Carbon Free Hose Pipe Dealers

• Country of Origin: India
• Material: Rubber
• Thickness: 5-10mm
• Length: 200-250mtr
• Feature: Perfect Finish, Easy To Use
• Dimension: 900-1000mm

We are the manufacture of high quality carbon free hoses . We manufacture these hoses under proper supervision and deliver to the customer after proper testing. These hoses are widely used in furnaces, coolant purpose, transfer hotcold liquid between the machines and discharging of water . sample availability : yes id: 25mm to 100mm length: 1mtr to 15mtrs working pressure: 10kg, bursting pressure: 30kg

• TEMPERATURE RANGE: -40°C to +100°C

Carbon Free Hose is recommended for Furnace Coolant & Electrical Cable Coolant Applications in Steel Industry and other non-conductive applications   Gates Carbon Free Hose offers high flexibility together with adequate toughness to help passing the electrical cable assembly through the hose. Gates Carbon Free Hose is specially designed and manufactured to take the abuse in your toughest working environments. You can always count on Gates Carbon Free Hose for optimal performance at a competitive price. We are The Value Connection.

Matching up with the exact requirements of customers, we are involved in presenting wide array of Carbon Free Hose(Rubber Carbon Free Heat Resistant Hoses).Features : High abrasion resistant Chemically resistant Smooth synthetic rubber GFCS Carbon Free Hoses :These Hoses are specially designed for services in iron/steel mills, glass works, electrical furnaces and out fields where the hose is required to be resistant to heat, radiation and splashes of hot metal. The tube is made out of white and black non conductive rubber compound. Rubberized and woven textile fabrics of natural and synthetic variety are used to reinforce the tube.GFCS Carbon Free Hose offers high flexibility together with adequate toughness to help passing the electrical cable assembly through the hose. GFCS Carbon Free Hose is specially designed and manufactured to take the abuse in your toughest working environments.Construction : Tube - Specialized Synthetic Rubber, Grey color. Reinforcement - High Tenacity Synthetic Yarn. Cover - Specially Compounded Nitrile, Green color. Service Temperature Range - 40oC to +100oC Working Pressure - 17kg/cm2

• Thickness (mm): all
• Usage: Industrial Use
• Brand Name: Gates, JK

All types Of carbon free hose are avaliable in all sizes

• Type: Pipes
• Thickness: 10-20mm
• Length: 4000-5000mm
• Application: Construction
• Color: Black
• Feature: Corrosion Proof
• Brand Name: Tata
• Shape: Round
• Certification: ISI Certified

Carbon free rubber hoses are available with or without asbestos cover both.SThese are specially designed hoses to carry cables that can conduct upto 11KVA and above. A synthetic carboon free white tube is used inside to provide the strength and resistance against high heat and electricity. Asbestos cover is provided on the outer side for longer life. Can handle the working pressure ranging from 7 kgcm2 to 15 kgcm2

• Reinforcement: Cotton textile fabric
• Working Pressure: 7 kgf/cm2 & 10 kgf/cm2
• CONSTRUCTION Lining: Carbon free made from the synthetic rubber having white wall.
• Cover: Abrasion, weather and heat resistant.
• Temperature: Upto 150°C
• Transport of food: Vegetable oil, Grease, beer, wine, milk, cream

Applications: Cleaning within food industry. It is used where hot water and cleaning solutions are necessary.

• Reinforcement: High Tenacity Synthetic Textile Yarn
• Hose Lining: Light gray, specially compound, oil resistant, synthetic rubber (nitirile)
• Cover: Light green, oil & abrasion resistant synthetic rubber (modified nitrile )
• Temp.Range: -40°C to + 100°C

Application   Furnace Coolant applications in steel Industries and other non- conductive applications with excellent leakage current less than 15 micro Amp. at 6 kv D.C.

We are engaged in manufacturing a wide array of Carbon Free Rubber Hoses which are used for covering wires of the electrical and electronics devices. All our hoses and pipes are designed using high grade raw materials to provide high flexibility. These electrical accessories are widely acclaimed for the notable properties such as high flexibility, light weight. We endeavor to provide most reliable and genuine products at the most reasonable price.In the steel, metal and foundry industries, Induction equipments are being used to melt or heat different metals. This induction furnaces operate at high power, high voltage and high current. This high electrical power passes through semiconductor devices, capacitor, inductor, several copper busbar, water cooled cable, induction coil. As very high current passes through all different component it get heated up. to cool this component we have to provide water cooling or in other sense we have to pass water through these component, But this component carry very high voltage so we have to flow non conductive-distilled water and also the rubber hose, which used to supply water must be non conductive.So for induction equipment rubber hose reqire following specification Rubber must be carbon free non conductive, very low leakage current at high voltage must withstand operating pressure long durability--synthetic rubber having long durability operating temperature more than 120 °C Good flexibility to accommodate small band good abrasive strength to protect from external wear and tear

• Country of Origin: India
• Type: Green Carbon Free Hose
• Color: Green
• Condition: New
• Brand Name: Green Carbon Free Hose
• Application: Electrical Coolant application; Conveying coolants in Furnace
• Temperature Range: -40°C to + 120°C.
• Tube: Cream Colour, Synthetic Rubber.
• Reinforcement: High Tensile Fiber Yarn Ply.
• Cover: Green Colour, Synthetic Rubber Cover Resistant to Oil, Weather and Abrasion.

We are authorised dealer of Carbon Free hose pipe of INDO make.we are supplying hoses from ID : 12mm to 150mm with asbestos or without asbestos covered.

Authorised dealers of Indo make Carbon Free Hose pipes both asbestos covered and plain. - Fast Delivery - Maximum possible discount - Original product with best quality.
