ECG Recorder Dealers

• Weight: 2.75 kg
• Lead Selection: Manual, Automatic
• Time Constant(sec): : >3.2
• CMRR(dB): >60, >80, >100, >103

Function:  Compact in size, easy and direct operation, portable. Accurate pace pulse identification and automatic analysis function. Four working modes: Manual / Auto / Physical Examination / Storage. 12 leads simultaneous waveforms display. 800 x 480 graphic 7-inch color screen with Alphabet keyboard for input (only for 12-CK). 800 x 480 graphic 10-inch color touchscreen (only for 12-CT). 215mm, 12 channel format recording. Built-in USB, RS232 interface, ECG NET software optional. Adapt to 110-230V, 50/60Hz AC power supply. Advanced [Freeze] function. Built-in rechargeable Li-ion battery. 250 patients information storage (Extendable). USB interface allows net transmission, USB flash disk and USB printer connected. High accuracy thermal printing, adapt to 215mm roll paper and 210x140mm Z-fold paper.

• Brand Name: A.D'S
• Lead: Standard 12 leads
• load acquisition: 12bit/1000Hz (synchronously 12 leads)
• Work mode: Manual / Auto / Physical Examination / Storage
• Filter: • AC Filter: 50Hz / 60Hz, • EMG Filter :25Hz/45Hz, • Anti-Drift Filter: 0.15Hz (Adaptive)
• CMMR: ≥100dB (with AC Filter)
• Input circuit: Floating; Protection circuit against
• Input impedance: 50MΩ
• Input circuit current: Input circuit current
• Patient current leakage: 10µA
• Calibrating voltage: 1mV±2%
• Voltage tolerance: ≥±500mV
• Time constant: ≥3.2s
• Frequency response: 0.05
• Noise level: <15µVp-p
• Inter-channel interference: ≤0.5mm
• Sensitivity: Auto, 2.5, 5, 10, 20. 40mm/mV
• Recording mode: • 3ch, 3ch+, • Default Man. Mode is 3ch format, • Default Auto.Mode is 3ch+ format
• Paper speed: 6.25, 12.5, 25, 50mm/s (±3%)
• Paper: 80mm x 20m Roll Paper
• Communication: RS232/ USB port
• Power supply: AC 110-230V (±10%), 50/60HZ (±1Hz), 60VA, DC Built-in rechargeable battery. i4.4V(2000mmAh)
• Dimension / Weight: 300mm x 230mm x 75mm / 2.8Kg

We are offering multi channel ecg machine. The cardiocare 2000 is an economically priced 12 channel resting ecg that does not compromise on performance. Suitable for use in private practice, the er, or hospitals use, the cardiocare 2000 is designed for maximum ease of use and convenience. Software upgradeable and networkable, the cardiocare 2000 is an excellent choice for your diagnostic needs

We provide customized packaging solutions, as we understand each customer is unique. The packaging we provide is strong, non-toxic, and capable of braving shipping and handling. We ensure on time distribution of wholesale as well as retail consignments owing to an extensive vendor, distributor and logistic facility base.

• Color: White
• Size: Handy

We are offering ecg holter recorder. ecg holter recorder feature:- 1. Compatible with many kinds of holter 2. Resolving power: 8 bit 3. Through led direct to begin and write down information. 4. Escape circuit of libration 5. Dimensions: 128mmx68mmx24mm 6. Use aa of alkalescent batteries 7. Safeguard circuit to be fit 8. Event button 9. 7 leads color electrical wire.

Dyausmed Track Smart Digital Holter the size of a pager, weighs just 63 grams and is easy for patients to wear while doing their day to day activities. This tiny, lightweight Holter stores so much information as if reading ECG from Cardiographs. The Holter recorder has three channels of ECG recording . Pacemaker detection is also supported. With Dyausmed Track Smart Holter Recorder system you get the high-quality ECG information you need—without any data mpression. The LCD lets you check the quality of the electrode connections as you place them. There's no need to roll in an ECG cart, which makes hook-up quick and easy for you and your patients. The monitor's lowweight and small siz ensure comfort and privacy. Water-resistance ensures that accidental fluid immersion won't stop the monitor from performing, which protects your investment for the long term.

36 channel printing 5 patient memory ECG display A4 size printing Measurements Memory stick download Computer connectivity*

We are leading supplier of huge range of ECG Recorder.

• Type: Ecg Recorder
• Application: Hospital, Veterinary Purpose, Clinical
• Color: Creamy, Off-white
• Condition: New
• Driven Type: Electric
• Feature: Easy To Operate, High-quality, Light-weight, Good Quality

Dyausmed’s CS10 Provides wireless transfer of ECG to your Tablet, PC and Helps in quick Analysis and review where ever you are in the Hospital. Bed to Bed ECG Dyausmed’s CS10 offers a unique solution for Bed to Bed Diagnostic ECG. It’s handy design let’s you take ECG at the Bedside without trouble of Carrying the CART with ECG machine through out the Hospital. Wireless facility helps in immediate transfer of Patient data from CS10 to Tablets and PC’s for quick and fast Analysis. CS10 Offers “Quick Mode” for fast and quick ECGin just two simple steps.

• Warranty: 1 Yrs
• Weight: 4.2kg (9.3 lbs) (Excluding recorder paper and battery)
• Brand: BPL
• Model Name/Number: Cardiart 9108 D
• Usage/Application: ECG Recording
• Power Voltage: 220 V
• Pack Type: Box
• Display Touch Screen: 12.1 Inches, 800x480 TFT LCD Screen
• Recorder: Thermal Dot Matrix Recorder
• Printing Density: 8 dots per mm / 200 dots per inch (amplitude axes) 40 dots per mm / 1000 dots per inch (time axes @
• Recorder Paper: 210 mm x 140 mm x 144 pages 210 mm x 295 mm x 100 pages (optional) 215 mm x 280 mm x 100 pages (opti
• Effective Width: 210mm
• Paper Speed: 5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s (+-3%)
• HR Range: Upto 300 BPM
• Accuracy: 3 BPM
• Acquisition Mode: Simultaneously 12 Leads
• A/D: 24 Bits
• Frequency Response: Upto 300 Hz
• Gain: 1.25, 2.5, 5, 10, 20, 10/5, AGC (mm/mV)
• Input Impedance: 100MQ (10Hz)
• Filter: AC Filter: 50Hz/60Hz/Off DFT Filter: 0.01Hz/0.05Hz/ 0.15Hz/ 0.25Hz/ 0.32Hz/ 0.5Hz/0.67Hz EMG Filter:
• Sampling Frequency: 16,000 Hz
• Pacemaker Detection: Available
• Anti Electric Shock Type: Class I with internal power supply
• Working Mode: Continuous Operation
• Temperature: Upto 55 Deg C
• Relative Humidity: 25%-93% Non-Condensing
• Atmospheric Pressure: 70 kPa

• Type: Ecg Recorder
• Certification: ISO 9001:2008 Certified
• Application: Hospital, Veterinary Purpose, Clinical, Home Purpose
• Weight: 0-4 Kg, 4-8 Kg
• Color: Creamy, Off-white, White
• Screen Size: 5 Inches, 5.5 Inches, 5.7 Icnhes, 6 Inches
• Frequency: 0.05-150 MHz
• Driven Type: Electric
• Feature: Easy To Operate, High-quality, Light-weight, Sturdy Design
• Warranty: 1 Yr, 2 Yrs, 3 Yrs

Sophisticated longterm ECG recorder The new medilog® FD12plus is the most sophisticated long-term ECG recorder of the medilog® plus series and is designed for 3 or 12-channel   ECG recordings. When the AF/AFL configuration is selected, 3 ECG channels can be recorded for 7 days without having to change the battery! FEATURES PureECG technology HRV analysis Fire of Life detection Apnoea detection ST-/QT-/pacemaker analysis Realtime QRS detection Realtime P-wave detection and atrial analysis Motion analysis Wireless BluetoothTM interface 7 days recording time (3-channel mode)

• Sharp and Clear Trace: Electronic Lead Selection
• Protected against High Defibrillation Voltage: Real Time High Fidelity Thermal Array Recording

We are offering most trusted indian Single Channel Ecg Recorder for decades. highest in market share.

• Lead: Standard 12 leads
• Load Acquisition: 12bit/1000Hz (synchronously 12 leads)
• Work mode: Manual / Auto / Physical Examination / Storage
• Filter: AC Filter: 50Hz / 60Hz EMG Filter :25Hz/45Hz Anti-Drift Filter: 0.15Hz (Adaptive)
• CMMR: ?100dB (with AC Filter)
• Input circuit: Floating; Protection circuit against Defibrillator effect
• Input impedance: ≥50MΩ
• Input circuit current: ≥0.05µA
• Patient current leakage: ≤10µA
• Calibrating voltage: 1mV±2%
• Voltage tolerance: ≥500mV
• Time constant: ≥3.2s
• Frequency response: 0.05
• Noise level: <15µVp-p
• Inter-channel interference: ≥0.5mm
• Sensitivity: Auto, 2.5, 5, 10, 20. 40mm/mV
• Recording mode: 3ch, 3ch+ Default Man. Mode is 3ch format Default Auto.Mode is 3ch+ format
• Paper speed: 6.25, 12.5, 25, 50mm/s (±3%)
• Paper: 80mm x 20m Roll Paper
• Communication: RS232/ USB port
• Power supply: AC 110-230V (±10%), 50/60HZ (±1Hz), 60VA DC Built-in rechargeable battery. i4.4V(2000mmAh)
• Dimension / WeightWeight: 300mm x 230mm x 75mm / 2.8Kg

• Country of Origin: Made in India
• Frequency: 50 Hz
• Brand: BPL
• Model Name/Number: Cardiart 6280 View
• Usage/Application: ICU
• Power Voltage: 240 V
• Phase: Single Phase

The 3 Channel Interpretive ECG Recorder is supplied by us in the market that is available under the brand name Aspen. The 3 Channel Interpretive ECG Recorder offered by us widely appreciated and recommended by various health experts for Automatic measurement and interpretation of ECG waveform. The clients can avail this ECG Recorder at very comprehensive price. Features Digital 3 Channel Interpretive ECG RecorderThree channel digital ECG recorder with 3.5 TFT ScreenDigital signal processor for effective inhibition of baseline drift, interference, as well automatic position of base lineAutomatic measurement and interpretation of ECG waveformPower supply both AC & DC (built- in rechargeable lithium battery)Can store 1000 patients dataThermal array (8dotsmm) recorderMeasurement parameters: HR, P-R interval, P-Duration, QRS Duration, Q-T interval, Q-Tc, P Axis, T duration, QRS Axis, TAxis, R (V5), S (V1), R (V5) +S(V1)Safety level corresponds to Class I, Type CF

• Brand: Trivitron
• Model Name/Number: iBeat 3V Pro
• Machine Type: Digital
• Battery Type: Built-in Rechargeable Lithium Battery
• Display Size: 7 Inches
• Display Type: TFT Color LCD
• Resolution: 800 x 480
• Keyboard Type: Alpha-numeric
• Features: 12 channel ECG recording and have simultaneous acquisition of all Leeds and display. Built in thermal Matrix printer. Any Lead can be selected as Rhythm Lead. Network transmission (optional).
