Dust Collecting Valve Dealers

We are engaged in manufacturing and supplying excellent quality dust collector solenoid valve to our valuable clients. Offers high performance diaphragm operated pulse and pllot solenoid valves with threaded ports. Available with integral pilot or as remotely pilot valves, out let at 90?? to inlet . The pulse valves have just one moving part the diaphragm. Springless construction of diaphragm providing fast on-off operation. This high speed operation saves compressed air and provides king of shock wave necessary to free the dust from filter bags. Suitable for dust collector application, in particular for reverse pulse jet filter cleaning including bag filters, cartridge filters, envelope filters, ceramic filters and sintered metal filters size range: 12" to 4" screwed operations the pulse valve is either by an integral solenoid operator or a remote pilot solenoid valve. When the pllot solenold valve is energised, the air trapped above the diaphragm is quickly exhausted

• Size: 1.1/2inch, 1.1/4inch, 3/4inch
• Material: Stainless Steel
• Certification: ISI Certified
• Application: Gas Fitting, Oil Fitting, Water Fitting
• Automatic Grade: Automatic
• Number Of Way: 2way, 3way
• Pressure: High, Low, Medium

・Piping: Flange type, flange body type, direct piping type・Orifice machining on the outlet is not necessary, so piping man　hour is reduced. (Flange body type)・Enclosure: IP65＊＊Electrical entry flat terminal type terminal is IP40.・Applicable for high temperature: Fluid temperature 100℃・Flat terminal type added.・Controller dedicated for operation series VXFC

• Type: 2 Way
• Material: Aluminium Pressure Die Cast
• Working Pressure: 0.6 to 10 Bar
• Media: Air
• Design: Angle Type Pilot Operated
• Size: 25 MM To 40 MM
• Diaphragm: Nitrile / Polyurethane
• Voltage: 220V AC / 24V DC
• Temperature: Upto 80 Degree C Ambient
• Ends Connection: Screwed End BSP (F)

• Country of Origin: India
• Brand Name: Aira
• Material: SS, BRASS, METAL, ETC
• Media: Air
• Type: Pneumatic Valves
• Condition: New
• Corrosion Resistance: Yes

Pneumatic PULSE JET DUST COLLECTOR VALVE, all sizes available, all brands available, Janatics, Festo, UFLOW, Pneumax, JELPC, Techno....................................................................................................

• Size: 1 to 3 Inches
• Material: Alloy
• Coil Voltage: 24V
• Usage/Application: Air
• Fluid Temperature: Normal
• Country of Origin: Made in India
• Features: High durable, Reliable, Supreme strength
• Port Size: 1 BSP
• Orifice: 29 mm
• Diaphragm: Nitrile (NBR), (SINGLE DIAPHRAGM)
• Brand Name: Mevadhashma
• Model Name/Number: Many
• Packaging Type: Box
• Power: As required
• Pressure Range: 8 Bar
• Coil Material: Copper
• Supply Voltage: 24 - 240V AC/DC
• Packaging Details: As Required

• Material: Alluminium
• Coil Voltage: 230v
• Color: Silver
• Usage/Application: Dust collector valve
• Frequency: 50Hz
• Brand Name: Asco
• Model Name/Number: SCG353D050

• Material: Aluminium
• Size: 1,1-1/2 Inches
• Pressure: 0.5 - 8.5 BAR
• Color: BLACK
• Media: Air
• Country of Origin: Made in India
• Media Temp.: -10° C to 90° C
• Circumstance Temp.: -10° C to 70° C
• Main Features: Internal Parts are in superior corrosion resistance steel, Suitable for Air Pollution Control System
• Brand Name: Uflow
• Model Name/Number: JAN
• Diaphragm: NBR

• Diaphragm: Nitrile or Neoprene (Reinforced) P.U
• Temperature: Rated for 80°C max For high temperature up to 125°C Viton diaphragm with viton seat can be provided
• Size: 1 Inch - BSP
• Coil Voltage: 12,24,48,110,230V AC / DC
• Country of Origin: Made in India
• Brand Name: AIRA
• Model Name/Number: CSDA
• Design: Single Diaphragm
• Temperature: NBR : Upto 85 Degree Celsius (Viton : Upto 125 Degree Celsius On Request)
• Pressure Range: 0.6 to 8.5 KGS/CM2
• Body: ASTM A351 Gr. CF8 / CF8M / CF3M
• Diaphragm: NBR / Viton
• Coil Insulation: "F" Class & "H" Class for Flame Proof
• Coil Encloser: IP 67 (Flame Proof / Explosion Proof As Per IS / IEC 60079-1 STD for Gas Group II C Zone 1 & 2)
• Ends: Screwed - BSP ( NPT On Request )
• Packaging Details: Plastic Polythene Bag / Corrugated Box

• Media: Air
• Model Name/ Number: JAN67
• End Connection: Screwed
• Diaphragm: Nitrile (NBR)
• Circumstance Temperature: -10 to 70 degree C
• Media Temperature: -10 to 90 degree C
• Body Material: Aluminium
• Pipe (Inch): 1.5 inch
• Orifice (mm): 51 mm
• Min. Operating Pressure: 0.5 kg/cm sq.
• Max. Operating Pressure: 8.5 kg/cm sq.
• Seal & Diaphragm Material: NBR
• Flow Factor: 40 Kv m cube/hr
• Main Features: Internal Parts are in superior corrosion resistance steel, (Equivalent to SS316L) Suitable for Air Pollution Control System, Bag Filter Machine.
• Coil Features: High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as require.
• Coil Housing: Epoxy square coil, metallic round enclosure, IP-67 Flameproof enclosure, IP-68 Weatherproof enclosure.
• Optional Feature: 90% Power saver series also available.

• Diaphragm: Nitrile/Neoprene/PU
• Pressure: 0.6 to 10 BAR
• Temperature: Up to 80°C(125° On Request)
• Body: Aluminum Die Cast,Stainless Steel
• Size: 1/2" to 2"

FFV Pulse Valve have to been designed for quick open and close which results in effective Cleaning & air consumption.While the pulse valve is closed the compressed air is trapped between diaphragm and solenoid valve orifice.When solenoid valve is energized, the air trapped above the diaphragm is quickly exhausted through the pilot solenoid valve, causing fast opening of the main pulse valve.When the pilot solenoid valve is de-energized the inflowing compressed air lifts up the diaphragm and flows through the outlet of the pulse valve & the air gets trapped, closing the diaphragm as a result of pressure equalization.     Application Pulse Valve It is used majorly in dust collector system,pulse jet filters,bag filters on lime,Coal Injection System for blast furnace which all are used in industries like feed, fabric industries, food processing powder,cement,coke ash lime,chemical,coke oven,Coal Preparation Plants & related systems,flue gas system,furnace etc.   Features The main pulse valves have just one moving part the diaphragm Due to high speed operation dust from filter bags is free It also allow high flow rates The volume of air is controllable by adjusting the pressure of the compressed air Long operational life Valves are mountable in any position Simple commissioning Less power consumption / Lower air consumption Spring Less Design

• Media Temp: -10 °C to 90 °C.

Main Features : Internal Parts in Superior corrosion resistance steel (Equivalent to SS316L) Suitable for Air Pollution Control System, Bag Filter Machine. Features : High Reliability Unaffected by Voltage Surges. Easy Coil changes Coil lockable in 4X90 position or freely movable in between as require. Coil Housing : Epoxy Square Coil, Metallic Round Enclosure, IP-67 Flame Proof Enclosure, IP-68 Weather Proof Enclosure.

• Size: 40 mm
• Material: Aluminium
• Country of Origin: Made in India
• Brand Name: Torque
• Model Name/Number: 2W ADPV 40
• Packaging Type: Box
• Pressure Range: 0.6- 8.5 Bar
• Voltage: 230V AC
• Temperature: 125 Deg C

• Frequency: 50 Hz
• Voltage: 230 V AC, 24 V DC
• Fluctuation: +-10 %
• Temperature: 55 to 85 Deg C
• Payment Terms: L/C (Letter of Credit)/T/T (Bank Transfer)/D/P

• Material: Aluminium
• Size: 1,1 1/2 Inches
• Country of Origin: Made in India
• Brand Name: Uflow
• Diaphragm Colour: Black

• Material: ALUMINUM
• Pressure: 0-10 KG/CM2
• Brand Name: U Flow
• Application: Pharmaceutical Industries
