PLUS TRANSFORMERS
Get Price Quote
- nput Impedance: See Table
- Droop: ≤20%
- Overshoot: ± 1V max
- Common Mode Rejection (CMR): 45dB min
- Frequency rage (No Load): 75KHz to 1MHz
- Insulation Resistance (Minimum): 1000M⦠@250Vdc
- Dielectric withstanding voltage: 200Vrms
- Operating Temperature: -55 to +125°C
Compupower Private Limited, over the years has earned the recognition of Indian Defence industry for its capability to produce highly reliable Data Bus Couplers for MIL-STD-1553B applications. With this capability and knowledge, we have designed and developed Data Bus Interface Transformers to meet the requirements of MIL-STD-1553B Data Bus applications. We believe our line of Data Bus Couplers and Transformers to be the best in terms of performance, cost and reliability.
Applicable documents:
MIL-STD-1553B
MIL-STD-202
MIL-T-21038D
Features:
High Reliability
45dB Common Mode Rejection
Low cost
All Standard Voltages & Turns Ratios
Fast Delivery
