Dalia Making Machine Dealers

The Techno Wings Daliya Making pulverizer are used for a producing dalia of wheat ( broken wheat for wheat porridge, dalia), Maize daliya Construction of Dalia Making Machinery Commercial dalia machine is made from heavy duty cast iron base. Cast iron oil chamber housings for long life of bearings. Aluminum Grinding Chamber lined with serrated Stainless Steel plates, which protects the body from wear and tear. Grinding done by a set of Stainless fixed better on a balanced rotor. A screen classifier forms the lower half of the grinding chamber.

• Weight: 100-500kg
• Voltage: 220V
• Power Consumption: 1 H.P. to 70 H.P.
• Capacity: 50 Kgs to 2300 Kgs per hour
• Warranty: 1 Year

Used for making edible dalia of wheat. maize etc. By this machine a superior quality dalia can be made. You can get dalia in round shape in various grades. Wastage of grinding material seperated automatically.

• Driven Type: Ekectric
• Condition: New
• Automatic Grade: Automatic
• Power: 1-3kw
• Voltage: 110V, 220V
• Weight: 100-500kg
• Warrenty: 1year

• Type: Automatic
• Certification: CE Certified
• Condition: New
• Frequency: 60Hz
• Driven Type: Electric
• Sound: 25-50Dba
• Warranty: 1 Year

Rava Making Machine that we supply is widely used in food industry for making rava. We procure Rava Making Machine only from the reliable manufacturers and vendors after stringent checking on different industry laid standards to ensure zero defects at buyer’s end. Manufactured from high grade quality raw materials, our Rava Making Machine is accredited for its robust construction, smooth functionality and longer operational life.

• Automatic Grade: Semi-Automatic
• Power Consumption: 5 kW
• Voltage (V): 220
• Power Source: Electricity
• Condiiton: New
• Capacity: Up to 500 kg /hr
• Usage/Application: Food Processing

• Application: Seed Grading
• Voltage: 220V
• Automatic Grade: Automatic
• Driven Type: Electric
• Production Capacity: 100-500kg/hr
• Power: 1-5kw

Makai Grading machine

• Type: Dalia Making Machine
• Weight: 100-500kg, 1000-2000kg, 2000-4000kg, 500-1000kg
• Color: Black, Brown, Grey, Light White
• Voltage: 110V, 220V, 380V, 440V
• Condition: New, Used
• Automatic Grade: Fully Automatic, Manual, Semi Automatic
• Power: 1-3kw, 3-5kw, 5-7kw, 7-9kw, 9-12kw
• Driven Type: Hydraulic, Penaumatic, Electric
• Warrenty: 1year, 2years

Application of Dalia Making Machinery The Techno Wings Daliya Making pulverizer are used for a producing dalia of wheat ( broken wheat for wheat porridge, dalia), Maize daliya Construction of Dalia Making Machinery Commercial dalia machine is made from heavy duty cast iron base. Cast iron oil chamber housings for long life of bearings. Aluminum Grinding Chamber lined with serrated Stainless Steel plates, which protects the body from wear and tear. Grinding done by a set of Stainless fixed better on a balanced rotor. A screen classifier forms the lower half of the grinding chamber.

• Country of Origin: Made in India
• Features: Easy Maintenance, Lower Operational Cost , Application Specific Design , Rigid Construction , Longer Serving Life.
• Capacity: 40 Kg/h
• Operation Mode: Semi-Automatic
• Electricity Connection: Single Phase
• Motor Power: 3 HP
• Material of Construction(Contact): MS
• Power Consumption: 2 Kwh
• Surface Finish: Powder Coated
• Brand: SR

Description of Dalia Making MachineCracked wheat or daliya is used to make a nutritious dish at breakfast or whenever a light meal is required. It can be made sweet or salty according to taste. The wheat is boiled in a little water and cooked till it becomes soft and the water evaporates. Sugar and milk may be added to the cooked wheat or it can be seasoned with salt, pepper and butter before serving.We have for our client commercial dalia machine that have fully machined & balanced beater. These commercial daliya machines are popular for continuous crushing and suitable for making daliya. Offered in compact size commercial daliya machines do not require too much space. Key features of dalia making machine Unique and reliable design of the dalia making machines series pulverizers are highly effective as well as nonstop continuous pulverizing process. All contacting parts are non corrosive materials. All rotating parts are dynamical balanced for less vibration and higher performances. Low temperature grinding technology thus the original ingredient cannot destroy. Ideal for dry crushing Increased production leading to faster return on the investments Hardened and fully machined shelving type beater thus less wear and tear. Single pieces grinding chamber no separate joints of fabrication for out late. Operating principle of dalia making machinery The flow of material from the feeding hopper is regulating by means of side handle easily to suit the load. Rotor runs in anti-clockwise direction. The beater pass just beneath the ratchet teeth liner fitted inside the top half of the crushing chamber, leaving a suitable gap between the liner teeth and the tips of the rotating beater. This cuts the material caught between the liner teeth like a sword with a scissors action at a 450/650 RPM. After the required size reduction, the material will pass through the screen fitted inside the lower discharge end of the grinding chamber. No sieving is required, as the appropriate size screen fitted will not allow coarser material to pass through. The air generated in the crushing chamber forces the powder to pass through the screen fitted at the bottom discharge end of the crushing chamber, into a filter attached to the delivery trough below. (When crushing wet-pulpy materials, the balloon should not be use) Servicing guidelines of dalia making machinery Open the cover of chamber all grinding parts cleaned with a brush in couple of minute and the pulverizer is ready for next grinding. If required, the grinding chamber can also washed with water. Remove the cotton balloon and the screen, close the cover tightly and start the grinder. Now pour a bucket or two of water into the hopper. The grinding parts will be flushed with the water and cleaned. Continue running the machine for a few more minutes as the draft of the fresh air sucked into the grinder will dry it. Please check the oil level of oil bath chamber regularly. Standard accessories of dalia making machinery Three set of perforated round holes screens Easy movable hopper helps you to ensure continuous and steady feed to the machine. Very useful where feed material is to be manually dumped from bags Motor pulley One numbers of cotton balloon. Mid steel fabricated foundation plate with adjustable rail for motor. Extra accessories of dalia making machinery Suitable totally enclosed fan cooled single or three phase squirrel cage motor as per is: 325 or 996 is supplied with mono pulverizer {electricity (special power can be accommodated): 110/220/380/415 volts, 50/60 Hz, 1/3 phase } Suitable miniature circuit breaker as per is: 8828 with 3 meter cable and 3 pin top as per is: 1293 are supplied with daliya machine as extra cost or 3 meter 4 core cable, starter, ampere meter, and capacitor, are supplied with daliya machine at extra cost. All contacting parts stainless steel 304 / 316 can be accommodated Application of dalia making machinery The techno wings daliya making pulverizer are used for a producing dalia of wheat (broken wheat for wheat porridge, dalia), maize daliya. maize grits, corn grits, etc.. Construction of dalia making machinery Commercial dalia machine is made from heavy duty cast iron base. Cast iron oil chamber housings are for long life of bearings. Aluminium grinding chamber lined with serrated stainless steel plates, which protects the body from wear and tear. Grinding done by a set of stainless fixed better on a balanced rotor. A screen classifier forms the lower half of the grinding chamber.Due to continuous improvements, we reserve the rights to alter and/or amend dimensions/design without prior notice. The figure for capacities given are for guideline only may very force case to case and depending many factors.

wheat maize dalia making machineused for making edible dalia of wheat, maize etc. By this machine a superior quality dalia can be made. You can get dalia in round shape in various grades. Wastage of grinding material seperated automatically. power consumption : 1 h.p. To 70 h.p.capacity : 50 kgs to 2300 kgs per hour

Unique and Reliable Design of the Dalia Making Machines series pulverizers are highly effective as well as non stop continuous pulverizing process All contacting parts are non corrosive materials All Rotating parts are dynamical balanced for less vibration & higher performances Low temperature grinding technology thus the original ingredient cannot destroy Ideal for dry crushing Increased production leading to faster return on the investments Hardened & fully machined shelving type beaters thus less wear & Tear Single pieces grinding chamber no separate joints of fabrication for out late Operating Principle of Dalia Making Machinery The flow of material from the feeding hopper is regulating by means of side handle easily to suit the load. Rotor runs in anti-clockwise direction. The beaters pass just beneath the Ratchet Teeth Liner fitted inside the top half of the crushing chamber, leaving a gap of 3 mm between the liner teeth and the tips of the rotating beaters. This cuts the material caught between the liner teeth like a sword with a scissors action at a 450 RPM. After the required size reduction, the material will pass through the screen fitted inside the lower discharge end of the grinding chamber. No sieving is required, as the appropriate size screen fitted will not allow coarser material to pass through. The air generated in the crushing chamber forces the powder to pass through the screen fitted at the bottom discharge end of the crushing chamber, into a Filter attached to the delivery trough below. (When crushing Wet-Pulpy materials, the balloon should not be use)

• crushing Chamber size: ø 300 mm X 150 mm
• Required Motor: 5 HP

Daliya Making Machines is used to make a nutritious dish at breakfast or whenever a light meal is required. It can be made sweet or salty according to taste. The wheat is boiled in a little water and cooked till it becomes soft and the water evaporates. Sugar and milk may be added to the cooked wheat or it can be seasoned with salt, pepper and butter before serving.All rotating parts are dynamical balanced for less vibration and higher performances.

• Features: Longer working life , Less maintenance

This machine is manufactured under the stern vigilance of our adept professionals by utilizing optimal quality components at our modern premises. Finding its application in food processing industry, the provided machine is used for processing dalia in simple way. In addition to this, the offered Dalia Making Machine.

We offer superior quality Dalia Making Machines. These machines are acknowledged amidst our clients for sturdy configuration and better performance. Our range of Daliya machines are manufactured using high quality raw materials and precision-made parts.
