Deep Drilling Machine Dealers

Clients can avail a broad assortment of Deep Hole Drilling Machine that is used extensively in automobile industries for drilling in auto parts. These Deep Hole Drilling Machines are manufactured using the finest grades of stainless steel alloys and iron components. These are designed for seamless performance in challenging conditions and are robust in construction. Also, these machines are well known for their dimensional accuracy and durability.

• Model: 1525
• Number of drill spindle: 1
• Drill capacity: 40 mm
• Table size: 400 x 2000 mm.
• Longitudinal travel (X-axis): 1500 mm.
• Centre height: 325 mm
• Total length of the machine: 4500 mm.
• Approx. total weight of the machine: 4500 Kg.

• Country of Origin: India
• Type: DEEP HOLE DRILLING MACHINE
• Brand Name: SWARAJ AUTOMATION
• Rated Power: 6-9kw
• Overheating Indication: Yes
• Machine Structure: Horizontal
• Warranty: 1
• Operating Mode: Semi Automatic
• Shape: Rectangular
• Phase: Three Phase
• Pressure: High Pressure
• Usage: Gun Drilling
• Drilling Capacity: 5-12
• Accuracy: 0.1/100mm

• Brand Name: N/a
• Machine Type: Automatic
• Power Consumption: N/a
• Capacity: N/a
• Model Name/Number: N/a
• Number Of Shaft: N/a
• Usage/Application: N/a
• Job Sizes: 400 - 1050 diameters, 300 mm height
• Hole sizes: 2.5 mm to 8 mm diameters X 80mm deep

Clients can avail a quality range of Twin Spindle Deep Hole Drilling Machine from us. These Twin Spindle Deep Hole Drilling Machines are belt driven, and have hardened and ground guide ways with turcite-B lining. Our range of Twin Spindle Deep Hole Drilling Machines is suitable for various drilling cycles. Fully automatic NC version of these Twin Spindle Deep Hole Drilling Machines with flexible wood packing cycle is also available.   Specifications Centre Height : 100mm to 250mm Max Drilling Length : 1000mm Drill Diameter : 8mm to 50mm Hardened & ground guide ways with turcite-B lining

• Application: water well
• Warranty: 12 Months
• Weight: 35tons
• product name: Compressor Borewell Drilling Rig
• Power(W): 1000
• Mast overall length: 8,800 mm
• Rotary Head travel: 7,050 mm
• Centralize opening: 14 inch (356 mm)
• Pull Back: 12,000 Kg-f
• Pull Down: 5,500 Kg-f

• Country of Origin: Made In India, India

BTA Deep Hole Drilling Cartridges

Deep Hole drilling in any plane and any length can be carried out INSITU.Deep Hole drilling in any plane and any length can be carried out INSITU.

• Application: Industrial
• Voltage: 220/240 Volt
• Hole Diameter: 25-50 mm
• Brand: Zonap
• Power Source: Electric
• Max Speed: 6000 RPM
• Phase: 3 Phase
• Number Of Shaft: 3

• Automatic Grade: Semi-Automatic
• Material: Stainless Steel
• Hole Diameter: 25-50 mm
• Number Of Shaft: 4

Multiple-spindle drilling machines are used for mass production. These machines are great time savers where many pieces of jobs having many holes are to be drilled. Multi-spindle head machines are used in mechanical industry in order to increase the productivity of machining systems. The multiple- spindle drilling machine is a production type of machine. It is used to drill several holes in a work piece simultaneously, in a single setting. This machine has many spindles driven by a single motor and all the spindles are fed in to the work piece simultaneously. These machines may be either horizontal or vertical type. The drill heads consists of several spindles mounted on angular contact ball bearings and driven by a set of gears. For spindles wherein the center distance are very close needle roller thrust bearings are used. The drive to the spindle is by AC spindle CNC motor or by AC induction motor. The speed of the spindles driven by induction motor is varied by using variable frequency drive. The drill head is interchangeable.

• Automatic Grade: Automatic
• Coolant Tank Capacity Max: 7500 ltr
• Tool Head Spindle Speed: 100 - 800 RPM
• Drilling Depth: 1500 - 10000 mm
• Solid Drilling Range: 30 - 125 mm
• Power Consumption: 50 kW
• Material: Cast Iron
• Model Name/Number: SBM125

• Type: Deep Hole Drilling Machines
• Certification: ISO 9001:2008
• Color: Grey
• Voltage: 110V, 220V
• Condition: New
• Rated Power: 3-5kw, 5-7kw
• Application: Hole Drilling
• Weight: 100-1000kg
• Automatic Grade: Automatic, Fully Automatic
• Warrenty: 1 Year

• Hole Diameter: 25-50 mm
• Automation Grade: Semi-Automatic
• Number Of Shaft: 4

CNC GUN DRILL MACHINE used for doing precise deep hole drilling.

• Model: XYBVN50
• Max Weight of Tube Sheet: 12000 kg
• Drilling Stroke: 500 mm
• Drilling Size: 19 - 50 mm
• Table Size: 2000X2000 mm
• Spindle Power Drilling: 22 kW
• Y Axis: 1500/2000 mm
• No of Spindles: 1 - 2

Innovative Idea for Deep Drilling Gun Drilling M/c. : ø 3mm to ø 20mm depth upto 300mm to 2000mm STS Drilling M/c. : ø 15mm to ø 75mm Direct Direct Drilling depth upto 3000mm Counter Boring ø 55mm to ø 150mm All models available as per customer requirement.

• Max Drilling Capacity: 4mm
• Head Stroke Length: 20mm
• Motor Power: 0.75KW/3000 RPM
• Max. Spindle Speed: 12,000 RPM
• Head Movement: LM Guide with Ball Screw
• Depth Control: By Lead Screw & Nut
• Ball Screw Drive: Servo Motor
• Feed: Infinitely Variable
• Swing Over Bed: 136mm
• Distance between Spindle center to Base: 100mm
• Machine Size (mm): 800L x 530W x 1300H

Column-type Planer-type Gantry-type Machines, Vertical Horizontal Spindle Machines,M Single Multi-Spindle, High Precision, Rigid Construction for Resulting in Good Surface Finish.

Accurate Machines Tools is also specialized in the field of SPECIAL PURPOSE MACHINES with expertise in Deep Hole Drilling Machines, Hydraulic Turning Machines, Cam Shaft Grinding requirement to achieve high production and accuracies.Our special purpose machines are supplied with user friendly Operating Control Panels for easy operations as well as programming. All the electrical and electronic components and devices are standard quality make.NOTE: All the mentioned specification and details are for the featured machines. We can design the machine as per your jobs and requirements.

Features Job rotating type machine for high concentricity of bore with respect to diameter & also less ovality of bore. Due to high speed & feed ratio - high material removal rate with minimum opration time. Both the sides chucks for job clamping so higher weight & length of job can be deep hole very easily. Seprate auto feed gear box & electric motor for feed drive system so you can deep hole the bore with maximum feed rate. A.C. variable drives for job rotation & feed drive system to produce high accuracy hole for variety of job metals.   Type of Machine Job rotating type machine to suit for Round job. Tool rotating type machine to suit for heavy and irregular shaped job. Job & tool rotating type machine for high accurate bore size with respect to diameter concentrically. STS type machine or Ejector drilling System type machine.  Specification (Capacity) 25mm solid drilling cap. to 250mm solid drilling. 125mm counter boring cap to 450mm Counter boring.

We are offering deep hole drilling machine, deep hole drilling machine.

• Country of Origin: Made in India
• Material: Mild Steel
• Number Of Shaft: 1
• Model Name/Number: DHD-1000/2000
• Usage/Application: Gun Driiling
• Automation Grade: Automatic
• Hole Diameter: 25-50 mm
• Power Consumption: 20 Kw
• Capacity: 5 mm To 35 mm

T2150/1-10m deep hole boring machine with funuc CNC system, with triangle rail (“V”),  width of rail:800mm with ring center rest the oil box is on the ground (can get 200L/min, 400L/min,600L/min,800L/min flow by rotate tune) drilling hole diameter range: 50-120mm boring hole diameter range: 50-500mm max depth of deep hole: 10m center height: 625mm ring center rest diameter range: 60-300mm roller center rest supporting range: 300-650mm main motor: N=30kw main shaft speed:  3.15～315r/min , grade 12 drilling box revolution speed: 60—1000r/min   grade12 drilling box motor: N=30kw drilling box main shaft front bore-hole 140 carrier feeding speed：5～1000mm/min （stepless） carrier moving speed：2m/min feeding motor: N=7.5kw carrier fast motor：N=5.5kW cooling pump motor: N=7.5kw X4 (set) cooling system pressure: 2.5Mpa cooling system flow capacity: 200、400、600、800L/min machine size: 29.5mX3800mmX1900mm machine weight : about 35ton max load weight: 10ton knife accessories: by user cutting oi and lubrication oil: by user processing precison: drilling : hole diameter precison:I T9-11, surface roughness: Ra6.3-Ra12.5 streight line degree of processing hole:
