Electrical Insulating Paper Dealers

• Type: Electrical Insulating Paper
• Thickness: 4MM
• Color: Multicolor
• Application: Wall/Roof Insulation
• Quality: Good
• Width: 1m, 1.2m
• Features: Sound Proof, Durable, Easy to Use

Flexicom f nrnn/npn is a 3 ply composite flexible insulating paper made of Calendered Polyamide Nomex Paper on both sides .of polyester film using thermosetting adhesive as the bonding material. Features
Good Flexibility
Higher dielectric strength
Higher thermal stability
Free of Voids, air pockets
Compatible with all insulating impregnating varnish

• Brand Name: VinCork
• Color: Brown
• Application: It is used as a top-cover gasket for electrical transformers to prevent oil seepage
• Type: Electrical Insulating Paper
• Thickness: As per customer requirement
• Country of Origin: India

• Features: Recyclable, Tear resistance, Fine finish.
• Item Code: IP-01

• Color: Cream
• Material: Paper
• Thickness: 0.18 mm (7.2 Mil )
• Usage/Application: Used For Oil Immersed Transformer.
• Brand: DuPont Nomex
• Class: 410
• Basis Weight, g/m2: 174 g/m2
• Density, g/cc: 0.95
• Tensile Strength, N/cm MD XD: 227
• Elongation, % MD: 20% MD
• Elmendorf Tear, N MD: 3.7N MD
• Initial Tear Strength, N MD: 48 N MD
• Shrinkage at 300 DegreeC, % MD: 0.5% MD
• Minimum Order Quantity: 10 Kg

• Packaging Type: Cardboard Box
• Size: 0.13 mm - 0.52 mm
• Color: White
• Material: Nomex Paper

• Color: White
• Thickness: 0.25-2 mm
• Material: Aramid
• Size: 1000 mm
• Class: Class H

• Material: Paper
• Thickness: 51 Microns
• Color: Brown
• Packaging Type: Roll
• Pattern: Plain
• Roll Length: 100 - 300 m

We are offering Electrical Grade Insulation Kraft Paper for use as Insulation in Power / Distribution Transformers, Covering of Copper / Aluminum Conductors, etc. The paper is manufactured as per IEC grades and pass all tests. The thickness above 5 mil can also be provided to meet the varied requirements of our clients.   Available in the thicknesses of:  1.5 mil (40 microns) 2.0 mil (50 microns) 2.5 mil (65 microns) 3.0 mil (75 microns) 4 mil (100 microns) 5.0 mil (125 microns)   Specifications: Color - Brown Application - Transformer application Minimum Order Quantity - 100 Kgs

• Material: Paper
• Material: Paper
• Packaging Type: Standard
• Temperature (deg. Celsius): 130 deg C
• Size: 25-500 mm
• Form: Paper Rolls
• Usage: Transformer Insulation
• Packaging Type: Standard
• Temperature (deg. Celsius): 130 deg C
• Size: 25-500 mm
• Form: Paper Rolls
• Usage/Application: Transformer Insulation

• Material: Paper
• Packaging Type: Standard
• Temperature (deg. Celsius): 130 deg C
• Size: 25-500 mm
• Form: Paper Rolls
• Usage/Application: Transformer Insulation

• Color: Brown
• Brand Name: Lee Vedla
• Usage/Application: Transformer Winding
• Size: Roll Width 500, 750 & 1000 (mm)
• Packaging Type: Carton Box
• Pack Size: 100 Pieces

Electrical Grade Insulating Kraft Paper manufactured by M/s: Aura Paper Industries. We offer this material in 2 mil, 2.5mil, 3 mil, 5 mil and 10 mil.And Crape Paper, Semi Conducting Crape Paper.

• Item Code: NOMEX410
• Packaging Type: Roll
• Temperature: 180 Deg C
• Size: Available in tickness of 2mills,3mills,5mills,7mills,10mills,20mills and 32mills914mm width
• Usage/Application: Motors and Transformer Insulations

• Application: Electrical Insulation
• Color: Brown/Black/Green
• Thickness: 0.10mm upto 0.55mm
• Packaging Type: Roll
• Size: 1000mm

Direct Importer Of "TOMOEGAWA MAKE" Japanese Origin Electrical Grade Insulation kraft Paper Used For Interlaying Of Transformers and Copper & Aluminium Conductors wrapping / covering. Ranges From 40 Micron (1.5 mil) To 125 micron (5mil). *   Transformer Industries interlayer insulation*  Wrapper of Copper & Aluminium Conductors.   INSULATING KRAFT PAPERElectrical Grade Insulating Kraft Paper available in jumbo orslit rolls from 1.5 to 6 mils thicknessSlit Widths : Insulating Kraft Paper in slit width (ready to use)   Special Characteristics:   . Low ion contaminants through the use of de-ionized water. Superior resin and oil impregnation characteristics. High tensile strength in the vertical direction. Capable of being produced in thin sheets (23g/m2 - 35 microns). Paper combinations - 3 layer construction possible. Low density, high air permeability. Little difference between front and back. Heat resistant insulating paper. Coloured insulating paper. Colored with dyes that have no electrical influences. Semi-synthetic insulating paper & others . Also used for instrumentation and condenser applications. Basis Weight 23 - 330g/m2

We are the major suppliers to some of India's leading Electrical Equipment companies like ABB, Alstom, Bharat Bijlee, CG Global, Emerson Trident, Leroy Somers, Cummins Generator Technologies, Siemens etc. As a result of our relentless pursuit of quality, we have obtained Product Certification from Underwriters Laboratories, USA. In the current manufacturing scenario where manufacturers are competing to produce world class products at competitive rates, manufacturers are looking to simplify production lines by outsourcing components and processes. Our company has a Kit making facility which offers insulation material in ready to use form as per the requirement of the customer. Through processes such as close tolerance slitting, cuffing, die cutting, heat forming, punching, etc., the electrical insulation material is converted to insulation components like Wedges, Slot Cover, Phase Separators, and Slot Liner as per the specification of the customer. These components are packed in individual bags referred to as "Insulation Kits".

• Material: Paper
• Color: Brown
• Thickness: 5mm
• Country of Origin: Made in India
• Brand Name: Vijay Trading
• Packaging Type: Roll
• Pattern: Plain

• Packaging Type: Roll
• Basis Weight: 23 - 30 G per M Square
• Dielectric Strength: Less than 10 KV per mm
• Width: 24 - 30 inch width per roll

We are offering electrical grade insulating kraft paper made entirely from high purity imported virgin fibres. used widely as electrical insulation wrap on aluminium and copper wires by conductor manufacturers, electrical insulation between layers of wound coils in electrical motors, in capacitors, transformers & such other electrical equipment available in natural brown finish

Stockist Of "ITC" Brand "UBIL" Electrical Insulation Craft Paper Suitable For Aluminium & Copper Conductors Wrappings Sizes Rauges Form 1.5 mill to 5mill

• Material: PVC
• Thickness: 0.5 to 1 mm
• Country of Origin: Made in India
• Flexural Strength: 120 Mpa
• Packaging Type: Roll
• Density: 1.3-1.4 g/cm3

• Material: Paper
• Packaging Type: Roll
• Pattern: Plain
• Temperature: 30 Degree C
• Voltage: 10 Kv

• Thickness: 0.05 mm-0.50 mm
• Color: Brown
• Features: High purity, Heat resistance , Resistance to ageing.
• Packaging Type: Roll
• Size: As per requirement
• Usage/Application: Transformer Insulation
•  :

We offer electric insulation grade crepe paper. This specially designed crepe paper is used as insulation in the manufacturing of oil-immersed transformers and current transformers of types imb, ct, cvt, etc for making leads and shields. The power transformer, an important piece of power transmission equipment, is the core component of the power system. Its main component is insulation. It plays triple role of dielectric barrier, mechanical support, heat escape route. The reliability of a power transformer is largely determined by its insulation condition. Electric insulation grade crepe paper can be advantageously used as insulation media for oil transformers by achieving marginal economy. Its quality directly influences the life span of the transformer.

• Features: High quality,Easy to use,High performance

We offer electrical insulating paper, thin ,press cardboard, transformer paper , ddp, laminated compressed wood.

Electrical Insulating Crepe Paper, Insulating Kraft Paper

Electric Insulation Paper, Plane Aluminium Foil for Capacitors
