Creep Drive Dealers

Creep Drives

Get Price Quote

The creep drive is manufactured from high quality raw materials that make it highly efficient in performance. The creep drive offered by the company provides low backlash that is the major reason for high demand in the market. special features large ratio in compact sizespecial seal design for bearing long lifeused in winch, cranes etc technical specifications mounting : footratio : as per customer requirementhp : 0.5 hp to 50 hp

Creep Drive

Get Price Quote

Used for creep speed in crane application,Planetary gear box inside,Ratio available 10.,Drum dia- 100mm To 400mm,from 1hp To 25hp.

Creep Gearbox Drives

Get Price Quote

• Material: Mild Steel
• Application: Material Handling Equipments
• Color: Blue
• Feature: Long Working Life
• Finishing: Paint Coated
• Phase: Single Phase

Planetary Creep Drives

Get Price Quote

The Planetary Creep Drives that we bring forth are highly appreciated by the customers for their superb quality. The Planetary Creep Drives that we provide are fabricated from high grade components that results in their longer functional life. Additionally, we are one of the celebrated Manufacturers and Suppliers of Planetary Creep Drives. Ideal For Extra speed and power reduction in overhead cranes Attributes Thruster brake Diameter : from 100 mm to 400 mm Power : from 0.33 Kw to 15 Kw Ratio : from 3.5:1 to 30:1 Inline power transmission

Creep Drive

Get Price Quote

We are counted among leading Hydrostatic Creep Drive Manufacturers in India. Our wide range of Creep Drive is widely recognized by leading manufacturers of Industrial Machinery, Steel Plants, packaging machinery and many more. Creep Drive is used for overhead cranes to achieve micro speed. Our Planetary Creep Drive have Torque Capacity of 50 Nm – 1000 Nm. We serve Foot Type Creep Drive with power rating 2 KW – 40 KW. The Brake Drum diameter of our product is 160 mm, 200 mm, 250 mm, and 300 mm. Their reduction ratio is 10:1 which can be modified as per requirements. These drives are used for overhead cranes to achieve micro speed Torque capacity – 5 Kgm to 100 Kgm. Brake drum dia. 160mm, 200mm, 250mm, 300mm Reduction Ratio – 10 : 1 Input – Solid ( free ) 0.5 HP to 50 HP Mounting – Foot type Torque capacity – 5 Kgm to 100 Kgm. Brake drum dia. 160mm, 200mm, 250mm, 300mm.

Creep Drive

Get Price Quote

We manufacture a large gamut of Creep Drive, which is manufactured from superior quality raw materials. The creep drive that we offer can be availed in different specifications and capacities to meet the customer’s requirements. We are widely well reckoned as one of the predominant creep drive exporters and suppliers from india. working principle the working principle of these drives is the planetary principle with drive system and thruster brake. Attributes highly efficient in workingassured to have zero defectshave high durability uses it is used in motors for achieving micro speed.

Kavitsu Planetary Creep Drive

Get Price Quote

We are the top supplier of planetary creep drive. we supply the best quality planetary creep drive which has a wide spectrum of industrial applications. Good quality raw materials are used in the manufacturing process of these planetary creep drives. They are available in various torque and input power options.

Creep Drive

Get Price Quote

We offer a Easy-to-fit, Shaft Mounted Sugar Crystallizer Drive rated up to 10.0 HP & for Output speeds 0.25 to 1.5 RPM to cover standerd range of Sugar Crystallizer Drives. Sugar Crystallizer Drives are avialble at : Horizontal type Suger Crystallizer Drive 20T to 120T Capacities. Vertical type Sugar Crystallizer Drive up to 500T Capacity. Developed after an in-depth study of typical Crystallizer installations, BEACON GEAR TRANMISSIONS Crystallizer Drive employs High Efficiency Planetary gearing instead of conventionally used Worm Gearing. The overall efficiency of BEACON Sugar Crystallizer Drive is better than 90% and installed motor rating is optimally used resulting in attractive savings in power consumption.

Creep Drive

Get Price Quote

We are one of the prime manufacturers and exporters of a wide range of Creep Drive that is primarily used for achieving micro speed for overhead cranes. The basic principle on which they work is planetary principle with differential drive system and a thruster brake. It comprises of Planetary Speed Reducer that is mounted on two bearings for achieving creep speed, by clamping the body of the drive with shoe brake or by any means which application demands. To avoid alignment problems, these Creep Drive are mounted on the single base frame. Advantages : Positive Creep Speed with full load and also light load or even no load.The Creep Speed is one hour continuous rated against the shorter time ratings of other method.Creep Drives are free input and free output type as per dimensions given, we can supply braking system with the drive on customer’s request. Preferred for : Easy Installation Rugged construction Speed reduction with Planetary drives Bearings are proportional Considerably higher efficiency Long working lifeVery high factor of safety.

Creep Drive

Get Price Quote

• Ratio: 1:5 to 1:10
• Torque: 70 Nm to 3000 Nm
• Power: 0.5 Kw to 15 Kw

The creep drive is a special planetary gearbox where in the input & output shaft both are solid and the body is mounted on both the sides with pedestal bearings. The constriction of creep drive is single stage planetary. The creep gearbox installed after main motor. Hoist gear box starts the reduction which is primary reduction to main gear box however when high speed required creep motor is off and brake is released and main motor gives drive to the primary gear box.

Creep Drive

Get Price Quote

• GEAR BOX OUTPUT SPEED IN RPM: 90
• MAIN MOTOR POWER IN HP: 0.5,1,1.5,2,3,5,7.5,10,15,20,25

creep speed drive, one can get 2 different speeds (typically lower speed is 10 % of normal speed) on same shaft. Creep speed drive unit includes 3 different parts assembled together viz. induction motor, helical gear box, electrically applied clutch.Typical application of this creep speed drive would be horizontal long travel mechanism of crane. Imagine that total long travel span of a crane is 40 feet. And crane operator is required to drop (already lifted load) at distance of 37th feet.

Creep Drive

Get Price Quote

• dia: 160mm , 200mm, 250mm, 300mm
• Power rating: 2 kw to 40 kw

These drives are used for overhead cranes to achieve micro speed Torque capacity 50Nm to 1000 Nm, Reduction ratio - 10 :1 ( Different ratio can be given on request. ).

Creep Drive

Get Price Quote

Planetary Gear Drives, has come out with specially designed Planetary Creep Drives for overhead cranes. Creep Drives has a nominal ratio of 10 : 1 and are ideal for getting positive creep speed for full load. All the gears are made from proper grades of alloy steels and hardened. The foot brackets and housings are made of cast steel. The input shaft of the Creep Drive is connected to the creep motor and the output shaft is connected to the main motor. The complete creep gear box is free to rotate on bearings which are fitted in foot pedestals. The shoe brake is fitted on the base and is applied on the outside diameter of the ring gear. In normal running, the brakes are open, main motor is running and creep motor is stationary. In creep mode, the creep motor is running, the main motor is off and the brakes are on.

Creep Drive

Get Price Quote

Creep Drive, Bevel gears, helical gear box, Helical Gear, Gear Box

Planetary Creep Drives

Get Price Quote

Planetary Creep Drives, hypoid gear, waterproof junction box, servo gearbox

Creep Drive

Get Price Quote

Creep Drive, lift duty reduction gear box, high torque gearbox

Creep Drives

Get Price Quote

Creep Drives, Geared Motors, Nauta Mixer, planetary belt conveyor drives

Creep Drive

Get Price Quote

Creep Drive, Slewing Drives, planetary drive, Hydraulic winches

Creep Drive

Get Price Quote

Creep Drive, Planetary Gear Box, Shaft Mounted Gear Box, helical gear box

Creep Drive

Get Price Quote

Creep Drive, Digital Programmable Thermostat, digital room thermostat
