DC MCB Dealers

• Country of Origin: India
• Application Area: For Solar
• No. of Poles: 1, 2 & 4
• Rated Current: 6, 10, 16, 20, 25, 32, 40 & 63 AMP

The Micron DC MCBs is a protective device equipped with thermal & electromagnetic release for circuit protection against overload & short-circuit current in DC distribution system equipment and electric equipment. Devices are designed for direct current (DC) applications mainly Solar PV & others like Electric Vehicles, Charging Stations, Battery Storage and UPS Systems.   Technical Information: Standard conformity : IS/IEC 60898:2/ 60947:2 Rated Current (In) : 6, 10, 16, 20, 25, 32, 40 & 63 AMP Rated Breaking Capacity (ICU) : 6000A (6 kA) Rated Voltage (Un) : 1P: 250V, 2P: 500V & 4P: 1000V No of Poles : 1, 2 & 4 Rated Insulation Voltage (Ui) : 500 V Rated Impulse Voltage (Uimp) : 4 kV Energy Limiting Class : Class 3 Ambient Temperature (˚C) : -5˚ to 55˚ Degree of Protection : IP20 Trip Type : Thermal and Magnetic  Installation Category : Class III  Mounting : Snap on Din rail at (35mm x 7.5mm) Connecting Terminals : Box Type/35mm² ON-OFF Indication : Positive Indication as ON (RED) & OFF (GREEN) Connections : Dual Connection Level (Bus Bar + Cable) Features:  CE marking fulfils the requirement of Global Standard. Protection the PV Module from dangerous high DC back current. Applicate in direct current circuit like Motor, auxiliary circuit and photovoltaic. Environment friendly, meets the ROHS compliance as defined by the European Standard. Shock Proof: Finger and Hand touch safe. Housing & Cover made from Flame Retardant Material ensures protection against heating and strong impact. Watt Loss value are much lower than the specific values of IS/IEC Consumes less power, thus cost effective and energy saving. A quick make & Break trip free mechanism. Positive Isolation. Suitable for Commercial, Industrial , Residential & New Energy. Install before invertor to protect Solar Panel in case of high surge current.

• Country of Origin: India
• Type: Miniature Circuit Breaker
• Material: Ceramic, Plastic, PP, PVC
• Color: Grey, White
• Feature: Best Quality, Durable, Easy To Fir, High Performance, Shock Proof, Stable Performance, Use Friendly
• Condition: New
• Power Source: Electric
• Warranty: 1year
• Current Type: both
• Puncture Voltage: as per mcb rating
•  Connection Type: as per mcb
• Brand Name: all
