Clariflocculators Dealers

Vishuddhi has a tradition of manufacturing and supplying the industry’s highest quality and most reliable clarifier mechanisms from basic bridge or pipe supported mechanism to those with the most complex and demanding special requirements. Vishuddhi mechanism are driven by high torque designed drive units that have corrosion resistant and precision ratings superior to any drive on the market, and exceed the industry’s highest standards. Vishuddhi’s versatile clarifiers with central and peripheral drive are specially designed and developed for a vast range of applications. High toque gear drive with overload protection facility provided for minimal maintenance. Vishuddhi offers a wide range of clarifiers / clariflocculators ranging from 5 to 50 meter diameter tanks. The Lamella clarifier name is derived from the laminar flow regime that is maintained between the two layers of the media. The EMC Series Slant Plate Clarifiers are designed for efficient removal of readily setteable solids. In this slant plate clarifiers, setting take place on the plate surface and the effective setting area is the plates surface area. The EMC's compact, small footprint design requires less installation space than conventional or tube type clarifiers. The EMC design incorporates slanted plate setting surfaces pitched at a 55° angle from the horizontal with uniform plate spacing. Due to plate angle the solids slide down the plates into the solids hopper below the plate pack. The simple, inexpensive design, combined with no moving parts or sludge auger makes the EMC easy to install, operate and maintain.     Features Central peripheral drive assembly enables vast range of applications. High torque gear drive with overloaded protection facility. Minimum maintenance. No lower pinion bearing, eliminating a common source of drive failure. Designed for minimum maintenance with permanently lubricated bearings and gears. Alarm and cutoff switches and maximum torque limiting via shear pin or pressure relief valve.     Specifications Foundation plate, gear box, electric motor. Drives with CI gears, pulleys, chain and belts etc. MS platform. Liftingarrangement. MS scrapper blade. Central bearing housing and slip ring assembly   Benefits Flexible Configurations. Easy Installations. Gear Frive Capability. Operating Speed Flexibility. Simple In Operation. Efficiently Operating Mechanism. Easy Mobility. Less Maintenance, Low Capital, Operation Cost.

Centrally driven clariflocculator: avighna claritec™ offers fixed fullhalf structural bridge cum walkway spans over the outer diameter of the tank with hand rail. Features of centrally driven clariflocculator • diameter of the flocculation tank is determined according to the diameter of the clarifier tank. • rake arm mechanism and drives are supported by bridge truss. • clariflocculator are designed according to 24 flocculation paddles with independent drives. • flocculation paddles coverage ranges from 20 to 25% of the cross-sectional area of the flocculation tank. • the settled solids are scrapped by means of a rake arm (scraper) through the central sludge pocket and clear overflow is collected in a peripheral launder. • drives for clarifiers are selected according to the application and the required torque, to achieve the tip speed of scraper to 2.5 mminute. • drives for flocculator are selected according to the application and the required torque, to achieve the tip speed of the flocculation paddle up to 0.3 – 0.4 mminute. • drive arrangement is comprised of: 1. drive mechanism (act-dh) 2. worm reducer (make: as per client requirement) 3. chain drive with guard 4. motor (make: as per client requirement) optional features provided by avighna claritec™ • overload protection by means of mechanical or electro-mechanical overload devices. • shear pin arrangement. • surface skimmer & v notch weir plate. • telescopic sludge discharge valve.

We are the supplier of this product. With complete focus on growing technology, we are one of the technically advanced companies,engaged as manufacturers and suppliers of Clariflocculator that is a fine combination of flocculation and clarification in a single tank. It comprises two concentric tanks where inner tank serves as a flocculation basin and outer.

• Type: peripheral and central driven
• Material: MILD STEEL AND STAINLESS STEEL
• Color: SMOKE GREY
• Certificate: ISO 9001-2015
• Brand Name: UNIVERSAL

We are main supplier of this product.

• Material: Mild Steel
• Automation Grade: Automatic
• Type: Central Driven And Peripheral Driven
• Bridge Type: Full Bridge
• Country of Origin: India
• Driving Principle: Centre Driven
• Sizes: 3 mt. Dia to 50 mt. Dia

• Material: Mild Steel
• Automation Grade: Automatic
• Bridge Type: Full Bridge, Half Bridge

clariflocculators are much useful in the primary treatment of water. our company provides products that benefit the environment and its inhabitants. clariflocculators are generally used for chemical primary treatment for effluent. instead of separate flocculation & clarification, clariflocculators are generally used. this results into economical and faster installation of primary treatment. our clariflocculators have high torque center drive with sludge arm lifting device. main feature of our clariflocculators is concentric paddle type flocculator mechanism which creates the flocs throughout the flocculation zone.we can provide the skimming mechanism or skimming device, if required by the clients for particular applications. generally, this mechanism is required to remove floating debris, solids, which float on effluent surface. it compromises of rotating skimmer, scum scraper and scum box. neoprene rubber wipers are generally provided with the clariflocculators. the scum scraper collects the scum and drops it in scum box, which is connected to withdrawal piping. a scum skimming arm, supported on one of the scrapper arm is provided for removal of floating debris or solids. the collected scum is pushed by a level-loaded or spring loaded scraper into a scum box. through this scum box the scum drains off the paddle and pipe. thus, floating scum is taken out from the clarifier easily.

• Type: Clariflocculators
• Material: Mild Steel, Stainless Steel, MSFRP
• Color: Customized
• Capacity: Customized
• Bridge Type: Full Bridge, Half Bridge
• Certificate: ISO 9001-2008 Certified
• Power Consumption: Customized
• Treatment Capacity: Customized
• Automation Grade: Automatic, Semi-Automatic
• Driving Principle: Centre Driven, End Driven
• Country of Origin: India
• Brand Name: Envifab

• Type: Clarifier, Clariflocculator
• Brand Name: HWE

We are offering clariflocculator, clarifier. upto 60m dia. centrally driven / periheral driven full bridge / half bridge

Clariflocculators incorporates the flocculator and clarifier in one compact unit. Agglomeration of the destabilised colloids is achieved as a result of particle transport in the inner flocculation unit. Clarification occurs in the outer clarifier unit.Flocculation, radial and upward flow sedimentation and positive sludge removal combined in a single tank operation is one of the salient features of this equipment.

We are offering Grey Water Treatment Plant that is used in treatment of any domestic wastewater produced, excluding sewage. This system has advantage over other methods as it treats the greywater naturally and also requires minimal power energy. The plant is completely designed using genuine stainless steel and are robust in built and weather proof. It has longer service life and requires minimal maintenance.

CLARIFIER Clarifiers are widely used for reducing suspended solids load by coagulation and settling method. High Rate Solids Contact Clarifier is used in Applications, where the inlet solids load is variable and if the solids are fine. Flocs formed in flocculator are settled in Tube or plate (lamella) settlers or in the settling zone of a clarifier. These equipment are used in river or lake water for high flow rates and also in ETP STPs Lamella Clarifier Lamella Clarifier is a water treatment process that features a rack of inclined metal plates, which cause separate liquid and solid, by directing the water between a series of inclined plates.We have established ourselves as a renowned manufacturer and supplier of Settling Tanks / Lamella Clarifier. Our products are highly appreciated by the clients for providing an effective solution for the clarification of water and waste water.

PARAMOUNT" make clariflocculator mechanism is suitable for installation in RCC circular basin. The drive can be used continuously for flocculation & setting of solids. The settled solids are removed from the centre of the tank. The recommended slope is 1:12 at the bottom of the clariflocculator tank for efficient removal of sludge. The sludge is scrapped from the bottom by means of rotating scrapper arm.

• Automation Grade: Semi-Automatic
• Type: Circular
• Treatment Capacity: 160 MLD
• Industry: Pharmaceutical Industry
• Brand Name: Indofab
• Tank Diameter: 70 m
• Speed of Flocculator Paddles: 400 mm/second
• Detention Time (in hours): 4 Hour
• Speed: 2500 mm/minute
• Bridge Width: 1.5 m
• RPM: 0.50 RPM

Fixed Bridge Across the tank Rotating Bridge

Clariflocculators are widely used for chemical primary treatment for effluent water. These Clariflocculators are designed and developed to provide an economical and faster installation of primary treatment. The innovative design enables the clariflocculator to handle heavy slugs while delivering shortest floc settling time.We supply different type of clariflocculators with built in flocculation well and paddle type flocculator in the flocculator well which help in creating flocks. There is no need to give separate flocculation tank with flocculator.

Karyasiddhi offers both centrally driven and peripheral driven clariflocculators. It is a combination of both flocculation and clarification in a single unit. Clariflocculator shall have two concentric tanks with inner tank serving as flocculation basin and outer tank serving as clarifier.The chemically dosed water is uniformly distributed over the surface of the flocculation compartment for effective utilization of the available volume for flocculation. The specially designed flocculating paddles enhance flocculation of the feed solids.   As heavy particles settle to the bottom, the liquid flows radially outward and upward and the clarified liquid is discharged over a peripheral weir into the peripheral launder.   The deposited sludge is raked to the bottom near the central pocket from which it can be easily discharged. Both central driven and peripheral driven mechanisms are available in the manufacturing range.   Applications   • Steel Industry Blast Furnace, Electric Arc Furnace, BOF, etc   • Fertilizer Industry Phosphate Rock Dryers & Calciners, Dryers   • Non-Ferrous Copper Reverberatory Furnace, Laea Blast Furnace   • Pulp & Paper Lime Kilns, Back Liquor Recovery, Bark Boilers   • Sugar Industry Boiler Flue Gas, Bagging Section   • Mineral Products Asphalt Stone Dryers, Cement Kilns   • Pharmaceuticals Tablet Coating Fans, etc

We are the supplier of this product. With complete focus on growing technology, we are one of the technically advanced companies, engaged as manufacturers and suppliers of Clariflocculator that is a fine combination of flocculation and clarification in a single tank. It comprises two concentric tanks where inner tank serves as a flocculation basin and outer.

We offer clariflocculator centrally mechanism that is suitable in the RCC circular basins. For continuous flocculation and setting of solids, this mechanism is absolutely suitable. Later on the settled solid is removed from the center of the tanks. As per our design specifications, the recommendable slope ration at the bottom of the clariflocculator tank is 1:12 and thus the sludge can be efficiently removed out. The centrally clariflocculators consist of the following types of components.

Clariflocculators unit is a combination of both flocculation and clarification in a single tank. This unit consists of concentric circular compartments. The inner compartment is the flocculation chamber and the outer compartment is the clarifier. The chemically dosed water is uniformly distributed over the surface of the flocculation compartment for effective utilization of the available volume for flocculation. The specially designed flocculating paddles enhance flocculation of the feed solids. As heavy particles settle to the bottom, the liquid flows radically outward and upward and the clarified liquid is discharged over a peripheral weir into the peripheral launder. The deposited sludge is raked to the bottom near the central pocket from which it can be easily discharged. Both central driven and peripheral driven mechanisms are available in shivam's manufacturing range CENTRAL DRIVE CLARIFLOCCULATORS 3 MT. DIA TO 50 MT. DIA  This unit is suitable for installation in client’s concrete tank. Each unit will consist of :- Fixed full bridge with walkway and handrail from one end to center. Center drive with Motor, Gear box, Base plate, V- Belts. Central heavy duty bearing housing. Central shaft. Clarifier rake arms with blades. Flocculator drive with motor and gear box. Flocculator shaft. Flocculator paddles. Flocculator chamber in steel.
