Crock Meter Dealers

We are offering our clients a wide range of Crock Meters that is used to check the color fastness of the fabric samples. Our crockmeter is a sturdy and simple to use instrument with a unique specimen holder that assures correct presentation of sample to the peg. These are used for determining the rubbing color fastness and staining properties of dyed or printed textile samples. The tests related to rubbing fastness tests are conducted into dry conditions, in which the samples are rubbed with wet undyed crocking cloth. Apart from this, the staining of crocking cloth is assessed with a grey scale. Our meter also consists of an A.G. geared motor running at 60 RPM & connected with a counter. To prevent slippage during the test of silky type of fabric samples, the use of emery paper on the platform is most suitable. In this, the sample specimen is fixed on the platform & fastened by the specimen holders. The sample is assessed with the assistance of Grey scale, once the rubbing action to & Ira 10 times gets completed 10 times in a straight line, along a distance of 10 cm, within a time span of 10 seconds. Specifications : Used to check the color fastness of the fabric samples. Assures correct presentation of sample to the peg. Checking of fastness properties of processed samples. Quality control checks.

• Type: Crockmeter
• Applications: Leather Testing
• Test: colour transferred

We are suppliers of Crockmeter For Leather, One of the tests for determination of colour fastness of dyed of printed leather is the crocking test. This test is used for the determination of colour fastness against rubbing, either under dry or wet condition. In this test a moving brass finger of specified shape and size rubs against the test specimens under a fixed load. The amount of colour lost by the test specimen and the amount of colour transferred to a piece of abradant Leather fixed over the base of the moving finger are graded with the help of standard grey scales to evaluate the colour fastness of the sample under test rubbing. Specifications

• Diameter of the finger ( for all fabrics & Textiles: 16 mm
• Force on the finger ( for all fabrics & Textiles): 9 ‘N’
• Size of Crocking Cloth: 9 ‘N’
• Dia of the finger: 5 x 5 mm
• Force on the finger: 25 mm
• Size of Crocking Cloth: 7 x 7 cm
• Length of the traverse of the finger: 100 + 4mm
• Digital Counter: 4 digit counter
• Grating of stainless wire: 1mm. dia & a width of mesh of about 20mm.

• Yarn: 15 tex (40/1 cotton count), 5.09 turns/cm "z
• Thread Count: 32 +/-3 warp ends/cm: 33 +/-3 picks filling/cm
• Weave: 1/1 plain
• pH: 7 +/-0.5
• Mass/sq. meter: 113 +/-5g greige: 100 +/-3 g finished)
• Whiteness: W = 80 +/-2

Originally designed to simulate the action of a human finger and forearm, the Crockmeter uses a standard pressure and rubbing motion to provide reliable and reproducible test results.  Specimens are positioned on the base of the Crockmeter and held in place with the sample holder. To prevent the specimen from shifting during testing, a sandpaper pad is provided to place under the specimen.  A hand crank moves a reciprocating arm a distance of approximately 100mm. The rubbing action is provided by a 16mm diameter acrylic "finger" which moves back and forth in a straight line with each complete turn of the crank. The reciprocating load arm is weighted to provide a constant 9N load on the sample at all times and a mechanical counter keeps track of completed cycles.  Abradants A standardized crocking cloth is most often used as the abradant for textile applications.  This square (or sometimes circular) cloth is wrapped around the acrylic crock "finger" and held in place with a wire spring clip.  AATCC Method 8 specifies the cloth should meet the following specifications:

Crock meter is used to determine colour fastness to dry & wet rubbing and staining properties of dyed and printed textile fabrics AC geared singe phase motor with 60 rpm Electronic counter with proximity switch ,Provided with 6 Amp plug top.

• Brand Name: M&T Engineering works
• Shape: Rectangular
• Condition: New Used
• Rated Power: 250W
• Power Source: Electric
• Application: Laboratory
• Size: 2feetx6inchx9inch

Our basic materials, which are used for the production of our finished goods, are cross examined over diverse aspects in order to ensure its excellent quality. The checking is done by our experts. In order to suit varied requirements of the clients, we have developed a secure payment procedure that have assorted offline and online options.

• Condition: New
• Power Source: Electric
• Material: Steel
• Application: Household,industrial,Laboratory
• Finish: Polished

A standard Crocking Cloth used to determine the color fastness of textiles to dry/wet rubbing as per ISO Method. 100 pcs pack 7 cm x 7 cm Dispatch Time :

• Type: Electronic Enclosures
• Material: Aluminium
• Shape: Rectangular
• Application: Laboratory
• Feature: High Accuracy
• Voltage: 220V
• Display Type: Digital
• Power Source: Electric
• Warranty: 1Years
• Brand Name: IKON INDUSTRIES
• Rated Power: 230V
• Color: Grey
• Standard: BS 1006 D02, AATCC 8/165, AATCC 8/165
• Calibration: Traceable to NABL
• Dimensions: 725 mm 305 mm 305 mm.
• Weight: 25 Kg

Utility: To determine the colour fastness of textiles to dry or wet rubbing provided with a crocking finger of 16mm diameter with a down ward force of Newton's and facility for mounting standard crocking fabric. A pinned acrylic sample holder ensures rapid sample mounting and repeatability of results. Available in various models MOC: SS 304 / 316

• Application: Laboratory,Industrial, Laboratory
• Brand Name: Asia Vision Instrument
• Material: Mild Steel
• Automation Grade: Automatic
• Finger Load: 900 g
• Finger Diameter: 16 mm

MYQ Colour fastness to rubbing is the most basic of colour fastness tests, Crockmeter is used to determine colour fastness to wet and dry rubbing. Specimens are rubbed with dry, standard cotton cloth (Crocking cloth) and again, if applicable, with wet cloth. The staining of the crocking cloth is assessed with an AATCC or SDC Grey Scale.   Equipment Hand Opreted crock meter is used for determination of color fastness of dyed & printed textile to dry & wet rubbing. This equipment is designed with 16mm diameter finger & length of traverse 100(±5)mm. The display comes digitally on the panel. The test specimen is held firmly over standard abrasive paper (Emery paper) with the help of specimen holder. The equipment is built on a mild steel base to give the stability and rigidity.   Salient Features Diameter of the rubbing finger :16mm Load on the finger : 9 N Specially designed acrylic clamp to mount the test garments. Supplied with all accessories. Length of the traverse of the finger: 104± 3mm   Accessories : Main Unit : 01 No. Finger (f16mm fitted in the unit) : 01 No. Spring Clips (for finger f16 mm) : 02 Nos. Specimen Holder (Acrylic) : 01 No. The User manual : 01 No.   Related Standards - ISO 105 x 12/D02 , AATCC 8 / 166, BS 1006 D02

• Type: Crock Meter
• Certification: CE Certified, ISO 9001:2008
• Feature: Durable, Stable Performance
• Warranty: Lifetime Buyback Warranty
• Country of Origin: India
• Brand Name: Paramount

This economical Equipment is used for testing the transference of color from the surface of small print to another surface by either wet or dry rubbing. The textile material can be any textile in the form of Textile Fiber, Fabric & Textile floor covering Specimens are rubbed with dry, standard cotton cloth (Crocking cloth) and again, with wet cloth. The staining of the crocking cloths is assessed with a Grey Scale. Paramount Crockmeter i9 ( Rotary) main unit is made of mild steel with a reciprocating arm & 16 mm finger. An 11.1 N load is exerted on the finger to meet the specification of American buyers. The rotary vertical Rotary crockMETER i2™ provides a reciprocating rotary motion to the test finger and a selected pressure on the test finger. Metal finger clip is supplied with the equipment for proper gripping of the crock square. The crocking base is provided with emery paper. The equipment is finished in metallic blue paint

• Display Type: Digital
• Diameter of Rubbing Finger: 16 mm
• Force on rubbing finger: 9 N ( 917.43 g)
• Length of Traverse: 100+/- 4 mm
• Model: NTF MCM 1331
• Size of Crocking Cloth: 50 x 50 mm
• Size of test specimen: 250 x 50 mm
• Usage/Application: Laboratory
• Brand Name: NTF

• Country of Origin: Made in India
• Voltage: 220 V
• Rated Power: 1 Kw
• Application: Laboratory
• Phase: Single Phase
• Brand Name: Asian
• Load on the finger: 900 g
• Frequency: 50 Hz
• Dimension of test specimen: 250 x 50 mm
• Size: 2 x 1 x 1 Feet
• Diameter of the finger: 16 mm

We are an eminent firm occupied in providing the best class Digital Motorized Crock Meter that is highly applauded by our prestigious customers all across the country. With due precision, the crock meter provided by us is fabricated with the consistent improvisation of upgraded techniques and quality approved components in tune with industry quality standards. Having its applications in textile industry, this crock meter is made available in different technical at reasonable prices with no hassle.

• Country of Origin: India
• Type: Motorized Screen
• Feature: High Performance
• Condition: New
• Finishing: Powder Finish
• Brand Name: SUPERLAB
• Material: MS
• • Diameter of the Rubbing Finger: 16 mm & 25 mm. • Force on the Finger : 9 N & 20 N.: • Size of Crocking Cloth : (5 x 5) Cms & (7 x7) cms. • Length of the Traverse : 100 ±5 mm Counter (Re-settable).
• 4-Digit Counter Size of Test Specimen: • Dimension of the Unit : 400 (W) x 700 (D) x 200 (H) mm.

To determine the Color Fastness of Textiles rubbing at wet /  dry  condition. The equipment consists of a digtal pre set counter. It also consists of an  mptorised operating system Tests the color fastness of the textile in a very accurate manner. It gives not only accurate but quick results also

• Material: Aluminium
• Shape: Rectangular, Square
• Voltage: 110V
• Application: Industrial, Laboratory
• Display Type: Analog, Digital
• Rated Power: 100W
• Power Source: Electric
• Feature: Durable, High Accuracy

We are instrumental in offering ISO 105 X 12/D02, BS 1006 D02, AATCC 8/165 approved Crock Meter. Crock Meter is used for determining the colorfastness of fabric against rubbing in dry or wet conditions. Our Crock Meter features easy to reset counter and consumes less power. Suitable for all kinds of fabric, the Crock Meter is made available in different specifications to meet all the needs of our customers. Further, our Crock Meter is well-acknowledged for excellent testing performance, synchronous motor speed and long service life. Technical Specification : Traverse Counter Digital Display Diameter of Rubbing Finger 16 mm Force on rubbing finger 9N ( 917.43 g) Traverse of rubbing finger 100 ± 3 mm With 2 Nos SS Spring Clip for holding crocking cloth With 2 Pack of Crocking Cloth (Pack of 100 Pcs.) Size of test specimen 250 x 50 mm Size of Crocking Cloth 50 x 50 mm

• Type: Manual
• Material: Iron, Mild Steel
• Certification: ISI Certified
• Application: Laboratory
• Color: Grey
• Warranty: 1 Year

The equipment is operated by a gear motor, and the arm moves in an oscillating motion over the test specimen with a specified load & diameter (approximately of a fore-finger). The rubbing finger has a flat base which is covered with a piece of standard white crocking cloth, which in turn is held by a stainless steel spring clip and is made to move over the test sample in an oscillating motion. The equipment is operated by a gear motor, and the arm moves in an oscillating motion over the test specimen with a specified load & diameter (approximately of a fore-finger). The rubbing finger has a flat base which is covered with a piece of standard white crocking cloth, which in turn is held by a stainless steel spring clip and is made to move over the test sample in an oscillating motion. The crocking cloth picks up the color lost by the sample under test. A 3 digit reset counter is provided to enable it to take the desired number of rubs and the same is displayed on the digital counter. The Test specimen is held by the Abrasive paper with the help of an acrylic plate mounted on the solid base and the equipment is finished with a metallic paint adding to its aesthetic appeal.
