Elevator Drive Dealers

• Brand Name: INVT
• Voltage: 415 VAC
• Operation: Close Loop
• Rated Output Power: 4 to 18.5kW
• Rated Output Current: 9.5 Amp
• Rated Input Current: 13.5 Amp

• Type: Automatic
• Certification: CE Certified
• Voltage: 100 - 415 V
• Frequency: 50Hz
• Cooling System: Air Cooling
• Produce Power: 5-10kw
• Frequency: 50
• Phase: 3 Phase
• Brand Name: Fuji
• Power Source: AC
• Shape: Rectangle
• Certification: CE, UL
• Voltage: 415
• Display: LED

• Product Range: Three Phase 415V - 2.2 to 22kW
• Enclosures: IP00
• Control method: Sensorless vector control, Closed Loop Vector Control
• Optional Encoder Cards: Sin/Cos encoder, Endat encoder (ECN413, ECN1313, ERN1387, ERN487 encoders)
• Function: To add power to elevator performance

Features : Ideal for High Speed Elevator Control. Suitable for geared / gearless machines. Starting Torque 200% at 0Hz for Closed Loop & 200% at 0.5Hz for Open Loop Control. Compatibility with various types of encoders. Built-in Line driver & open collector (Incremental) encoder feedback card. Anti-roll-back algorithm. Distance Control through ELIO card. Built-in ARD function. Built-in Braking chopper till 22kW. Conformal Coating complying to IEC 60721-3-3 class 3C2.   Control method : Sensorless vector control. Closed Loop Vector Control.   Overload capacity : Designed to be used for heavy duty applications. Overload capacity:Heavy duty operation: 150% of rated current 60 sec.   Built-in brake control for safe vertical loading : To minimize risk of the elevator’s giving in to the gravitational pull of the earth, brake-control is built in. Extreme precise control.   ELIO Option on board (Distance learning) : Accepts position sensor input ( rid switches etc ). Measures height & stores floor count. Displays floor number, speed in elevator units. Reduces creep time. Controls position. Advance door opening Handshaking with elevator controller

• Output Current: 50 A
• Input Phase: Three Phase
• Usage: Industrial Premises
• Brand: Angel
• Input Voltage: 380-440 V
• Frequency: 50-60 Hz
• Starting Torque: 150% / 3Hz

• Material: Metal
• Shape: Rectangle
• Application: Factories, Home, Industries
• Color: Black
• Frequency: 50Hz
• Feature: Excellent Reliabiale, High Mechanical Strength

• Certification: CE Certified
• Voltage: 220V
• Driven Type: Electric
• Warranty: 1year
• Brand Name: Emotron

CG Emotron new VSE Dedicated Elevator Drives is a reliable choice for elevator OEMs and end users for new and modernization of older elevators. The drive works effortlessly and smoothly with all elevator types and includes excellent tuning features for the safest, most efficient and most comfortable passenger experience without vibration and jerks. VSE features includes safety and reliability, UPS applicable, dedicated brake control sequence and commendable leveling .   Key Features I/O's-3AI,2AO,7D1,2DO,2RO Safety and reliability UPS applicable. Dedicated brake control sequence. Commendable levelling. Silky smoothness Emergency and inspection sped programmable. Quick commissioning. Built—in dynamic braking unit for all models. Light load detection feature. Built in baseblock feature.

• Voltage: 415 VAC
• Frequency: 50 Hz
• Model Name/Number: FR500D
• Input Phase: Three Phase

• Power: 1.5-25 KW
• Sheave Diameter: 350-800 mm
• Line Speed: 0.5-2.5 m/sec

These drives are constructed with worm helical gears and are compact and unicast design and supplied with brake and traction sheave.

• Brand Name: Danfoss

Description : Developed specifically for lifts to provide reliable and excellent ride comfort. Operates without motor contactors and can be commissioned in less than 10 minutes.

Manufactured in compliance with international quality standards, our Elevator Drives are of impeccable quality. Our company shares glorious credentials with the trusted Suppliers of Elevator Drives in Kerala. The Elevator Drives we make available features overshoot and anti-vibration control. Owing to our reliable logistics network, we are capable of delivering bulk orders of the Elevator Drives within stipulated time. Details : Runs induction and synchronous motors Rescue operation using backup power supply Direct-to-floor and Short floor functions Terminal block with parameter backup Maintenance monitor function Rated upto 50oC   Range : 1.5 kW – 110 kW   Our BrandsAllen Bradley, Autonics, Delta, Honeywell, Larsen & Toubro, Omron, Radix, Selec, Shihlin Electric & Yaskawa

• Brand Name: marck
• Driven Type: Electric
• Condition: New
• Type: Elevator Drive
• Country of Origin: India

elevator drive

• Brand Name: VLT
• Input Phase: Three Phase
• Output Power: 5.5 KW
• Input Voltage: 220-415 AC
• Frequency (Hz): 0-3000
• Assembly Style: With heat sink

Consider our name, if seeking for high quality products that are prepared using the best grade material and modern technology. Our associates procure it from the reliable names after complete quality satisfaction. Feel free to get to approach us for placing orders and stay assured for timely and safe deliveries!

• Brand Name: Monarch
• Input Phase: Three Phase
• Input Voltage: 220V-415V
• Power Rating: 4.0 KW to 15 KW
• Phase Type: Three
• DBU in built: 15 Kw

• rated speeds: 0.25 to 2.0 M/sec.

Various types of drive systems are available to cater to applications with rated speeds from 0.25 to 2.0 Msec. These include single speed and Variable voltage variable frequency drives. Selection of an appropriate drive system would depend upon building parameters as well as desired levels of ride comfort and leveling accuracy requirements.

• Model Name/Number: V1000
• Motor Power: 5hp
• Input Voltage: 440V
• Input Phase: 3 - Phase
• Input Frequency: 55hz
• Output Current: 9A

L&T L1000A drive is a reliable product with superior aesthetics, power & high performance vector control technology that meets the current needs & future requirements.
