continuous foaming machine
Get Price Quote
We are offering continuous foaming machine. is a high capacity machine for production of a continuous slab of flat top flexible pu foam with easy operation.this machine comes along with a three conveyor system & a large touch panel for operation (plc-touch panel).
continuous foaming machine
8,500,000 - 40,000,000 Per Plant
This machine is for making round blocks continuously. These are used for Peeling rolls with very high yield. The machine is a round conveyor with independent mixing head, which takes its input from the maxfoam plant mixing head output. The machine has a high pressure TDI metering unit for fine cell foam production. The round block machine has 2 sets of blower units for blowing away the gasses.
Best Deals from Continuous Foaming Machine
Continuous Foaming Machine (RA-REW-55)
Get Price Quote
Continuous Foaming Machine is designed for a large scale of production. This machine produce different grades of high yielding quality foam with great economy. This is chosen by the companies for high production of foam of several grades.
continuous foaming machine
Get Price Quote
Continuous Foaming Machine, PROCESS: All the P.U. chemicals are first mixed together in a mixing chamber & then taken into a metal trough where the initial reaction takes place. The rising foam then passes from the top of the trough on to a variable width fall plate, which then leads the expanding foam block along a metal slat conveyor for further expansion. METERING SYSTEM: There are seven metering systems in all. All metering system are equipped with world class AC motors, AC variable speeddrives, special internal gear pumps (for very low slippage), pressure gauges & Recirculation network to ensure high class quality product.
continuous foaming machine
Get Price Quote
Continuous foaming machine is performance efficient and delivers reliable results. We have a team of experts who handle our quality department and ensure that our products meet both Indian as well as international quality standards. Our circular foam cutting machine is equipped with the following systems:
continuous foaming machine
Get Price Quote
Owing to our rich industry experience, we are one of the profound manufacturers and suppliers of Continuous Foaming Machine. These machines are available in three conveyor systems and meet the demands and requirements of our diverse clients. We design these machines by employing most sophisticated technology and fine grade raw materials. Some of the key attributes of these Continuous Foaming Machine are sturdy construction, high tensile strength, corrosion & abrasion resistance, easy operation and durability.
continuous foaming machine
Get Price Quote
Continuous Foam Re Bonding Machine We have manufactured and supplied the machine to ms sheela foam Inquire to know about the product
foam machinery
Get Price Quote
The Max Continuous Foaming Machine is the mostly used where the requirement are in huge demand. It is one of the leading way to manufacture the polyurethane foam as if the factories can produce the polyurethane foam at higher capacity of 200kg./minute. The densities which can be produced in this machine are 14kg./cubic meter to 50 kg./cubic meter. The machine designed by ALLIEDTECH MACHINE is using the super advance machine techniques to enhance the product quality with most relevant mandatory changes in modern time. Our machine hold the base to satisfy the demand of its buyer by producing the outstanding quality polyurethane foam by the machine. Manufacturing Process : The Continuous foaming machine is provided with the chemical tanks for namely all chemical like Toulene-di-isocynate , Polyol , methlene chloride , Stannous octane , Amine , Silicon and water with separate color tanks. Now the calcium carbonate is mixed with the polyol chemical into the mixing tank having capacity of 5000 kg. Now the mixed polyol base is taken as the density formulation base on it we are going to Foam Machine manufacturer. All the chemicals are feeded by the imported high accuracy chemical pump to the mixing head , in between all chemical are controlled with the pneumatic actuator 3 way valve system to control the flow of the chemical towards the mixing head when it is required. All chemicals are calibrated well before their output going towards the mixing head. The mixed chemical are spread on the chemicals falls plate and then the conveyor start to carry the manufactured foam towards the Block cutting machine . There is single slab stock of the length at least 70' at a single time. Now with help of the Block cutting machine which is installed at the conveyor end cut the block into desired size. After drying the block for few hours the , Vertical Foam cutting machine trim the block from all sides , then it is put on the Circular Foam Cutting Machine or Car soul Foam Cutting Machine to cut the it into desired thickness. Specifications : Can produce foam density from 14- 50 kg./cubic meter. Provided with High speed and advanced mixing head with self cleaning. Conveyor length of 50' which enhance the drying capacity of foam before cutting. Two chemical tanks of 1000 liters each with cooling jacket system with the machine. Separate control panel with Advance features which enable all controls very well. Most advanced chemical reaction and handling system. Automatic polyol, T.D.I and M.CL feeding system to the chemical tanks from the barrels. Advanced Block cutting machine attached with the end of the conveyor.
foam machinery
Get Price Quote
foam machinery, Pocket Spring Assembling Machine
continuous foaming machines
Get Price Quote
At A S Enterprises we have the best Machine Experts Designing the Continuous Foaming Machines for us. Our Foaming Machines can compete with the best foaming machines in the world. These foaming machines have a high production rate and are quite versatile in producing different grades of foam. These machines are quite economical and the Companies capable of selling large quantities of Foam in India use this Machine.
continuous foaming machines
Get Price Quote
continuous foaming machines, foam machine, injection foaming machines
continuous foaming machine
Get Price Quote
continuous foaming machine, batch foaming machine, Foam Cutting Machine
Flat Top Continuous Foaming Machinery
Get Price Quote
Flat Top Continuous Foaming Machinery, polyurethane foam machinery
foam machinery
Get Price Quote
foam machinery, vertical cutting machines, mattress making machine
CONTINUOUS FOAMING
Get Price Quote
CONTINUOUS FOAMING, DIS CONTINUOUS FOAMING, HORIZONTAL CUTTING
Continuous Foaming Machine Fm200
Get Price Quote
Continuous Foaming Machine Fm200, edge rounding machine
foam machinery
Get Price Quote
foam machinery, pu foam machine, cutting machinery, batch foam machine
