ENT Operating Microscope Dealers

We are offering ent operating microscopes. optical head : indian zoom optical system zoom ratio: 6:1 binocular tubes : 90deg.straight magnification : 5x to 25x ( step magnifications are also available) eye pieces : 10x / 15x dioptric adjustment objective lens : f=200 mm field of view : 50mm ipd adjustment : 55mm to 75mm fine focusing : by motorized foot control illumination : 15v/150w twin halogen lamps with 100% coaxial through the lenses focused fiber optics light guide 1.5 meter, white bright light more than 80,000 lux when maximum. field of illumination : 70mm filter : cobalt blue, green arm : counter balanced pantographic arm with 320 degree rotation. vertical range of counter balanced arm: 250mm to 300mm floor stand : mobile floor stand on caster wheels for easy handling and absolute stability. base : 600mm x 500mm (approx) height : 1500mm (approx.) weight : 65kg (approx.) power : ac 220v /110v, 50/60hz. spares: dust cover for covering the microscope, set of sterilizable of silicon caps, 15v-150w bulbs, fuses. optional accessories:- 1. Beam splitter with camera mount 2. Ccd camera

• Application: Hospital
• Brand Name: Jb 01
• Driven Type: Electricity
• Color: Black, Creamy, Dark Grey, Grey, White, Z-Black
• Condition: New
• Power: 100W
• Feature: Actual View Quality, Easy To Use
• Voltage: 220V
• Portable Style: Non Portable
• Type: Ent Operating Microscope
• Weight: 60kg
• Warranty: 1yrs
• Country of Origin: India
• Eyepieces: WF10X
• Focus: 200mm
• Objective: M40x
• Magnification Range: 25x

• Objective: F=200mm and F=300mm
• Drawtube: Binocular
• Magnification of binocular: 6X
• Fine focusing distance: 10mm
• Interpupillary distance: 50mm-80mm
• Illumination: Coaxial illumination with 10W

Manufacturer and Supplier of ENT Operating Microscope; we are a leading name in this domain. Extensively used by the hospitals and medical institutes, we certified range of Operating Microscope that is highly durable, quality tested and cost effective as well. We are working with a pool of experts and they ensure that the range commensurate to the international standards.

• Brand Name: Pioneer
• Voltage: 220 - 240 V AC
• Drawtube: Binocular
• Model Name/Number: Pioneer ENT Operating Microscope
• Magnification: 5X, 10X ,20X (3-step)
• Usage/Application: Hospital/Clinic
• Binocular: 90 degree
• Working Distance: 250 mm
• Interpupillary distance Adjustment: 55mm to 75mm
• Field of view: 37.8mm,23.5mm,14.5mm

• Observation Angle: 45, 0 - 80 Continuous binocular tube (F=170mm)
• Total Magnification: 4x to 25x
• Working distance: 175mm (Optional 200mm)
• Brightness: Continuously Variable

0x wide field (Optional 12.5 x wide field) Eye Pieces From +6 to - 6 Diopter Adjustment 45, 0 - 80 Continuous binocular tube (F=170mm) Observation Angle Adjustable from 55mm 75mm by knob Interpupilary Distance

• Weight: 50 Kg
• Application: Hospital, Laboratory
• Power Supply: 220V
• Portable: Yes

• Type: Surgical Microscope
• Working Distance: 200mm, 250mm, 300mm & 400mm of ent microscope
• Packaging Details: Export Worthy Packing
• Instrument classification: Class III
• Model Number: MS 230 PO
• Magnifications: 7.5x, 12.5x & 20x OF ENT Microscope
• Illumination: LED Illumination of ent microscope
• Place of Origin: Haryana, India
• Supply Ability: 100 Unit/Units per Month

• Type: Ent Operating Microscope
• Application: Hospital, Clinic
• Color: Grey, White
• Voltage: 110-240v
• Condition: New
• Feature: Durable, Easy To Use
• Warranty: 2yrs
• Brand Name: Dr.Onic
• Color: White,Grey,Silver,Cream
• Power: 110-240V
• Weight: 58kg (Approx.)
• Magnification: 4x,6x,10x,16x & 25x
• I deal in: New Only
• Eye Pieces:: Eye Pieces:
• Height: 1500mm (Approx.)
• Magnifications: 5 Step- 4x,6x,10x,16x & 25x
• Vertical Range of Counter Balanced Arm:: 250mm to 300mm
• IPD Adjustment:: 55mm to 75mm
• Accessories: Motorized Stand,LED,Beam Splitter,C Mount,HD Camera,Floor Stand
• Base: 600mm x 500mm (Approx)
• Certificates: ISO,CE,FREE SALE
• Model: DXI9
• Automation Grade:: Automatic
• Is It Portable: Portable
• Illumination: Through Fiber Optic Light Source 15V/150W twin LED
• Optics: German
• Field of Illumination: 70mm
• Light Intensity: 80,000 Lux max. at standard conditions
• Objective Lens: F=200mm
• Procedure: ENT
• Fine Focusing: Motorized Fine Focusing by Foot Control System
• Arm: Counter balanced pantographic arm with 320 degree Rotation
• Binocular Tubes: 90 Degree

We are listed among the leading ENT Microscope Manufacturers, Suppliers and Exporters from Ambala, Haryana. We offer ENT Microscopes that are engineered to precision by experts and therefore are guaranteed to deliver desired results. Equipped with 320 degrees rotatable counter balanced gas spring loaded arm, the ENT Microscope offered by us has carved niche for itself in the market.

ENT OPERATING MICROSCOPE ITEM CODE: EN-02 Rajas is engaged in manufacturing and supplying an extensive range of ENT Operating Microscope that caters the diverse needs of medical industry. These microscopes are counted as one of the most advanced microscopes and preferred by medical staff. We offer our range at market leading prices and in standard sizes. Our products are highly appreciated for the following Specifications of ENT Operating Microscope: Optical Head eye Pieces 12.5 x wide field diopter Distance Adjustable from 52 mm to 75 mm by knob Working Distance 175 mm or 200 mm Magnification – Manual 5 step 0.4 x, 0.6 x, 1.0 x, 1.6 x, 2.5 x Adjustment From +6 to -6 Inclination to Vertical 450 off Vertical Interplanetary Field of View (With 175mm bjective) 56, 36, 22, 14, 9 mm Diameter (with 200mm Objective) 80, 51, 31, 19, 12 mm Diameter Total Magnification: (With 175 mm Objectives) 5, 7, 11, 18, 28 (with 200 mm Objectives) 3, 5, 8, 13, 20 Fine Focusing 50 mm manually adjustable/ OPTIONAL Motorized foot control Illumination System:Illumination Standard 60 Illumination coupled with -20 Illuminations for bright Red Reflex Maximum Intensity 75,000 Lux Brightness Continuously Variable Filters Built in Heat Absorbing Filter and UV, GREEN & BLUE Filter with Switchable Facility Light Transmission By Fiber Optic Cable Light Source Twin outlet 15V/150W Halogen Lamp with Cold Reflector Microscope Stand: Arms Counterbalanced Spring Arms Horizontal Length of Arms 850 mm Vertical Height Minimum 905 mm Maximum 1465 mm Vertical Height adjustment 560mm Rotation of Arm 320 0 with lock Floor Stand Mobile Floor Stand OPTIONAL Table Mount Model Dimensions of Base: Length 520 mm Breadth 520 mm Mobility On Four Caster Wheels Power Supply AC 220-240 Volts or 110 V on Request Total Weight (Net) 50 Kgs approx Features: Corrosion resistant High performance Durable

• Application: Clinic
• Minimum Order Quantity: 1 No(s)
• Power Supply: AC 220V to 240V
• Working Dist: F=200mm Objective Lens
• Fine Focusing: Manual Fine Focusing
• Magnification: 0.4x, 0.6x, 1.0x, 1.6x & 2.5x

Technical specification OPTICS:a. Apochromatic Optics with five step magnification changer.b. Magnification Range 2.4x-40x or morec. Max Field of view should be more than 180mm.OBJECTIVE:a. Working distance f=250 mm and 400 mm.b. Fine focusing for 300 mm.BINOCULAR TUBE:a. Inclinable binocular tube f=170 mm or higher.b. Inter pupillary distance adjustment from 55 mm to 75 mm.EYEPIECES:a. Pair of wide field push-in eyepieces 10x or 12.5x with rubber sleevesb. diopter setting -5D to +5D. ILLUMINATION:a. Coaxial fiber optic / direct Xenon or LED illumination system.b. In LED equipped systems: single lamp.c. Dual lamp system with quick change over in case of Xenon.d. Continuously lamp intensity adjustment by control knob near to the surgeon.STAND:a. Stable and sturdy floor stand on four lockable castors, column (height: minimum 1.6m).b. Spring-balance articulated arm, carrier arm, power supply unit.OTHERS:a. With lateral Handgrips for all knobs, dust cover.b. integrated full HD (1080p) camera & full HD recording system. Camera should have play back function for videos & photoc. Microscope is CE Marked & ISO Certified

• Power consumption: 200 watts max

In Built LED Illumination offer low heat generation low power consumption, LED Illumination also guarantees greater contrast and natural color. Sharp 3D image can be observed with high fidelity & Depth. High resolution and wide field optical system having exceptional depth of field.

• Objective: F= 200/250mm
• Type: By Optical Light Guide System
• Type: Floor Stand
• Weight: 60kg Approx.
• Working Distance: 200/250mm
• Interpupillary Distance:
• Adjustment: 55mm to 75mm
• Motorized Foot Focusing System:
• Light Source: 24V/250W Halogen Lamp OR LED Illumination
• Illumination Control: Continuous Adjustment
• Field of Illumination: 70mm
• Filter: Cobalt Blue, Red-Free, Heat Absorbing Filter
• Vertical Range of Counter Balanced Arm: 400mm
• Base Size: 600mm x 550mm
• Height: 1550mm
• Electrical Power: AC 220/110V

• Brand Name: SCISOL

We offer ent operating microscope. Specification of operating microscope for ent: binocular tubes: straight 45 degree inclined apochoramatic magni changer: 0.4 xs, 0.63 xs, 1.0x, 1.6 xs & 2.5 xs objectives: f=250, manual fine focus light source: 15v150w halogen lamp built in filters : green or yellow vertical movement arm: 600mm steps: fiv.

We offer Ent Surgery Operating Microscope. 3 Step Magnification Operating Microscope Description : Advance optical system designed exclusively for Easier. Handling and versatility in ENT Head : 3 Step Magnification Optical Straight Head. Eye Pieces : 10x paired wide field Eyepiece. Magnification : Objectives Lens power 6x, 10x and 16x Objectives Power 0.6x, 1.0x and 1.6x Working Dist : F=200mm

Portable ent operating microscope binocular tubes : fixed at 90deg.straight eye pieces : 10x wide field magnification : 3 step (5x,10x & 20x) objective lens : f=200 mm,300mm,400mm field of view : 50mm ipd adjustment : 55mm to 75mm fine focusing : manual focusing illumination : 15v150w twin halogen lamps with 100% coaxial through the lenses focused fiber optics light guide 1.5 meter, white bright light more than 80,000 lux, maximum at standard condition. field of illumination : 70mm arm : counter balanced pantographic arm with 320 degree rotation. vertical range of counter balanced arm : 350mm to 550mm table clamp stand :( portable) easy handling and absolute stability. weight : 20kg (approx.) power : ac 220v, 5060hz. (110v on request) spares : dust cover for covering the microscope, set of sterilizable of silicon caps, 15v-150w bulbs, fuses.

We are offering surgical ent operating microscopes etc. Surgical ent operating microscopes offered by us are available with a 90° straight optical system in the market. These are manufactured using latest technology and are well equipped with ccd digital camera and lcd monitor or screen. We offer them with continuous adjustable options and these are designed with perfection. These microscopes are available with special zoom capacitates and we offer them for different hospitals, clinics and medical sector. features: innovatively designs highly versatile easily movable
