Computerized Weighbridge Dealers

• Platform Size: 6 x 6 ft

The Electronic Static Weigh-bridge is made up of a framework of girders adequately reinforced with transverse beams and suitable non-slip top deck with Pit less & Pit type Structure. The entire steel framework is mounted on strain gauge double ended shear beam Compression Type Load Cells (4, 6, & 8 No's. Load Cells), depending on length of the platform. The shear stress produced by the load is detected by a strain gauge, full bridge circuit and converted into an analog electrical signal. Signal from each loadcell is fed to Junction Box. Output from Junction Box is fed to microprocessor based weighbridge Microprocessor based weighbridge Intelligent Terminal. The processing electronics of terminal digitizers the signal from the Junction-box using an ADC, based on time proven quad slope integration technique and weight is registered on LED display.

We manufacture high quality computerized Weigh bridge These are mostly suitable where excavation work for foundation is difficult or construction of pit is expensive. Since the structure is above ground level, vehicles can approach the weigh bridge only from two directions where the ramps are provided. This type of weigh bridge requires more space. Computerized Weigh bridge has some unique benefits over other types of weighbridges. Benefits : Costly pit construction is eliminated.  Platform above ground level- No water logging during rainy season Problem of pit maintenance is eliminated. Easy maintenance since all parts accessible above ground level. In Pit less weigh bridge RCC ramp work must be required at least 3 meters for both side for easy movement of vehicle.

• Material: Mild Steel
• Type: Computerized
• Weighing Capacity: 200 Kg-100 Metric Ton
• Color: Grey, Black
• Usage/Application: Weighing
• Temperature Range: To

High accuracy upto 5000 to 10000 counts pitless pit type construction platform size as per customer choice accessories detachable extra display at 5 meter. Computer printer interface (rs-232 c). jumbo display wireless rf extra display windows base weigh bridge software usb port for laptop computers utilizing 24 bit?-?adc (high internal resolution) micro controller based 6 digit easy to read bright led display utilizes 6v, 4ah smf battery double ended share beam type steel alloy heavy duty load cell (4 to 8 nos)

• Size: 6 X 3 M
• Material: Concrete
• Weighing Capacity: Approx. 180T
• Brand: Nipro
• Taring Range: 100% Subtractive Tare
• Calibration: Internal Digital Calibration
• Accuracy: 20 Kg
• Voltage: AC 230V

• Size: 6x4mtr, 7x5mtr, 8x6mtr
• Type: Computerized Weighbridge
• Material: Stainless Steel
• Color: Silver
• Condition: New
• Automation Grade: Semi Automactic

In order to deliver consistent quality products, we keep our vigil eyes on product development, storage and final dispatch. Due to our streamlined packaging system, we are capable of meeting both standard and customized packing needs of the clients. Moreover, we make use of quality packaging material.

• Size: 6m x 3m to 18m x 3m

A leading manufacturer, supplier and exporter of all kinds of electronic weighbridges in Delhi NCR and all over India, Amar Scales makes sure that customer’s needs are given the topmost priority. At amarscales.in, our expertise lies in manufacturing the best products – highly durable and extremely meticulousness.

We are market leaders in the manufacture and supply of Computerised Weighbridges. Rockway has Computerised Weighbridges of various kinds. They can be using a concrete platform or the more common steel platform. Foundation-less weighbridges are also supplied by us. We have pit-less type weighbridge or pit type weighbridge. Rockway also provides weighbridges which are fully Computerised, Unmanned weighbridges, Industrial weighbridges of all kinds.   Features: Accurate. Impeccable performance. Highly Efficient Weighbridge.

• Size: 5x3mtr, 6x4mtr, 7x5mtr, 8x6mtr, 9x7mtr
• Type: Computerized Weighbridge
• Material: Iron, Metal, Mild Steel, Stainless Steel
• Application: Loading Heavy Vehicles
• Color: Black, Brown, Grey, Silver, Smoke Grey
• Condition: New, Used
• Display Type: Digital, Led
• Feature: Accurate Result, Durable, Easy To Operate, Good Capacity, High Resolution, Non Breakable, Quick Weighing
• Automation Grade: Automatice, Semi Automactic
• Weighing Capacity: 100-150ton, 150-200ton, 50-100ton

All load cells in a Computerized weighbridge may produce unequal output which gives corner error and result weight error on every weighment. General thumb rule for eccentricity test is to test each load cell with the load of Total Weighbridge Capacity No. of Load Cells. For example, a weighbridge with a capacity of 60 tonnes with 6 load cells may be tested each load cell with 10 tonnes weights.

These are Computerized Weigh Bridge are best in quality and with high precision. This Computerized Weigh Bridge is electronically operated and takes very less maintenance. This truck weigh bridge is highly durable and efficient and provides excellent performance in loading the contents. These are very comfortable in using because everything is done computerized. WWS are manufacturers, exporter and suppliers of fully computerized weighbridge, truck weighbridge, truck scale, Fully Electronic, electronic, pit type, pit less, Mechanical, mobile, movable, portable, axle, Ahmedabad, Gujarat, India. For more detail please

ifferent platform size 6m x 3m to 18m x 3m Heavy duty load cells and rugged construction for long life and reliable operations Optional Stainless Steel Hermetically Sealed Compression Loadell with IP68 Environmental Protection Incorporates latest Microcomputer – technology for accurate weighing Eliminates leavers and knife edges to avoid frequent maintenance Computerized model for effective truck management and report generation on the basis of date, vehicle number, supplier, material, etc., on a printer

Bar graph to enable the operator to understand the percentage of weighbridge capacity being used each time as it will ensure the condition of load cells each time after weighment.Provision for printing complete weigh tickets with automatic calculation of net weight from stored data.Any Header, Footer or other format is possible by just changing its program IC. This ensure no need to program again & again due to corrupt memory if stored in RAM.

The structure of weighbridge is made up of a framework of girders adequately reinforced with transverse beams and suitable non-slip top deck. The entire steel framework is mounted on strain gauge double end shear beam Rocker pin type load cells. The number of load cells depends on the length of the platform. LEO Weighbridge Indicator is a micro processor based digital indicating system. This is optimized to meet all the fundamental requirements of modern day Electronic Weighbridge. The high precision tracking excitation source has a capability to source more than 150 ma, adequate for 10 no. 350 ohm load cells. The analog front end is built around a programmable gain differential amplifier with extremely low noise and offset drift. It has the facility to be interfaced with PC through RS 232 port.

In order to ensure the safety of the products, we carefully store the lot under hygienic conditions and safe environment. Moreover, the lot is stringently and regularly checked by the experts. Be cash payment or bank transfer, we are capable of making transactions using them all. Worry not! We have organized and maintained database to keep a stern check on the transactions made.

Computer Integrated management & control system,Automatically identify vehicle information system,Traffic controller along with RED & GREEN light signals, Voice automatically prompt system,Video monitoring system, Anti-cheating system,RF ID cards along with card reader,SMS after each weighment,Support for Dot matrix as well as Graphics printers, Zero check between weights
