Electroless Nickel Plating

Similar to stainless steel in color, Plates uniformly in recesses and cavities (does not build up on edges). Corrosion resistance is good for coatings over .001 thicknesses. Electro less Nickel is used extensively in salvage of miss-machined parts. Also for inside dimensions and irregular shapes (where assembly tolerances need uniformity provided by Electro less process).

The process of adding an electroless nickel plating to a metal surface is an autocatalytic chemical reduction. This means that instead of using an outside source of electricity like in the similar electroplating process, the electroless nickel plating process uses a chemical bath to deposit a nickel / phosphorous layer onto the metallic surface.

Being a non-conventional plating system, the Electroless Nickel Plating, which we render, doesn�t use current for deposition purposes. The Electroless Nickel Plating Service, we render, helps in getting intricate parts with deep recesses and holes, or uniformed layer thickness; resultantly minimizing excess build-up, if any, on the edges or corners, eliminating the post-plating grinding operation. The Electroless Nickel Plating Service produces an amorphous layer, having exceptional resistance against corrosion and uniform thickness of the deposited electro-nickel material. This Electroless Nickel Plating Process is best suited for taper cavities, spiders, breakers plates, plastic dies and other varied extrusion die parts. Why Our Electroless Nickel Plating? Ideal for complex shapes where uniform and controllable plating thickness is not possible by conventional electroplating processThis Electroless Nickel Plated Layer offers a surface hardness of 48 to 62 HRC with excellent bonding and the plated layer does not flake-off.Helps the barrels for injection molding machines by giving them non-stick propertyEasy cleaningHelps in re- building worn-out punches to original dimensionsThis coating is also used for costly instruments and oil field as well. Electroless Nickel Plating Properties Superior corrosion protectionUniform and controllable layer thicknessNon-stick property for plastic molds and extrusion diesWear resistanceSolderabilityLubricityDuctility

This new technology coating method which replaces Hard chrome in many areas where critical profile have to be plated, Uniformity of the deposits, even on complex shapes, thickness variation of 0.1 micron, Deposits are often less porous and thus provide better barrier corrosion to steel substrates, much superior to that of electroplate nickel, Surface Hardness: Ranging from HV 600 - HV 950.

Offered is executed under the strict guidance of our diligent personnel in an effective manner to achieve the more clients’ satisfactions. Offered service is widely demanded for corrosion protection, chemical resistivity and lubricity on valves, pistons, engine shafts, engine mounts, compressor blades and other flight-critical components.

Nickel plating is an electrodeposit process that offers moderate corrosion and oxidization resistance. Nickel is sometimes used to build up worn or undersized parts. Nickel is highly recommended for increased ductility and corrosion protection . Bright finishes are obtained by using proprietary brightening agents. We offer Bright nickel and chrome plating. Please contact us for a quote on your industrial chrome plating needs.

Anand Industries provide electroless nickel plating that is a non-conventional plating system where no current is used for deposition that helps in uniform layer thickness plating on intricate parts with hole and deep recesses.

“ PEPCOAT ” is the trade name of our quality phosphorus- Nickel metal alloy coating. We undertake coating of customer parts ranging from small fasteners to large rollers and Chemical Equipment.A New and unique Engineering Plating Chetana is a Job shop where we do Electroless Nickel plating on customer parts equipment, We are the pioneers in this field and besides being the most experienced, have one of the largest plating facilities in India. Our plating – called “ PEPCOAT ” and technically known as Electroless Nickel – is an unusual plating because it does not have the handicaps of conventional Electroplating, and offers the following :

Electroless nickel plating is a chemical process done without applying current by using auto catalytic chemical reduction process in higher temperature and it can be plated over a wide variety of metals like Aluminum, Mild steel, Hardened steel, Stainless steel, Copper and Brass. The main feature of electroless nickel plating is that being a chemical diping process, the deposition is absolutely uniform, and the dimension of components can be maintained within a close tolerance of 1 to 2 micron hence no need to carryout machining or grinding operations. Plating can be successfully acheived highly recessed areas such as deep bores, grooves and blind cavities, unlike in any conventional electrochemical process such as hard chrome plating.

Electroless nickel plating improves corrosion resistance, increases the surface hardness of the material, provides a uniform and dense coating, and, in many cases, maintains the same surface finish the material had before plating.

Electroless Nickel Plating can be applied on most metals like Plain Carbon, High Alloy Steels, Aluminum, Copper & Copper Alloys etc. This process is carried out by auto catalytic process without applying electric current. The deposit has a high corrosion resistance against most of the chemicals. It has also got very good wear resistance and low coefficient of friction. In response to increasing demand for environmentally purer products - "ELECTROCHEM's Process" is free of lead and cadmium additives.   Uniform Deposit : This being a chemical deposition process, it gives uniform Plating thickness all over even if shape of the article is intricate.   Hard Deposit : The hardness of the Electroless Nickel Deposit is 45 - 50 RC after plating. It can be increased to 65 RC by low temperature baking.

Similar to stainless steel in color, Plates uniformly in recesses and cavities (does not build up on edges). Corrosion resistance is good for coatings over .001 thicknesses. Electro less Nickel is used extensively in salvage of miss-machined parts. Also for inside dimensions and irregular shapes (where assembly tolerances need uniformity provided by Electro less process).

• Type: Low-Phosphorus Electroless Nickel
• Location: Bhopal
• Brand: H h india
• Grade Standard: Technical Grade
• Packaging Size: 1 liter
• Usage/Application: Industrial

Electroless Nickel Plating ensures enhancement in durability and corrosion resistance of motors, rotors, drive shafts, door knobs etc. Our team of well trained professionals is known for accomplishing the tasks within committed time frame in hassle free manner.

Electroless nickel plating is a process for depositing a nickel alloy from aqueous solutions onto a substrate without the use of electric current.

Electroless Nickel Plating Services Faraday Electrotech’s primary aim is to give customers a competitive benefit and be recognized as the finishing specialist of choice. We have friendly and affordable Electroless Nickel Plating Services for customers. We develop a symbiotic and synergistic relationship with every employee and customer. With years of experience, our experts are devoted to giving the highest standards in the industry. No matter, it is electroless nickel plating or aluminum anodizing; you can focus on us to give you the best quality product at competitive prices. Grab the friendly and accommodating Electroless Nickel Plating Services without going for anything. Contact our team for more information.

Coatpro Private Limited is the premier Electroless Nickel Plating Services throughout Mohali, Punjab (India). We pride ourselves as one of the best customer and market-focused leaders qualified for customer services, product quality, and environmental management. Electroless nickel plating can be used for different kinds of substrates – the coating possesses 4 to 7 percent phosphorus, which merges high hardness and wears resistance both as heat-treated and plated. Products having a special electroless nickel finish also have a positive corrosion guard. We keep our rates as affordable as possible. If you are interested in Electroless Nickel Plating Services, you can contact us now for more information.

Electroless Nickel Plating, Hard Chrome Plating, Silver Plating
