CNC Carving Machine Dealers

(108 products available)

CNC Wood Carving Router Machine

430,000 Per Piece

Weight: 1100kg
Moving speed: 25 m/min
Table Size: 1220 X 2440 Mm
No Load Speed: 25000 mm/min
Rebating Depth: 25mm
Spindle Speed: 18000 Rpm
Travelling Size X Axis: 1220 mm
Travelling Size Y Axis: 2440 MM
Travelling Size Z Axis: 150 mm
more..
Real Tech

Vaniyambadi, Vellore

5.0 2 Review(s) Website
K1325 HD Servo Wood Carving CNC Router Machine

415,000 Per piece
1 Piece (MOQ)

Country of Origin: India
Voltage: 220V
Rated Power: 1-3kw
Automatic Grade: Automatic
Driven Type: Elecric
Brand Name: K-Tech
more..
Kameshwara Technologies

Hyderabad

4.0 1 Review(s) Website
Best Deals from CNC Carving Machine

Name

Mobile
Hybrid Servo 1325D CNC Router carving Machine

700,000 - 840,000 Per pieces
1 Piece (MOQ)

Brand Name: Woodstar
Driven Type: Elecric
Color: Grey
Condition: New
Rated Power: 7-9kw
Automatic Grade: Semi Automatic, Fully Automatic, Automatic
Size: 2500x1300mm
Voltage: 220V
Type: Cnc Wood Carving Machine
Weight: 1000-2000kg
Frequency: 50Hz
After-Sales Service Provided: Yes
Country of Origin: India
Table Size: 2500 X 1300 Mm
Warrenty: 2years, 1year
Moving speed: 45 Mm/min
Speed: 15 Mm/min
Traveling Size X Axis: 1300mm
Traveling SizeY Axis: 2500mm
Working area: 1300 × 2500 × 200 mm
Phase: Single Phase
more..
KOVAI WOODSTAR AUTOMATION & TECHNOLOGY PRIVATE LIMITED

Kalapatti, Coimbatore

5.0 1 Review(s) Website
CNC Carving Router Machine

550,000 Per piece

Rated Power: 10000W
Automatic Grade: Fully Automatic
Warranty: 1 Year
Spindle Power: 4.5KW
Humidity: 75%
Spindle Speed: 18000RPM

Description X,Y,Z Working Area : MT : 1325 /1530/2040/1300x2500x300mm Table Struture : Heavy Duty Lath Body Software Environment : Windows xp/7/8/10 X,Y Structure : Gear Rack made in Taiwan Z Axis German Ball screw Z Structure : Taiwan PMI Linear Guide Taiwan TBI Ball Screw Spindle Power : HSD/HQD Spindle 3.5/4.5/6w Spindle Speed : 0-18000/24000RPM Drive Motors : 850W Japan YASKAWA/YAKO, Servo Motor & Stepper Drive Working Voltage : 220w Single phase, 380V 3 Phase, 50Hz Operating System : DSP/NC Studio /NK Running Environment Temperature : 0-45 Centigrade
more..
Maura Technologies

Horamavu, Bangalore

4.0 1 Review(s) Website
Cnc Wood Carving Machine

380,000 - 420,000 Per nos
1 nos (MOQ)

Driven Type: Elecric
Color: Grey
Condition: New
Rated Power: 3-5kw
Automatic Grade: Fully Automatic
Size: 1400mm*3000mm
Voltage: 220v
Type: Cnc Wood Carving Machine
Weight: 100-1000kg
After-Sales Service Provided: yes
Country of Origin: India
Table Size: 8*4
Warrenty: 1year
Moving speed: 25000mm/min
Speed: 26000rpm
more..
Lakshmi International

Kasipalayam, Erode

5.0 1 Review(s) Website
Cnc Wood Carving Machine

380,000 Per Piece
1 Piece (MOQ)

Country of Origin: India
Weight: 1300 Kg
X-Y Axis Working Area: 1300 x 2500 mm
Z Axis Working Area: 300 mm
Spindle Power: 3.5 kW
Machine Type: 3 Axis
Job Material: MDF, Sign Board, Wood, Plywood, Foam Board, Acrylic
Spindle Head Type: Single Spindle
Spindle Speed: 18000 RPM
X-Y Movement: Helical Racks
Z Movement: Ball Screw
Command Code: G Code
Driven Motor: Driven Motor
Control System: Rich Auto A11 DSP Controller
Power Consumption: 5 KW
more..
Kataria Tech Zone

Hakima Gate, Amritsar

0.0 Website
Cnc Wood Carving Machine

550,000 - 750,000 Per piece
1 1 (MOQ)

Driven Type: Elecric
Color: Red
Condition: New
Automatic Grade: Fully Automatic
Country of Origin: India
Warrenty: 1year

CNC routers can cut a variety of materials, including wood, plastic, aluminium, and high-density foam. CNC stands for computer numerical control, and it refers to machines that are operated by computer software and electronics rather than by a human operator. CNC machines can cut in three directions, known as the X, Y, and Z axes, in most circumstances. The longest axis is the X-axis, which runs from front to back. The Y-axis represents left and right, whereas the Z-axis represents up and down. CNC routers are faster and more exact than people since they run on computers, making them valuable in manufacturing. Application:Wooden Door, Wooden Carving Gift Articles, MDF, Plywood, PVC, Foam Guards, Waving Boards, 2D-3D Carving, Indore and outdoor signs
more..
SIDDHTECH INDUSTRY

Vatva, Ahmedabad

4.0 1 Review(s) Website
Cnc Carving Machine

680,000 - 980,000 Per Piece
1 Piece (MOQ)

Driven Type: Electric
Color: White
Condition: New
Rated Power: 7-9kw
Automatic Grade: Fully Automatic, Automatic
Application: 3 d design
Certification: ISO 9001:2008

400*400*200/600*400*200 spindle as per requirement and control as per requirement
more..
KR CNC AUTOMATION

Nangloi, Delhi

5.0 1 Review(s) Website
Cnc Wood Carving Machine

490,000 Per Piece
1 Piece (MOQ)

Country of Origin: India
Type: Automatic
Certification: CE Certified
Brand Name: Oken
Weight: 1600 Kg
Frequency: 50 Hz
Packaging Size: 3000 x 1800 x 1500 mm
Spindle Power: 3 Kw
Spindle Speed: 18000 RPM
Tolerance: 50 Micron
more..
Sri Hari Technologies

Avadi, Chennai

4.0 1 Review(s) Website
CNC Door Carving Router Machine

570,000 Per piece
1 piece (MOQ)

Application: Plastic Cutting, Wood Cutting
Model: MarkSys CNC Router ER 30.15 DH
Working Area (mm): 3000mm X 1500mm
Control System: DSP A11 / NK 105
Guide Rail: 20mm /25mm Linear Square Guide Rails
Motor: Stepper/Servo
Drives: Leadshine / Yacotech
Spindle Power: 3.5Kw/ 4.5Kw/ 5.5Kw/ 6Kw
Axis: (X,Y,Z)
Z Axis: 200mm /300mm/400mm
Spindle: Air Cooled /Water Cooled
Working Table: Aluminium Profile With T-slot
Work Voltage: AC 220/380Volt/50Frequency Single Phase / 3Phase
Transmission System: Rack and Pinon (Helical)
Optional Device: Servo Stablizer / Dust Collector
more..
MarkSys Integrators

Aurangabad

0.0 Website
1525 CNC ROUTER wood carving machine

570,000 Per Ton
1 Piece (MOQ)

1525 cnc wood carving machine 08897828285 EMI :15000

more..

G NEXT CNC ROUTERSnMACHINES

Sabbavaram, Visakhapatnam

0.0 View Profile
3D CNC Wood Carving Machine

675,000 Per Piece
1 Piece(s) (MOQ)

Work Table Dimensions: 1300 mm x 1300 mm (L x W)
Computerised Control of Machine Operations: DSP / Nc studio card
Maximum Traverse Rate: 15000 mm/min
Spindle Motor Maximum Speed: 18000 rpm
Axis Travel: 1000 mm x 1000 mm x 250 mm (X axis x Y axis x Z axis)
Axis Motion Transmission: X Axis-Rack N Pinion, Y Axis-Rack N Pinion, Z Axis-Ball Screw
Axis Drivers: Stepper motor with microstep drive
Axis Sliders: Linear motion Guide (Hiwin/Alwan)
Available Spindle Motor Power: 2.2/3/4.5/6 kW
Spindle Motor Drive: VFD speed control
Available Collet Size: ER 20 to ER 32
Maximum Tool Diameter: Up to 20 mm
Maximum Weight of Material on Table: 300 kg
Weight of Machine: 1200 kg (Approx)
Floor Space Required: 8 feet x 8 feet
Structure of Machine: Solid Steel Frame Structure
Power Source Required: Single Phase / Three Phase Depending On Spindle
more..
Maheer Technologies

Dhokaliya, Rajkot

0.0 View Profile
Cnc Wood Carving Machine

Get Price Quote

Voltage: AC 380 V
Automation Grade: Semi-automatic
Power: 850 W ( Drive Motor)
Spindle Power: 9 kw
Accuracy: +/- 0.01 mm( Positioning), +/- 0.01 mm/300 mm (Travelling Positioning Accuracy)
Frequency: 50-60 Hz
Spindle Speed: 24000 RPM
Traveling Speed: 15000mm/min
more..
Gopal Engineering Works

GT Road, batala

0.0 View Profile
CNC Double Head Wood Carving Machine

650,000 - 850,000 Per Piece

Type: Cnc Wood Carving Machine
Certification: ISO 9001:2008
Color: Grey
Automatic Grade: Fully Automatic
Driven Type: Elecric
Warrenty: 1year
Country of Origin: India
Brand Name: Black Smith
Transmisison: X and Y Axis Transmit By Rack & Pinion with Timing Pulley & Belt Mechanism and Z Axins By Ball Screw
Spindle RPM: 18000
Lm Guide and Ball Screw: 25 Mm , Pmi
Rack Ckand Pinion: Yyc Helical , Harden
Spindle Drive: DELTA/INVT/Mitshubishi
Cable and Drag Chain: Igus, German
Maximum Working Speed: 15 M/min
Commanig Language: G Code
more..
Black Smith

Bakrol, Ahmedabad

0.0 View Profile
CNC Carving Router Machine

415,000 Per Piece

Type: Automatic
Certification: CE Certified
Application: Industrial
Driven Type: Electric
Warrenty: 1 Year
Brand Name: Unistar
more..
Unistar CNC

Bhosari, Pune

0.0 View Profile
CNC Marble Carving Machine

650,000 Per Piece

Country of Origin: Made in India
Spindle Speed: 24000 RPM
Machine Weight: 1200 Kg
Flash Memory: 128 M ( U Disk)
Running Temperature: 0 to 45 Degree C
Relative Humidity: 30 % to 75 %
Max. Rapid Travel Rate: 20000-30000 mm/min
Size: 5 x 10 Feet
Spindle Cooling: Air Cooled Spindle
Brand: YKS
X-Y Axis Working Area: 1250 x 2500 mm
Z Axis Working Area: 200 mm
Spindle Power: 6 kW
Job Material: Stone, Marble
Maximum Working Speed: 25000 mm/min
Repositioning Accuracy: +/- 0.03 mm
Driven Motor: Servo Motor
Condition: New
more..
YKS ENGINEERINGS

Shastri Nagar, Delhi

0.0 View Profile
Fully Automatic Cnc Wood Carving Machine

Get Price Quote

Automation Grade: Fully Automatic
Usage/Application: Wood Carving
Speed: 24000RPM
Phase: Three Phase
Working Voltage: 440 V
Body Material: Mild Steel
Resolutions: 0.025 mm
more..
Cybernetic Instruments

Dahanukar Colony, Pune

0.0 View Profile
Cnc Wood Carving Machine

430,000 Per

Rated Power: 6kW
Brand Name: Neptune System
Speed: Up to 1550 RPM
Country of Origin: Made in India
Voltage: 280V
Frequency: 50Hz
Material: Mild Steel
Usage/Application: Carving, Routing, Drilling
Automation Grade: Semi-automatic
Carving Material: Wood
more..
Neptune System

Alandi, Pune

0.0 View Profile
Cnc Wood Carving Machine

825,000 Per Piece

Rated Power: 5-7kw,9-12kw
Warrenty: 1year,2years
Automatic Grade: Automatic,Fully Automatic
Certification: Other
Condition: New
Driven Type: Elecric
Weight: 1000-2000kg,2000-4000kg
Voltage: 220V,380V,440V
Type: Cnc Wood Carving Machine,Other

CNC wood router Machine Made in INDIA Raghav techno industries Ahmedabad
more..
Raghav techno industries

Odhav, Ahmedabad

0.0 View Profile
Wood Carving CNC Router Machine

Get Price Quote

Working Dimension XY: 1300*2500mm
Spindle Power: 4.5kw 4.5kw Water Cooling / Air Cooled, 24000rpm
Machine Frame: Ultra Thicken Steel Tubes with Quenching Treatment Welded
Machine Table: Coolant Tray with Wheels for Moving Stone Plate Easily
Working Voltage: Ac380, 3phase/ac220, 3 Phase
Control System: dsp Remote Controller with Usb Interface with Cable for Pc
Software offered: ArtCAM, Type3 etc
Program File: G Code
Moving Speed: 32m/min
Working Speed: 10/min
Working Precision: ±0.05mm
Motor: Stepper
Working Dimension: 2000*3000mm
Spindle Power: 6kw, 7.5kw or more
Control System: NC studio etc
more..
Modern Techno Engineers

Jor Bagh, Delhi

5.0 1 Review(s) View Profile
