Core Shooter Machine Dealers

These Amine Cold Box Core Shooters (Horizontal Parting Machine) are made from very high quality raw material which ensures hassle free work performance at its user end. These Amine Cold Box Core Shooters (Horizontal Parting Machine) are widely finds its applications in various industrial sectors.• Sample Availability : Yes • Supplier Product Code : SHRI-12

• Condition: New
• Material: Metal
• Plate size: 300x400, 400x600
• Core size: Suitable for small and medium size cores
• Core volume: Suitable for small to medium size volume
• Use: Industrial

Headquartered in Kolhapur(India), we are making available high quality products to every nook and corner of the country. Interested buyers can purchase Rollover Type Auto Core Shooter Machine from us in bulk and retail, as we are its reputed supplier.

IT IS SPECIALLY TAILORED & TOOLED UP ROBOTIC CORE CENTRES WITH INTEGRAL SAND PREPARATION & FEEDING SYSTEMS, CORE COATING, DRYING & HANDLING SYSTEMS ARE DESIGNED & EXECUTED TO SUIT REQUIREMENTS

We offer Core Shooter.

We have carved a niche as one of the most promising Automatic Shell Core Shooters Manufacturers and Suppliers in India. Designed to precision, our Automatic Shell Core Shooters find their application in diverse industrial processes. Fabricated with the help of innovative techniques and modern machinery, these Automatic Shell Core Shooters have high strength and have a longer functional life. Furthermore, the clients can avail these Automatic Shell Core Shooters at very reasonable rates in the markets. Attributes Robust construction Reliable performance Better quality Longer service life Features In-Built control system Safety interlocks Air blow gun for cleaning purpose Heavy-duty bars for core box carriage plates Pneumatic clamping system Pneumatic cylinders with Control Panel Sizes Available 300 X 400 400 X 500 500 X 600

Our rich industry experience also lies in successfully handling the emerging industrial market requirements for Core Shooter Machines. As a leader in the field of construction of core shooter systems, here our rich experience in the field of design and construction helps us to make available the technically advanced solutions that are specifically tailored for meeting the specific end process needs of the customers. Further, our expertise also lies in offering competitive technical consulting support that aids clients to select most suitable technology/process for core production. With the offered core shooter range being fully automatic and of high performance, their hydraulic based operations are controlled by software. These are offered in different capacities with option of parting horizontally or vertically. The core systems involved in the production program include :• Vertical parting  • Horizontal parting  • Combined systemsAutomatic machines for use in applications/processes like• Shell moulding  • Hot box  • Shell Mould Fuser  • CO2  • SO2  These core shooting machines can also be automated on parameters like:• Core box clamping  • Shooting plate clamping  • Gassing plate clamping  • Core removal template clamping  • Core box cleaning  • Lubrication system  Machine's Strengths:• Shooting head designed to achieve high and more uniform core density• Rapid clamping core box that helps in providing for quick tooling changeover• Hydraulically operated operations• Shorter cycle time through use of multi station machine support• Can be custom-designed to customer's given working specifications

We are offering core shooter machine. High productivity. Sks shoot volume from 5 kgs to 50 kgs. Average machine cycle time from 10 - 30 sec. Core box clamped by pneumatic & hydraulic cylinder. Plc is the core place for all functions. Core box clamped by horizontal or vertical. operation is by pneumatic or hydraulic supply and each auto operation is controlled by plc electrical panel board. Amine gas generator, and compressed air dryer is built into the machine. range 5 kgs to 50 kgs. We customize on your request.

• Certification: CE Certified
• Automatic Grade: Automatic, Manual
• Power: 6.4 Kw
• Features: Longer Working Life, Efficient Performance, Reduced Maintenance Cost
• Material: MS. SS, iron
• Greatest Weight: 6 Kg the Biggest
• Sizes L X W X H: 400X280X200mm Heating
• Mould: Less than 250 mm
• MOQ: As per Client Request

• Core Box Size: 450 X 450 mm.
• Core Box Thickness: 200 mm
• Core Weight: 5 Kg.
• Sand Hopper Capacity: 50 Kg.
• Electrical Load: Max 1.5 KW.

Blow Area: 400 X 400 mm   Pneumatic Pressure Required: 6 to 7 Kg./cm2   All Functions are Managed by APLC: No   Fully Automatic With Ejection: No   Average Machine Cycle Time from Sec. (Without shoot and Exhaust): 10 Sec

• Material: MS
• Voltage: 440 V
• Weight: 1 Ton
• Air Pressure Required: 10 Bars
• Machine Type: Automatic
• Frequency: 50 Hz
• Production Capacity: 10

Manufacturer the machine as per industry standard. We also have the capability to produce it , according to the plate size specification provided by our customer. It is extremely demand for its unique feature of roll over & top shooting,swing door on vertical axis,pneumatic hydrolic control operations,plc control,minimum maintenance.

• Country of Origin: Made in India
• Sand Hopper Capacity: 05 TO 100 KG
• Capacity: 5 to 120 kg
• Usage/Application: CORE PRODUCTION
• Machine Type: Foundry Core Shop Machineries
• Automation Grade: Fully Automatic
• Material: Iron

• Weight: 3800 kgs.
• Gas Heating: LPG
• Die Size: 600 x 600
• Power Consumption: 3 HP
• Dry Cycle Time: 20 sec
• Open Height: 1000 mm
• Shut Height: 400 mm

Plate size : 500*700, 600*800, 600*1200, 500*1100Core sizes : Medium to big coresCore volumes : Medium to highOperation : Pneumatic, hydrualic

• Brand Name: Navdis
• Material: MS
• Power Source: Electric
• Voltage: 220-240 V
• Automatic Grade: Fully Automatic
• Power: 24 kW
• Capacity: 0.1 kg to 20 Kg
• Air Pressure Required: 6 to 8 Kg/cm2
• Frequency: 50 Hz
• Hoper Capacity: 100 kg
• Maximum Core Box Size: 400X800 mm
• Minimum Core Box Thickness: 100 mm
• Maximum Core Box Thickness: 200 mm
• Dimension: 3 X 2 X 3.25 Meters

• Country of Origin: Made in India
• Voltage: 415 V
• Features: Easy to install, Excellent functionality, Impeccable performance
• Automatic Grade: Semi Automatic
• Phase: Three Phase
• Material: MS
• Power Source: Electric

• Overall Dimensions: 2x2.5 x 2.5 Ht in Meters
• Maximum size of core box vertical parting: 300mm x 500mm x 200mm thick
• Maximum size of core box horizontal parting: 400mm x 500mm x 200mm thick
• Maximum core weight: 10 kg, 15kg, 20kg, 25kg. Sand magazine capacity 50kg, 70kg.
• Air Consumption: 25cfm, 40cfm, 60cfm.
• Air Pressure: 5-6 Bar

We carry different types of Cold Box Type Core Shooter to fulfill the varied needs of our clients. It is widely used in the Foundry industry. We also custom manufacture it according to the guidelines of our customers. The machine possesses unique attributes such as: Air Drier Unit Good Core Weight Fast and Simple Operation Rigid Construction High Output Easy Maintenance

• Ranges ofered: 5 Kgs. To 150 Kgs.

Salient Features SSEC Cold Box Core machines are known for the ruggedness and durability. Operates with gas cured process. The cores are cured and stripped at a very high speed. SSE C Cold Box Core Shooter machines are available either with Horizontally  or vertically parted Core boxes. Machine operates in Automatic mode with sand blowing, gassing and purging cycles. Machines can be supplied with automatic core removal also. Quick changing of tools. PLC Control Systems.
