressure sensitive tape dispenser integral with base. A Stationary Anvil and separable platen which the pendulum strike at the same point for each test. A pendulum of dual capacity and free to swing on a housed and dust proof ball bearing. The range changing weights are available to select the pendulum capacity. A mechanism for holding the pendulum in raised position with a provision instantaneous release. A plexiglass peak pointer to register the maximum arc, enough which the pendulum swings when release. The scale is calibrated in thousands of a foot pound in both ranges, with a reference point for calibrating the pointer in free swing to compensate for friction during swing. The five number specimen preparation unit, which will allow for variations of specimen thicknesses, with different clamping pressures on the specimen from 50 to 200 PSI in 50 PSI increments with provided spacer rings.   Test Description: the operator clamps a prepared sample in the holder . the pendulum is released and impacts on the aluminum angle , which tears the sample internally . the angle falls on the rubber mat . the operator removes the support plate . four more tests are performed the same way . the values are measured . after finishing the tests the operator removes reminders of adhesives tapes from the angles and support plates , and cleans them ready for further sample preparations . That way , instruments and its accessories are ready for further tests.

• Color: Blue
• Condition: New
• Automatic Grade: Automatic
• Application: Industrial Use
• Feature: Easy To Use, Electrical Porcelain
• Country of Origin: India
• Warrenty: 1year
• Puncture Voltage: 220V

Peel Adhesion Tester provides a relatively inexpensive way for determining the peel adhesion, seal and tensile strength of packaging, tapes etc.

• Brand Name: Advancetech
• Capacity (Ft. Lbs.): 0 to 0.250 and 0.100 to 0.500
• Range (PSI): 50 to 100 (sample pressure)

Internal Ply Bond Tester is used to measure the internal bond strength of papers. Designed originally to evaluate the de-lamination strength of barrier materials comprised of kraft paper and sisal yarns, the Internal Ply Bond Tester has found many other uses in quality control laboratories in paper industry. The unit is used to measure the average force, in thousandths of ft. lb., required to de-laminate the fibers in the paper specimen, as described by the TAPPI “Useful Methods  403”. Other test includes de-lamination of bonding strength of coated papers stocks, the fibre bonding strength of kraft stocks (“Z” axis tensile) and the ply de-lamination strength of paper board. The Internal Bond Tester mat also be used as a coating pick tester. The procedures for this test are given in the TAPPI “Useful Methods 534”.General Features : A table-mounted unit designed for ease of operation, this model does not require an electrical power source. The unit consists of a base, a sample preparation device and a dual capacity free-swinging pendulum incorporating a ball nose-striking hammer. The pendulum pivots on ball bearings and a striking hammer gives point contact on the aluminum angle of the specimen assembly. The energy of the pendulum may be changed by simple adding or removing weights. The dial has two scales, for light and heavy loads. The specimen is held between the base and the anvil of the test fixture by double-sided pressure sensitive tape. Test fixture provide a standard specimen of one inch square, with lamination assembled under calibrated pressure to assure uniform adhesion throughout the samples. Technical Specifications : Load Measuring System: Consist of a free swinging dual capacity, pendulum of 0 to 0.250 and 0.100 and 0.500 ft. lbs. Capacity, a frication pointer of transparent plastic and a calibrated dial to indicate the force expanded by the impact. The pendulum assembly is supported by a cantilevered column, pedestal mounted on a cast iron base. A dispenser for a double-sided pressure sensitive tape width 1” is also an integral part of this model and is mounted into the base of the instrument along with the sample preparation apparatus consisting of five positions, each having one base and one angle. The aluminum angles are retained in a fixture for ease of alignment and assembly. After the samples are prepared pressure is applied through a cam and a lever. The range of pressure is adjusted from 50 PSI to 200 PSI by changing the capacity washers furnished with the tester.

Get in touch with us for obtaining the Internal Ply Bond Tester. Designed for various industrial applications, our Ply Bond Tester has garnered appreciation because of its high quality and high stability. We are a renowned Manufacturer, Exporter and Supplier from Saharanpur, Uttar Pradesh and are offering Mechanical Model of Internal Ply Bond Tester at nominal rates. Details : Designed for determining the Internal Bonding Strength of Paper, Paperboard and Laminates, by measuring the average energy, in thousands of foot pound required to delaminate the specimen in two piles, as described reference standard TAPPI T-569. Model AI – 7002
