Compression Moulding Machine Dealers

• Frame Design: 4-Pillar Type
• Condition: New
• Material: Mild Steel
• Automation Grade: Fully automatic
• Weight (Tons): 10 ton
• Capacity (Ton): 300
• Daylight (Millimetre): 500
• Heating Mode: Eletric
• Electric Motor: Three phase
• Platen Size (Millimetre): 600 x600
• Platen Temperature (Celsius): 200'C
• Power Of Electromotor (Kilowatt): 25kw
• Pressing Capacity (Tons): 300 tons
• Type of Press: 1-dilite
• T- Slot: M16
• Model Number: 600-600-1/500-300
• Power Source: 3-phase
• Number Of Phase: 3-phase
• Working Pressure (kn): 210kg/cm2

• Type: Rubber Injection Moulding Machine
• Certification: ISO 9001:2008
• Color: Black, ANY
• Voltage: 440V
• Condition: New
• Warranty: 1 Year
• Clamping Force: 1100-1500kn, 1600-2000kn
• Brand Name: bp-rcm
• Production Capacity: spm
• Plastic Type: silicon /nytral
• Style: Vertical
• Operation Mode: Automatic, Fully Automatic, Manual, Semi Automatic
• Power(W): 1-3kw, 3-5kw, 5-7kw, 7-9kw

• Maximum daylight: 560mm, 600mm, 810mm
• Approx. pressing speed: 5mm/sec ,3mm/sec

Heavy steel fabricated body of l-beam and plates construction. Graded cast-iron platens of liberal thickness. Uniquely designed telescopic main press cylinder. Cylinder is openable at both ends for in-situ-servicing. The use of telescopic cylinder results in fast and accurate operation of the press with mould begning to close at fast speed, low pressure. Slow mould closing at full pressure can be selected to develop desired pressure just before mould is fully closed. This not only provides safety to the mould, but also results in substantial power saving.

• Platen Size: 250 x 250 mm
• Condition: New
• Country of Origin: Made in India
• Capacity: 30 Tons
• Machine Type: Closed Frame
• No. of Station: Single
• No. of Daylight: One
• Heating of Platens: Electrical Heater
• Stroke Length: 300 mm
• Bore Diameter: 150 mm
• Motor Power: 3 HP

• Brand Name: STAR HYDROTECH
• Phase: 3phase
• Material: Ms

• Condition: New
• Country of Origin: Made in India
• Capacity: 600 Tons
• Machine Type: 4-Pillar Type
• No. of Station: Double
• Heating of Platens: Thermic Fluid or Oil
• Stroke Length: 150 mm
• Bore Diameter: 200 mm
• Motor Power: 3 HP
• Control: PLC Controlled

• Compression molding: Lab Press
• ceramic press: gold press
• rubber press: metal press
• forming press: powder press
• cold press: hot press

Hydraulic Compression molding press from 50 tons to 3000 tons . Platen size 500 x 500 mm to 2500 x 1500 mm sizes . with PLC controls , hydraulic units and conveyors

• Finishing: Polished
• Driven Type: Hydraulic
• Shape: Rectangular
• Color: Blue
• Usage: Industrial
• Type: Automatic
• Warranty: 1 Year
• Country of Origin: India
• Capacity: 10 Ton to 1600 Ton
• Platen Size: 350x350 to 1250x2500 mm
• Daylight Gap: Closed Frame
• Stroke Length: 400 mm
• Bore Diameter: 125 to 450mm
• Motor Power: 5 hp to 60 hp

• Brand Name: Ulai
• Driven Type: Hydraulic
• Machine Body Material: Cast Iron
• Finishing: Galvanized, Polished, Chrome Finish, Coated
• Color: Sliver
• Condition: New
• Automatic Grade: Semi Automatic,Automatic
• Power: 10 KW, 10-50 KW
• Frame Design: H Type Frame, 4-Pillar Type, Closed Frame
• Speciality: Reliable, Robust Construction, Easy To Use, High Efficiency
• Certification: CE Certified
• Voltage: 440V
• Packaging Type: Wooden Box
• Type: Compression Molding
• Country of Origin: China
• Machine Structure: Vertical
• Phase: Three Phase
• Warranty: 1 Year
• Corrosion Resistance: Yes
• Clamping Force: 50-500 Ton, 500-1000 Ton
• Machine Type: New
• Material: SS

• Type: vacuum compression
• Brand Name: JRD
• Type: Compression Press
• Condition: New
• Warranty: 1 year against manufacturing defect
• After-Sales Service Provided: yes
• Model Number: VAC

We offer vacuum compression moulding machine.

• Voltage: 108 KW
• Frame Design: rotary compression
• Material: Stainless Steel
• Power Source: Ac
• Automation Grade: Automatic
• I Deal In: New Only

• Range: 300t

Double station compression moulding hydraulic press for thermoset plastics & rubber. Economic due to common hydraulic pump motor and electric panel. Better utilization of labour. Range lot to 300t. Custom built option. Down stroking or up stroking option. Manual hand valve operation standard, optional auto control. Hydraulic or mechanical ejector as option. Insulated mould platens to prevent undue heat transfers. One piece design for easy installation and lesser floor space requirement. Single speed operation as standard, optional last and slow speeds. Manual de-gassing for better product quality. PID temp. controllers for each station with two zones per station with Thermocouple sensors. World class hydraulic and electric components. World class hydraulic seals for cylinders. Pump and electric motor stops upon releasing down push button after achieving clamping tonnage. Tonnage maintained by holding valves. When pressure drops due to process. operator can restore the pressure just by pressing push button. Curing timer alarms operator to open the mould manually by valve thus repeatability in curing time and hence quality of product. Controlled parallity between two platens for flash free moulding. Manual press comparable to quality parameters like automatic press.

• Brand Name: Magnum
• Condition: New
• After-Sales Service Provided: yes
• Power: 7500
• Color: white and blue
• Place of Origin: china

Quality of cap produced on rotary hydraulic compression machine has received wide acceptance from customers because of its quality and finish and has fetched a higher selling price then the ones produced using injection moulding process. The consistency in quality, fast cycle time and low cost of production have given this technology all the advantage. The process involve continuous extrusion of plastic at the tip of extruder from where the take up unit cutter lifts the material and drops in the cavity of the mould and the rotary movement of mould wheel keep the production process continuous and cyclic and the revolution of the wheel is the time taken for the cap to take shape, cool and get ejected before starting the next cycle.

We manufacture 5 tons & 30 tons capacity hydraulic compression Molding presses for various laboratory applications.The range of Compression Molding Presses we offer are as follows

Atwo piece closure having PCO neck finish with liner sealing designed for the Carbonated Beverages Market. 28mm CSD 1810 :- This is a single start thread, two piece closure with single lip liner sealing suitable for carbonated beverages. Decoration in two color printing on top of closure also possible. Instant pressure retention 100 psi for 1 min. Then up to 175 psi .

• Features: High finish,Low energy requirement,Higher Productivity
