Elevator Automatic Rescue Device Dealers

• Type: Automatic
• Material: Aluminium
• Shape: Rectangular
• Number of Stops: 10-15
• Input Voltage: 280 V
• IP Rating: 66
• Phase: Three Phase

Key Features : For VFD based control panels Motor Capacity: 5HP/3.7KW to 50HP/37KW (Geared/Gearless) Battery DC Voltage: 48VDC Input AC Voltage: 440V AC Output Inverter Voltage: 400V Two Phase 50Hz Pure Sine wave in ARD mode and 400V Three Phase in Normal mode Require Minimum wiring Incase of phase reversal, ARD will work in MAINS mode only. ARD will work only in case of one or more phase failure. Optional protection for phase in neutral condition. Single card system, easy to maintain. MCB protection for switching off ARD for longer time and protection while installation. Easy for troubleshooting. Separate Indication for R,Y and B. Each phase can be set individually for MAINS mode.

• Brand Name: elevista,elevista
• Material: Steel
• Frame Material: Metal
• Shape: Rectangular
• Color: Black, Grey
• Automatic Grade: Automatic
• Application: Home, Hotel, Office, Restaurant, elevators
• Type: Elevator Automatic Rescue Device,5 HP to 100 Hp
• Country of Origin: India,India
• Logo: elevista

Based in Gujarat (India), we are a trustworthy Manufacturer, Exporter and Supplier of Elevator Automatic Rescue Device. Our Elevator Automatic Rescue Devices are fabricated in compliance with the international quality standards under the supervision of our experts. Corrosion resistant, durable and sturdy, our Elevator Automatic Rescue Devices are extensively demanded. In order to meet the urgent and bulk orders of buyers, we maintain a huge stock of Elevator Automatic Rescue Devices in our spacious warehouse.   Top Safety  Top Quality  Top Customer Satisfaction.

• Brand Name: marck
• Material: ms
• Shape: Square
• Automatic Grade: Automatic
• Application: Elevator
• Type: Elevator Automatic Rescue Device
• Country of Origin: India

Elevator Automatic Rescue Device

we are one of the most sought after company having earned the status of brand in the manufacture and supply of automatic rescue devise system. We provide different varieties of rescue devise in the market. The devise is made up of excellent quality material and is very long lasting and efficient. We are offering this elevator to our clients at a very reasonable range of prices.   features: suitable for auto door /manual door lift. starting current of 300% of rated  current  for high starting torque requirement. automatic shut down to prevent unnecessary battery usage. modified pwm technique forpure sine wave output with power efficient low on resistance mosfet based design. wide input voltage range 380vac-475vac. automatic battery charging cut off. protection against deep discharge of battery. status indications on lcd / leds. available up to 30 h.p. And as per requirements.

• Color: Metal White
• Usage: Elevator
• Name: Elevator Integrated Controller

As 380

• Color: off white powder coated
• Brand Name: Raystar
• weight: Approx. 15 kgs

Automatic Rescue Device is compatible to all lifts fitted with Induction Motor. Power supply from control panel to motor passes through Automatic Rescue Device. Same safety circuits works both for lift panel as well as ARD. Whenever power fails in between two floors, the car stops. Then ARD starts its operation in the following sequence: 1. It checks whether lift car is at floor level or not. Floor Level switch is closed when the car is not at floor level. 2. Emergency Light in the car puts on 3. It checks the safety circuit. If car door is closed, it starts moving in one direction and check the load. If load is more and can not rotate the motor, it stops and change the direction of the motor. 4. When it reaches the floor level it stops the car. 5. Start power supply 220 volts AC to the door drive along with the door open signal. 6. After about one minute it switch off the emergency light and put the machine in normal mode. When the power resumes, Batteries get charge with a regulated power supply.

• Efficiency: >90%
• Adaptable Machine Power: 15 kW
• Max. Adaptable Elevator Load: 1600 kg
• Rescue Rated Output Capacity: 1.3 kVA
• Output Current: 18 A
• Single Running Duration: 5 min
• Output Wave: Sine Wave
• Protection Class: IP20
• Cooling Mode: Free Cooling / Forced Air Cooling
• Voltage: 240 V
• Frequency: 50 Hz
• Phase: Three Phase

• Input Voltage: Three Phase 440VAC, 50Hz Pure Sine Wave Main Line Voltage.
• Output Voltage: Two Phase 440VAC, 50Hz Modified Square wave with power Booster Logic.

In case of a main power supply failure, the lift stopped between two floors is moved to floor level, the automatic door is opened and passengers are out safely, For lifts with automatic door, in case of a main power supply failure at floor level, the door is remain opened.This device is suitable for those buildings without an emergency power source allocated for the elevator.

• Charging current: 2Amps
• Bypass: Electro mechanical Switch

User friendly front panel Led Indications to monitor system status and rault indication Rocker switch to put OFF Inverter in-case of battery low condition Safest evacuation device as it has no interface with the safety circuit of elevator. No interface with any operating component of elevator motor, brake, door Operator, Rcam, etc. Highly reliable as the entire rescue operation is achieved by just producing 400V, 1 Phase power. Ride quality in rescue mode is same as elevator ride (as the VF Drive runs the Motor during rescue operation).

Computerized microprocessor based controller with fully collective-selective system in dust proof M.S. cabinet Variable voltage frequency inverter (V3F) drive. With the help of ARD when the power goes the device would bring the elevator car to the nearest floor and will stay on that floor with door open till the power supply is resumed.

• Material: Mild Steel
• Power Supply: 415 V
• Frequency: 60 Hz
• Phase: Three Phase

• Features: In sores safety , Quick rescue operation , No human intervention .

In case of a main power supply failure, the Lift stopped between two floors is moved to floor level, the automatic door is opened and passenger are out safely, For lifts with automatic door, in case of a main power supply failure at floor leval, the door is remain opened.

• Material: Metal
• Brand: UTL
• Usage/Application: Household
• Model Name/Number: ARDB485H
• Audible Noise: Yes
• Dimension: 425 X 245 X 315 mm
• Operating Temperature Range: 50 Degree C
• Nominal Voltage: 230V
• Operating DC Voltage: 48V
• Input Supply Phase: 1 Phase
• Switches: On\\Off
• Max. Relative Humidity: 95 %
• System Rating: 5HP
•  :

The increase in demand of sophistication in the elevator field is taking us to design the new dimension of Auto Rescue Devices for Elevators. Power failure is very often in our country and makes the passenger inside the lift to get panic, if unnoticed for long. Auto Rescue Devices are taken care of the elevator operation during power fail and moves the elevator to the near by floor. Most of the builders especially like Apartments and Hospital are insisting for Rescue unit even for new as well as old lifts. This document gives an overview and technical details of MABARA-Auto Rescue Device here after called as MARD.

The AUTOMATIC RESCUE DEVICE is the safest automatic elevator evacuation device designed for VF Elevators. The Automatic Rescue  relates to a new concept and design and operates the elevator controller at rated voltage to perform the evacuation operation.   Principle of Operation The  Automatic Rescue works on the principle of powering and operating the Elevator Controller at rated Voltage to perform the Rescue operation. The Rescue device interfaces with the ES Drive which has a unique feature of "Low voltage DC operation" to operate the Elevator Motor with Low voltage Battery.   The Automatic Rescue comprises of two-phase space vector modulated inverter and a state of the art high frequency battery charger with four operating modes of charging.   During Mains power ON, it monitors the power and continuously charges the Batteries. In the event of power failure, the Rescue device will activate within the predetermined "response time 8 second” It will be changeable as per requirement of time.  The Powerful Inverter will produce and supply 2-Phase, 400V, sinusoidal power to the Controller. The Controller is now energized with 2-Phase power and will run the Motor as per the controller command direction at low speed and bring the Elevator to the immediate next floor and opens the door automatically. Upon opening the doors, the trapped passengers shall exit and the Rescue will shut down within 9-10 second the Inverter to prevent any further battery drain. When normal power resumes, the Automatic Rescue will automatically switch over the Controller to Normal Operation.

It is mandatory for buildings above 7 Storey. The Speed velocity of the elevator is equal to or greater than 1 ms. we provide automatic rescue device (ARD) if required by the customer. Designer golden finish auto door lift provides a state of art impression to the building.

The smart rescue device is the safest automatic elevator evacuation device designed for vf elevators. The smart rescue relates to a new concept and design and operates the elevator controller at rated voltage to perform the evacuation operation
